- Page 1 Kit Instructions Secondary Display Mount 7360-K010 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
- Page 3 Revision Record Issue Date Remarks Sep 2016 First issue. Jun 2017 Updated IP PDF template.
- Page 4 Secondary Display Mount This kit contains the components to add a Secondary Display Mount to the NCR FastLane SelfServ™ Checkout 7360. Kit Contents...
- Page 5 7360-K010 Secondary Display Mount Installation Procedure 1. Install the VESA Mount Plate and Left–hand Brace Assembly to the Secondary Display. a. Hook the VESA Mount Plate into the corresponding slots on the back of the Secondary Display. b. Slide the VESA Mount Plate and Left–hand Brace Assembly into place.
- Page 6 7360-K010 Secondary Display Mount c. Secure the Plate and Brace Assembly to the Secondary Display using two screws. 2. Position the Secondary Display with Plate and Brace Assembly above the cable opening on the back of the Tri–Light Pole.
- Page 7 7360-K010 Secondary Display Mount 3. Mount the Secondary Display on the Pole. a. Align the embossed feature of the Left–hand Brace to the hole in the Pole. b. Align the pins of the Right–hand Brace with the holes on the Left–hand Brace.
- Page 8 7360-K010 Secondary Display Mount c. Secure the Braces using two screws. 4. Connect the cables to the back of the Secondary Display.
