4 System Installation

4.1 Checking Before the installation

Checking the Outer Packing
Before unpacking the battery, check the outer packing for damage, such as holes and cracks,
and check the battery model. If any damage is found or the battery model is not what you
requested, do not unpack the product and contact your dealer as soon as possible.
Checking Deliverables
After unpacking the battery, check that the deliverables are intact and complete, and free from
any obvious damage. If any item is missing or damaged, contact your dealer. For details about
the number of deliverables delivered with the battery, see below Packing list.
Packing list
Category
Hex head screws
Battery power cable-Positive
Battery Power cable-Negative
Output Power Cable-Positive
Battery
Output Power Cable-Negative
Control
Unit
Communication cable
Antenna parts
Ground cable
RJ45 terminal
Wifi Antenna
hex head screws
Battery
Battery serial power cable
Module
Unit
Battery cascading cable
Earthing Cable
Item Description
M6
4AWG, 132mm, Orange,
Amphenol terminal*2
4AWG, 1550mm, Black,
Amphenol terminal*2
6AWG, 4000mm, Orange
6AWG, 4000mm, Black
3500mm, RJ45*2
1m
RJ45
M6
UL10269/4AWG/160mm,Amphenol
Surlok Plus 5.7mm Terminals,
Positive + Negative
250mm, RJ45*2
150mm
20
Quantity
4
1
1
1
1
1
1
1
2
1
4
1
1
1
