- Page 1 Kit Instructions Remote Scale Display Mount (NCR 7895 Scanner/Scale) 7360-K912 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Software screen images are representative, and in some cases, may not match a customer’s installed software exactly.
-
Page 3: Revision Record
Revision Record Issue Date Remarks July 2021 First Issue... -
Page 4: Kit Contents
Remote Scale Display Mount (NCR 7895 Scanner/Scale) Remote Scale Display Mount (NCR 7895 Scanner/Scale) This publication provides procedure for installing a Remote Scale Display Mount (NCR 7895 Scanner/Scale) to the NCR FastLane SelfServ™ Checkout (7360). Kit Contents Part Number Description 497-0529311 SSCO R6C Remote Scale Display Mount (7895... -
Page 5: Installation Procedure
Remote Scale Display Mount (NCR 7895 Scanner/Scale) Installation Procedure To install the Remote Scale Display Mount (NCR 7895 Scanner/Scale), follow these steps: 1. Shut down the NCR FastLane SelfServ™ Checkout software and hardware systems. 2. Unlock the Tower frame from the back panels using a key. - Page 6 Remote Scale Display Mount (NCR 7895 Scanner/Scale) 3. Lift the Terminal Display from Tower frame. 4. Align the screw holes of the Remote Scale Display Mount with the Remote Scale Display Clamp just below the cable access hole of Tri-Light Pole and secure both...
- Page 7 Remote Scale Display Mount (NCR 7895 Scanner/Scale) 5. Insert the Scanner Display Cable through the cable access hole of the Remote Scale Display Mount and secure it with two (2) cable ties. 6. Secure the Remote Scale Display using two (2) M4 bolts and two (2) nuts on the...
- Page 8 Remote Scale Display Mount (NCR 7895 Scanner/Scale) 7. Bundle the excess cable length of the Scanner Display Cable and secure it with two (2) cable ties. 8. Insert the bundled excess cable into the Tri-Light Pole access hole and secure the extra length under the Remote Scale Display Bracket with two (2) cable ties, as shown in the image below.
- Page 9 Remote Scale Display Mount (NCR 7895 Scanner/Scale) 9. Route the 7895 Scanner Cable and the Color Camera Cable on the left side of the Tower Cabinet and secure it with a cable tie, as shown in the image below. Note: Ensure that there is enough length on the cables to reach the POS panel.
- Page 10 Remote Scale Display Mount (NCR 7895 Scanner/Scale) 10. Connect the scanner cable to the USB Client port on the NCR 7895 Scanner/Scale.
- Page 11 Remote Scale Display Mount (NCR 7895 Scanner/Scale) 11. Place the Scanner/Scale in the scanner bucket. 12. Lower the Top Plate as shown below:...
- Page 12 Remote Scale Display Mount (NCR 7895 Scanner/Scale) 13. Close the Terminal Display and lock the Tower Frame to the back panels. 14. Ensure that the devices are working properly by powering up the NCR FastLane SelfServ™ Checkout software and hardware systems.
