NCR 7358-K702 Kit Instructions

NCR 7358-K702 Kit Instructions

2-bag bagwell module (medium gray)
Hide thumbs

Advertisement

Quick Links

Download this manual
Kit Instructions
2-Bag Bagwell Module (Medium Gray)
7358-K702
Issue C

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7358-K702 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NCR 7358-K702

Summary of Contents for NCR 7358-K702

  • Page 1 Kit Instructions 2-Bag Bagwell Module (Medium Gray) 7358-K702 Issue C...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.

  • Page 3: Revision Record

    Issue Date Remarks Mar 2021 First Issue May 2021 • Updated illustration and part numbers in the Kit Contents section. • Updated procedures. • Added procedures for NCR FastLane SelfServ™ Checkout (7370). Aug 2022 Added procedures for NCR FastLane SelfServ™ Checkout (7360).
  • Page 5 2-Bag Bagwell Module (Medium Gray) This publication provides the steps for installing the 7358-K702 2-Bag Bagwell Module (Medium Gray) to a SelfServ Checkout unit. The kit is designed using modules that are ready to be assembled at the site. The NCR FastLane SelfServ™ Checkout with a Bagging Area (Bagwell) Module or...

  • Page 6: Kit Contents

    2-Bag Bagwell Module (Medium Gray) Kit Contents Part Number Description 497-0530819 Large Basket 2-Bag Module Kit (WM Medium Gray) 006-8627877 Push In Rivet, 0.25", Black (6 pcs)
  • Page 7 2-Bag Bagwell Module (Medium Gray) Part Number Description 006-8627878 Wingnut, 1/4-20, Zinc-Plated Steel (3 pcs) 006-8627935 Screw, Flat Head, M6 X 16Mm L, Steel (8 pcs) Note: If needed, use these screws to mount Bag Racks on the Top Trays. 006-8628097 Plastic Knob, 1/4-20 X 5/8"...
  • Page 8 2-Bag Bagwell Module (Medium Gray) Shipping Dimension and Weight This section shows the approximate shipping dimension and weight of the 7358-K702 2- Bag Bagwell Module (Medium Gray). Note: These values are for reference only. Shipping Dimension Shipping Weight Height Length...
  • Page 9 2-Bag Bagwell Module (Medium Gray) Module Dimension and Weight This section shows the approximate dimension and weight of the 7358-K702 2-Bag Bagwell Module (Medium Gray). Note: These values are for reference only. Module Dimension Module Weight Height Length Width Pounds (lbs) Kilograms (kgs) 737.0 mm...

  • Page 10: Required Tools

    2-Bag Bagwell Module (Medium Gray) Required Tools The 7358-K702 2-Bag Bagwell Module (Medium Gray) is designed to be assembled without tools. But, if a push-in rivet needs to be removed NCR recommends using any of the following tools: • wire cutter •...

  • Page 11: Installation Procedures

    2-Bag Bagwell Module (Medium Gray) Installation Procedures Installing the 7358-K702 2-Bag Bagwell Module (Medium Gray) involves the following procedures: Setting up the modular 2-Bag Bagwell on the next page. 2. Installing the Bagwell to the SelfServ Checkout unit. Depending on the unit, refer to either of the following procedures: •...
  • Page 12 2-Bag Bagwell Module (Medium Gray) Setting up the modular 2-Bag Bagwell Set up the modular Bagwell before installing the assembly to the Core Cabinet Door. Note: The procedure uses the Right-hand (RH) orientation for reference. 1. Lay the U-Module on its side as shown in the image below. 2.
  • Page 13 2-Bag Bagwell Module (Medium Gray) b. Slide the hooks into the U-Module slots to engage the hooks. Ensure that the End Panel snaps in place. c. Verify that all hooks are properly engaged.
  • Page 14 2-Bag Bagwell Module (Medium Gray) d. Fasten the End Panel and U-Module together using two (2) push-in rivets. 3. Attach the U-Module to the U-Module assembly by doing the following: a. Align the hooks with the slots (two on each side) of the Center Panel assembly, and then slide down to engage the hooks.
  • Page 15 2-Bag Bagwell Module (Medium Gray) b. Fasten the U-Modules together using using two (2) push-in rivets. 4. Attach the End Panel to the U-Module assembly by doing the following: a. Align the hooks with the slots (two on each side) of the U-Module assembly, and then slide down to engage the hooks.
  • Page 16 2-Bag Bagwell Module (Medium Gray) b. Fasten the End Panel and U-Module together using two (2) push-in rivets.
  • Page 17 2-Bag Bagwell Module (Medium Gray) Installing Modular 2-Bag Bagwell Fence To install the Bagwell fence, follow these steps: 1. Assemble the modular 2-Bag Bagwell. For more information, refer to Setting up the modular 2-Bag Bagwell on page 8. 2. Install the modular 2-Bag Bagwell assembly. For more information, refer to Installing the modular 2-Bag Bagwell to a 7358 Core Cabinet on the next page.
  • Page 18 2-Bag Bagwell Module (Medium Gray) Installing the modular 2-Bag Bagwell to a 7358 Core Cabinet To install the modular 2-Bag Bagwell to the Core Cabinet of an NCR FastLane SelfServ™ Checkout (7358), follow these steps: Note: The procedure uses the Right-hand (RH) orientation for reference.
  • Page 19 2-Bag Bagwell Module (Medium Gray) 4. Secure the Bagwell using four (4) black knob screws.
  • Page 20 2-Bag Bagwell Module (Medium Gray) Installing the modular 2-Bag Bagwell to a 7370 Pedestal Cabinet To install the modular 2-Bag Bagwell to the Pedestal Cabinet of an NCR FastLane SelfServ™ Checkout (7370), follow these steps: Note: The procedure uses the Right-hand (RH) orientation for reference.
  • Page 21 2-Bag Bagwell Module (Medium Gray) 5. Secure the Bagwell using two (2) red knob screws. 6. Install a hole plug in the area not covered by the Pedestal Cabinet, as shown in the example below.
  • Page 22 2-Bag Bagwell Module (Medium Gray) 7. Install the Bagwell Support Bracket by doing the the following: a. Attach the Bagwell Support Bracket using two (2) bolts on the underside of the Scanner Bucket and two (2) bolts on the Bagwell. b.
  • Page 23 2-Bag Bagwell Module (Medium Gray) Installing the modular 2-Bag Bagwell to a 7360 Core Cabinet To install the modular 2-Bag Bagwell to the Core Cabinet of an NCR FastLane SelfServ™ Checkout (7360) unit, follow these steps: Note: The procedure uses the Right-hand (RH) orientation for reference.
  • Page 24 2-Bag Bagwell Module (Medium Gray) 4. Secure the Bagwell using four (4) M6 red knob screws.
  • Page 25 2-Bag Bagwell Module (Medium Gray) Installing Modular 2-Bag Bagwell Top Tray To install the Top Tray on the Bagwell, follow these steps: 1. Place the Top Tray on the Bagwell. Ensure that the captive screws on both ends of the Top Tray are aligned with the corresponding screw holes on Bagwell. 2.
  • Page 26 2-Bag Bagwell Module (Medium Gray) Changing Modular 2-Bag Bagwell Orientation To change the orientation of the Bagwell, follow these steps: Note: For the purpose of illustration only, this procedure shows images using Right- hand (RH) orientation. 1. Remove the Top Tray from the Bagwell. For more information, refer to Removing Modular 2-Bag Bagwell Top Tray on the facing page.
  • Page 27 Removing Modular 2-Bag Bagwell Top Tray To remove the Top Tray from the Bagwell, follow these steps: Note: The illustrations in this procedure shows an NCR FastLane SelfServ™ Checkout (7358) unit only as an example. 1. Loosen the captive screws at each end of the Top Tray, as shown in the image below.
  • Page 28 2-Bag Bagwell Module (Medium Gray) Removing Bagwell Fence To remove the Bagwell fence, follow these steps: 1. Remove the Bagwell Top Tray. For more information, refer to Removing Modular 2- Bag Bagwell Top Tray on the previous page. 2. Remove two (2) wing nuts that are securing the Rear Fence to the Bagwell. 3.
  • Page 29 2-Bag Bagwell Module (Medium Gray) Removing the modular 2-Bag Bagwell from a 7358 Core Cabinet To remove the modular 2-Bag Bagwell from the Core Cabinet of an NCR FastLane SelfServ™ Checkout (7358), follow these steps: Note: The procedure uses the Right-hand (RH) orientation for reference.
  • Page 30 2-Bag Bagwell Module (Medium Gray) 3. Pull the Bagwell assembly away from the Core Cabinet, as shown in the image below.
  • Page 31 2-Bag Bagwell Module (Medium Gray) Removing the modular 2-Bag Bagwell from a 7370 Pedestal Cabinet To remove the modular 2-Bag Bagwell from the Pedestal Cabinet of an NCR FastLane SelfServ™ Checkout (7370), follow these steps: Note: The procedure uses the Right-hand (RH) orientation for reference.
  • Page 32 2-Bag Bagwell Module (Medium Gray) b. Remove two (2) bolts from the underside of the Scanner Bucket and two (2) bolts from the Bagwell. 3. Remove two (2) red knob screws to detach the Bagwell from the Pedestal Cabinet.
  • Page 33 2-Bag Bagwell Module (Medium Gray) 4. Pull the Bagwell assembly away from the Pedestal Cabinet, as shown in the image below.
  • Page 34 2-Bag Bagwell Module (Medium Gray) Removing the modular 2-Bag Bagwell from a 7360 Core Cabinet To remove the modular 2-Bag Bagwell from the Core Cabinet of an NCR FastLane SelfServ™ Checkout (7360) unit, follow these steps: Note: The procedure uses the Right-hand (RH) orientation for reference.
