- Page 1 Kit Instructions PIN Pad Mount (Verifone P400) 7360-K431 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Software screen images are representative, and in some cases, may not match a customer’s installed software exactly.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Dec 2020 First Issue... -
Page 4: Kit Contents
PIN Pad Mount (Verifone P400) This publication provides procedures for installing a PIN Pad Mount for a Verifone P400 device on an NCR FastLane SelfServ™ Checkout (7360) unit. Note: The Verifone P400 PIN Pad is supplied by the customer. Kit Contents... -
Page 5: Installation Procedures
Installing PIN Pad Mount on page 6. • Installing Verifone P400 PIN Pad on page 12. Note: The Verifone P400 PIN Pad is not included in the 7360-K431 PIN Pad Mount (Verifone P400) Kit. For more information, contact an NCR Customer Service Representative. - Page 6 PIN Pad Mount (Verifone P400) Removing Existing PIN Pad Mount Depending on the SelfServ Checkout unit, refer to the following: • Full Recycling (Fixed/Convertible) Unit on the next page. • Credit/Debit Only Unit on page 5.
- Page 7 PIN Pad Mount (Verifone P400) Full Recycling (Fixed/Convertible) Unit To remove the existing PIN Pad Mount, follow these steps: 1. Remove the Allen key securing the PIN Pad Mount to the PIN Pad Arm. 2. Remove the PIN Pad Mount from the PIN Pad Arm, as shown in the images below.
- Page 8 PIN Pad Mount (Verifone P400) Credit/Debit Only Unit To remove the existing PIN Pad Mount, follow these steps: 1. Remove the Allen key securing the PIN Pad Mount to the PIN Pad Arm. 2. Remove the PIN Pad Mount from the PIN Pad Arm, as shown in the images below.
- Page 9 PIN Pad Mount (Verifone P400) Installing PIN Pad Mount Depending on the SelfServ Checkout unit, refer to the following: • Full Recycling (Fixed/Convertible) Unit on the facing page. • Credit/Debit Only Unit on page 9.
- Page 10 PIN Pad Mount (Verifone P400) Full Recycling (Fixed/Convertible) Unit To install the PIN Pad Mount on a Fixed or Convertible unit, follow these steps: 1. Attach the PIN Pad Mount to the PIN Pad Arm. 2. Position the PIN Pad Mount so that its edge is approximately parallel with the Pivot Arm Surface.
- Page 11 PIN Pad Mount (Verifone P400) 3. Fasten the PIN Pad Mount to the PIN Pad Arm using the Allen key.
- Page 12 PIN Pad Mount (Verifone P400) Credit/Debit Only Unit To install the PIN Pad Mount on a Credit/Debit Only unit, follow these steps: 1. Using an Allen key, remove two (2) Allen head screws securing the PIN Pad Plate to the Tilt Arm. 2.
- Page 13 PIN Pad Mount (Verifone P400) 3. Install the PIN Pad Plate on the Tilt Arm using two (2) Allen head screws. 4. Attach the PIN Pad Mount to the PIN Pad Arm.
- Page 14 PIN Pad Mount (Verifone P400) 5. Position the PIN Pad Mount so that its edge is approximately parallel with the Pivot Arm Surface. 6. Fasten the PIN Pad Mount to the PIN Pad Arm using the Allen key.
- Page 15 Note: For the purpose of illustration only, this procedure shows images using a Full Recycling (Fixed) unit. Note: The Verifone P400 PIN Pad is not included in the 7360-K431 PIN Pad Mount (Verifone P400) Kit. For more information, contact an NCR Customer Service Representative.
- Page 16 PIN Pad Mount (Verifone P400) 3. Connect the cable to the PIN Pad port. 4. Attach the PIN Pad on the PIN Pad Mount, as shown in the image below.
- Page 17 PIN Pad Mount (Verifone P400) Note: The maximum vertical tilt of the PIN Pad Plate is 80° and the minimum vertical tilt is 20° as shown in the image below.
