The Xerox
DocuPrint N24/
N32
Finisher
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DocuPrint N24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Xerox DocuPrint N24

  • Page 1 The Xerox DocuPrint N24/ Finisher User Guide...
  • Page 2 XEROX®, The Document Company®, the stylized X, DocuPrint, N24, and N32 are trademarks of Xerox Corporation or its subsidiaries. Adobe® and PostScript® are trademarks of Adobe Systems Incorporated.
  • Page 3: Table Of Contents

    Table of Contents Introduction ... 5 How Much of This Guide Must I Read? ... 5 Finisher Overview ... 6 Features ... 7 Built-in Stapler ... 7 Capacity Handling ... 7 Use with Mailbox ... 7 Face-down Bin ... 8 Job Offsetting ...
  • Page 4 Stapling Positions ... 11 Stapling Positions for Letter, Statement, and Executive Paper . 11 Stapling Positions for A4 Paper ... 12 Stapling Positions for A5 Paper ... 13 Stapling Positions A3 Paper ... 14 Stapling Positions for Ledger, Legal, and Folio Paper ... 15 Job Offsetting ...
  • Page 5: Introduction

    Then install the finisher. This document is for use with the DocuPrint N24 and N32 printers. Because most of the printer’s features and functionality are shared by both the DocuPrint N24 and...
  • Page 6: Finisher Overview

    Finisher Overview Figure 1 Finisher components Front View Transport Cover Paper Transport Staple Access Door Unload Button Output Bin 1 Output Bin 2 Output Bin 3 Top View Area E Area F Door G Area H X e r o x D o c u P r i n t N 2 4 / N 3 2 F i n i s h e r U s e r G u i d e The major components of the finisher are indicated in Figure 1 below.
  • Page 7: Features

    Bin 2 receives output from the compiler bin. Finisher bin selection is made from the System Menu at the User Interface, via PCL commands or from printer drivers. Use with Mailbox The finisher is designed to be used with console versions of the DocuPrint N32.
  • Page 8: Face-Down Bin

    Job offsetting is configured either via the User Interface (UI) or through SNMP commands. Job offsetting is a system function; it cannot be configured from the printer drivers. Supported Paper All sizes of paper can be sent to the finisher except A6 and Envelopes.
  • Page 9: Bin Level Sensors

    When a bin is full and the stack height does not allow additional sets to be sent to it, the destination of additional sets directed to the full bin is determined by the Output Timeout system parameter in the printer’s System Menu. See Table 2 on page 17. Safety Limitation When Finisher Bin 3 is selected, the bins are raised to the highest position.
  • Page 10: Bin Capacity

    Bin Capacity Each finisher Bin is capable of stacking up to 667 sheets of 20 lb. paper for long edge feed (LEF) paper sizes and 334 sheets for short edge feed (SEF) paper sizes. The maximum stack height is decreased when stapled sets are delivered to each bin, since stapled sets affect the stability of the output stack.
  • Page 11: Stapling Positions

    Stapling Stapling positions can be sent from the System Menu at the User Interface (See Table 7 on page 19.) or by PJL commands. Positions See “Finisher Specific Commands” (page 32). Stapling Positions Figure 2 illustrates the approximate position of staples for Letter, Statement, and Executive paper in Portrait, for Letter, Landscape, and Inverse Landscape Modes based upon the UI...
  • Page 12: Stapling Positions For A4 Paper

    Stapling Positions Figure 3 illustrates the approximate position of staples for A4 paper in Portrait, Landscape, and Inverse Landscape Modes for A4 Paper based upon the UI parameters indicated in the left hand column. Figure 3 Position 1 Position 2 Dual X e r o x D o c u P r i n t N 2 4 / N 3 2 F i n i s h e r U s e r G u i d e...
  • Page 13: Stapling Positions For A5 Paper

    Stapling Positions Figure 4 illustrates the approximate position of staples for A5 paper in Portrait, Landscape, and Inverse Landscape Modes for A5 Paper based upon the UI parameters indicated in the left hand column. Figure 4 Position 1 Position 2 Dual Stapling positions for A5 paper Stapling...
  • Page 14: Stapling Positions A3 Paper

    Stapling Positions Figure 5 illustrates the approximate position of staples for A3 paper in Portrait, Landscape, and Inverse Landscape Modes A3 Paper based upon the UI parameters indicated in the left hand column. Figure 5 Position 1 Position 2 Dual X e r o x D o c u P r i n t N 2 4 / N 3 2 F i n i s h e r U s e r G u i d e Stapling positions for A3 paper...
  • Page 15: Stapling Positions For Ledger, Legal, And Folio Paper

    Stapling Positions Figure 6 illustrates the approximate position of staples for Ledger, Legal, and Folio paper in Portrait, Landscape, and for Ledger, Legal, Inverse Landscape Modes based upon the UI parameters and Folio Paper indicated in the left hand column. Figure 6 Position 1 Position 2...
  • Page 16: Job Offsetting

    Job Offsetting The finisher, like the Face-Down Bin, supports offsetting output between successive jobs or multiple collated sets of a single job. A system parameter configures the offset function to OFF (no offset), or ON (toggle offset portion of sequential jobs or multiple collated sets of a single job.) Job offset is a system function that cannot be configured by the driver.
  • Page 17: Output Timeout

    Display shows “Bin Full”. Printer waits until the Bin is emptied. Immediately changes destination to Bin 2. If Bin 2 is full, output is directed to Bin 3.
  • Page 18: Paper Output Exception Conditions

    D o c u P r i n t N 2 4 / N 3 2 F i n i s h e r U s e r G u i d e It is possible to send a combination of commands to select an output destination or feature that cannot be processed by the printer. Table 3 describes printer operations when these exceptions occur. Printer Operation Destination is ignored.
  • Page 19: Finisher Menu Options

    Finisher Menu Options Figure 7 System Menu showing finisher-specific options only Job Menu Password Menu Tray Menu PCL Menu Output Dest PostScript Menu System Menu Parallel Menu Staple Mode Ethernet Menu Novell Menu Test Menu Reset Menu *Factory defaults When the finisher is installed, it is reflected in the System Menu in two options: Output Destination and Staple Mode.
  • Page 20 Table 4 System Menu finisher-specific functions Menu Item and Function Output Destination Set the default output bin. The available values are: Face Down Bin* Face Up Bin Finisher Bin 1 Finisher Bin 2 Finisher Bin 3 Staple Mode Set the default Staple Mode. The available values are: Off* Position 1...
  • Page 21: Control Panel Messages

    Close Door G, the Top Cover of the finisher. Close the stapler door. Power off the printer. Then power it back on again. Power off the printer. Then power it back on again. Power off the printer. Then power it back on again.
  • Page 22 D o c u P r i n t N 2 4 / N 3 2 F i n i s h e r U s e r G u i d e Description/Corrective Action Power off the printer. Then power it back on again. Power off the printer. Then power it back on again.
  • Page 23 Check to see that the thumb screw that connects it to the finisher is hand tightened. Power off the printer. Then power it back on again. Power off the printer. Then power it back on again. Power off the printer. Then power it back on again.
  • Page 24: Adding Staples

    Adding The printer will pause during a stapling job when the staple cartridge is empty. Follow these steps to place a new staple Staples cartridge into the finisher. Open the access door on the side of the finisher. Staple replacement and jam...
  • Page 25 Remove the empty cardboard from the cartridge by pressing the clear plastic tab on the top rear of the cartridge as the hand on the right is doing in the figure. Slide the full Staple Cartridge into the finisher until it snaps into place. Slide a new set of staples into the cartridge and pull the tab to release the packaging.
  • Page 26: Clearing Jams

    Clearing Jams Follow the procedures below to clear finisher paper jams. Clearing Area E Follow the procedure below when the Control Panel display reads: Paper Jam Clear Area E. X e r o x D o c u P r i n t N 2 4 / N 3 2 F i n i s h e r U s e r G u i d e Lift the plastic roll cover under the paper transport, using the tab as indicated.
  • Page 27: Clearing Area F

    Clearing Area F Follow the procedure below when the Control Panel display reads: Paper Jam Clear Area F. Clearing Area G Follow the procedure below when the Control Panel display reads: Paper Jam Clear Area G. Raise the cover of the Bypass Transport and remove any jammed paper.
  • Page 28: Clearing Area H

    Clearing Area H Follow the procedure below when the Control Panel display reads: Paper Jam Clear Area H. X e r o x D o c u P r i n t N 2 4 / N 3 2 F i n i s h e r U s e r G u i d e Raise the assembly at Area H and remove any jammed paper.
  • Page 29: Space Requirements

    36 inches (915 mm) 102 inches (2550 mm) For easy operation, maintenance and replacement of consumables, you should select a location for the printer that leaves the minimum clearances around the finisher as shown in Figure 8 and Figure 9.
  • Page 30: Precautions

    D o c u P r i n t N 2 4 / N 3 2 F i n i s h e r U s e r G u i d e Please leave a minimum of 36 inches (900 mm) above the printer when the finisher is installed.
  • Page 31: Finisher Specifications

    Dimensions 1,133 x 633 x 658 mm (HxWxD) Weight 56 kg (124 lbs.) without paper Productivity Up to 32 PPM (Simplex) in continuous running mode with N32 Printer Up to 24 PPM (Simplex) in continuous running mode with N24 Printer...
  • Page 32: Finisher Specific Commands

    D o c u P r i n t N 2 4 / N 3 2 F i n i s h e r U s e r G u i d e Xerox has added some PCL and PJL commands to select output destination and stapling at the finisher.
  • Page 33: Special Notices

    Special Notices FCC Notice for USA Base Printer with Finisher and Canada This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 34: European Markets

    European Markets CE Certification The CE marking applied to this product symbolizes Xerox Limited Declaration of Conformity with the following applicable directives of the European Union as of the dates indicated: January 1, 1995: - Council Directive 73/23/EEC amended by Council Directive 93/86/EEC, approximation of the laws of the member states related to low voltage equipment.
