Kit Instructions Sliding Pack Left Hand 7360-K780 Issue A...
Page 2
NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
Page 3
Revision Record Issue Date Remarks Nov 2017 First release.
This kit contains sliding pack components for a 3–Bag bagwell module in an NCR FastLane SelfServ™ Checkout (7360) unit with a Left-hand orientation. Note: The NCR FastLane SelfServ™ Checkout (7360) can be configured for either Left- hand or Right-hand orientations, which refer to the direction that customers scan and bag items.
7360-K780 Sliding Pack Left Hand Installation Procedures Installing the Sliding Pack involves the following procedures: Remove Scale Tray on the facing page. Remove Rear Panel on page 4. Install Sliding Pack Left Hand on page 5. Note: Before you begin, the leveling feet should set on the floor and must be...
Page 6
7360-K780 Sliding Pack Left Hand Remove Scale Tray To remove the Scale Tray, follow these steps: 1. Lift and remove the Scale Tray from the Bagwell. Note: The Scale Tray will be installed on the Bagwell after installing the Sliding...
7360-K780 Sliding Pack Left Hand Remove Rear Panel To remove the Rear Panel from the Bagwell, do the following: 1. Remove the Scale Tray from the Bagwell. For more information, refer to Remove Scale Tray on the previous page. 2. Remove nuts securing the rear panel to the Bagwell Frame.
Page 8
7360-K780 Sliding Pack Left Hand Install Sliding Pack Left Hand To install the Sliding Pack, do the following: 1. Remove the Scale Tray from the Bagwell. For more information, refer to Remove Scale Tray on page 3. 2. Remove the Rear Panel from the Bagwell. For more information, refer to...
Page 9
7360-K780 Sliding Pack Left Hand 4. Install rail bracket into the side of the bagwell and secure it with two M6 nuts. 5. Install the rear cover panel into the spacer panel and secure it with four M6 nuts.
Page 10
7360-K780 Sliding Pack Left Hand 6. Install the spacer panel with cover panel to the rear side of the bagwell and secure it with three M6 nuts. 7. Install the two housing bearing as shown in the image below and secure it with two...
Page 11
7360-K780 Sliding Pack Left Hand 8. Attach the leg support assembly and secure it with three M6 screws. 9. Slide in the two single rails into the housing bearing as shown in the image below.
Page 12
7360-K780 Sliding Pack Left Hand 10. Align the Sliding Pack main frame with the Bagwell. 11. Extend the two rails from the Sliding Pack and align the holes with the mounting holes of the rail bracket and then secure with five M6 screws on each rail.
Page 13
7360-K780 Sliding Pack Left Hand 12. Install the lock stopper into the spacer panel doing the following. a. Slide the sliding pack frame until the mounting holes in the spacer panel show b. Install the lock stopper into the spacer and secure each stopper with four M6...
Page 14
7360-K780 Sliding Pack Left Hand 13. Install the locking assembly on the main frame and secure it with three M6 nuts. 14. Install the stainless steel top tray on the main frame and secure with ten M4 screws.
Page 15
7360-K780 Sliding Pack Left Hand 15. Install the leg support cover and secure it with M4 screws. 16. Install the scale tray to the bagwell by doing the following. a. Slide the sliding pack frame until the top bagwell shows.
Page 16
7360-K780 Sliding Pack Left Hand b. Install the scale tray on the bagwell. 17. Adjust the leveling feet of the sliding pack by aligning the rail with the housing bearing. Ensure that the rail slides smoothly in the housing bearing.
Page 17
7360-K780 Sliding Pack Left Hand 18. Cover all holes using hole cover labels..
