WIFI Module
Product
Cell Type
Nominal Energy
Nominal Voltage
Nominal Capacity
Continuous Operation Current
Voltage Range
Expansion
Depth of Discharge
Dimensions (W*D*H)
Weight
Cycle Life
Operation Temperature
Storage Temperature
Protection level
Certifications
Remarks:
* In case of 1C continuous charging and discharging, double check with PYTES for operation environment investigating is required. Improper
conditions may trigger system protection.
** 18°C~28°C operation temperature is suggested for best cycle performance purpose.
RF Band Range: 2.412GHz-2.472GHz
Transmit power
802.11b: +17 +/-1.5dBm(@11Mbps)；
802.11g: +15+/-1.5dBm(@54Mbps)；
802.11n: +14+/-1.5dBm(@HT20, MCS7)
Antenna Type:
External WIFI Sticker, I-PEX to SMA 3dBi
Gain: 2.5dBi
Produced by IGEN Tech Co., Ltd.
Battery Module
LFP
5.12 kWh
5.12 V
100 Ah
50 A
45.5~58V
5-15pcs
80%
484*530*140 mm
43 kg
≥6000 cycles
-20°C~60°C
-30°C~60°C
IP20
CE, IEC62619, UL1973, UN38.3
