- Page 1 Kit Instructions Basket Over Bagrack 7360-K509 Issue B...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Mar 2017 First issue. Jun 2017 Updated IP PDF template. -
Page 4: Kit Contents
Basket Over Bagrack This kit contains the components to add a Basket Shelf to the NCR FastLane SelfServ™ Checkout 7360. This kit can be used with a Bagrack. Kit Contents... -
Page 5: Installation Procedure
7360-K509 Basket Over Bagrack Installation Procedure 1. Install the Slide Bracket on the Core (7 screws). Note: If some mounting holes are inaccessible, remove the color panel and drill 9 mm holes through the cross marks shown below. The cross marks are located at the... - Page 6 7360-K509 Basket Over Bagrack 2. Align the Slide Rail with Carriage Assembly on the studs of the Slide Bracket and secure with six (6) serrated lock nuts. Note: The studs can be accessed by sliding the Carriage along the Slide Rail.
- Page 7 7360-K509 Basket Over Bagrack 4. Install the Shelf on the Hinge. a. Slide the Shelf Bracket and Hinge Assembly to end of the Slide Rail that is farthest from the front of the Core. b. Partially thread screws on the two upper holes of the Hinge.
- Page 8 Install two (2) screws on the lower holes to secure the Shelf Assembly on the Hinge. e. If the NCR Fastlane SelfServ™ Checkout (7360) unit's orientation is converted from self–checkout mode to assisted service mode, slightly lift the Shelf and slide...
- Page 9 7360-K509 Basket Over Bagrack 5. Install the Bagrack in front of the Shelf.
