Summary of Contents for NCR 7360-K079
- Page 1 Kit Instructions Remote Scanner Bracket 7360-K079 Issue B...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Dec 2016 First issue. Jun 2017 Updated IP PDF template. -
Page 4: Kit Contents
Remote Scanner Bracket The kit contains the components to add a bracket to mount the Remote Customer Scanner to the secondary display of the NCR FastLane SelfServ™ Checkout 7360. Kit Contents... -
Page 5: Installation Procedure
7360-K079 Remote Scanner Bracket Installation Procedure 1. Attach the RCS Mounting Bracket to the 7360 RCS Mount Assembly using two M4 nuts. 2. Place the Remote Customer Scanner on the RCS Mounting Bracket. 3. Slide the Scanner in the direction shown until it clicks and locks into place. - Page 6 7360-K079 Remote Scanner Bracket 4. Secure the Scanner to the 7360 RCS Mount Assembly using a screw. 5. Route the Remote Customer Scanner Cable as shown and secure with cable ties. 6. Remove the Secondary Display from the back of the Tri–Light Pole. ...
- Page 7 7360-K079 Remote Scanner Bracket b. Remove the two screws from the Right-hand Brace. c. Remove the Right-hand Brace then remove the Secondary Display from the Tri– Light Pole. Note: The Left-hand Brace is attached to the back of the display.
- Page 8 7360-K079 Remote Scanner Bracket 7. Lay the display face down on a flat surface. Note: Always use a soft material (cloth, foam) to protect the display screen when placing the display face down. 8. Remove the two screws.
- Page 9 7360-K079 Remote Scanner Bracket 9. Install the 7360 RCS Mount Assembly on the back of the display using the two M4 x 8 screws included in the kit. 10. Reinstall the Secondary Display to the back of the Tri–Light Pole. a. Align the embossed feature of the Left–hand Brace to the hole in the Pole.
- Page 10 7360-K079 Remote Scanner Bracket b. Align the pins of the Right–hand Brace with the holes on the Left–hand Brace. c. Secure the Braces using two screws.
- Page 11 7360-K079 Remote Scanner Bracket 11. Reconnect the Display Cables to the back of the Secondary Display. 12. Insert the Remote Customer Scanner Cable down the Tri–Light Pole.
- Page 12 7360-K079 Remote Scanner Bracket 13. Use a key to unlock the tower. 14. Raise the terminal.
- Page 13 7360-K079 Remote Scanner Bracket 15. Remove the 7879 Scanner from the bucket area. a. Lift and remove the Scale Plate from the 7879 Scanner. b. Grasp the front of the 7879 Scanner and lift up, then grasp the back of the...
- Page 14 7360-K079 Remote Scanner Bracket c. Pull out the loose end of the Remote Customer Scanner Cable and route as shown. d. Connect the Remote Customer Scanner Cable to USB Port C or Port D on the back of the 7879 Scanner.
