Maxxus Multipress 8.1 Installation & Operating Manual page 14

Advertisement

Assembly Step 9
No.
13
53
54
55
Assembly - Multipress
54
55
Parts list of installation step
Part Name
Push arm assembly
External hexogon screw M16*140
External hexogon locking nut M16
Flat washer Ø16
53
55
13
14
Qty.
1
1
1
2
