NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
Page 3
Revision Record Issue Date Remarks Feb 2018 First issue.
Lower Bumper Kits This publication provides procedures for installing Lower Bumpers on the Core Cabinet, Core Door, and Bagwell module in an NCR SelfServ™ Checkout (7350) unit. Kit Contents Depending on the existing configuration, refer to any of the following kits: •...
7350-K600/K601/K602 Lower Bumper Kits Installation Procedures Installing the Lower Bumpers on the NCR SelfServ™ Checkout (7350) unit involves the following procedures: • Installing Core Door Bumper on the next page. • Installing Lower Bumpers on Core Cabinet on page 9. • Installing Lower Bumpers on Bagwell...
Page 9
7350-K600/K601/K602 Lower Bumper Kits Installing Core Door Bumper To install the Core Door Bumper, follow these steps: 1. Uninstall the plastic door fascia from the metal core door by removing ten 8–32 pan head screws. 2. Attach the lower bumper bracket onto the metal core door using 10-32 pan head screws.
Page 10
7350-K600/K601/K602 Lower Bumper Kits 3. Attach the plastic door fascia onto the metal core door using ten 8–32 pan head screws. 4. Remove the three plastic plugs from the plastic door fascia as shown in the image below.
Page 11
7350-K600/K601/K602 Lower Bumper Kits 5. Do the following: a. Insert three clear zinc bumper spacers into each hole on the plastic door fascia. b. Align the core door bumper holes with the corresponding bumper spacer and then secure using three 1/4–20 flat head screws as shown in the image below.
Page 12
7350-K600/K601/K602 Lower Bumper Kits Installing Lower Bumpers on Core Cabinet To install lower core bumpers on the Core Cabinet, follow these steps: 1. Remove hole cover labels located from the lower area of the Core Cabinet as shown in the image below. 2.
Page 13
7350-K600/K601/K602 Lower Bumper Kits 3. To install the Rear Core Lower Bumper, do the following: a. Insert a bumper spacer into each hole. b. Align the Rear Core Lower Bumper holes with the corresponding bumper spacer and then secure using two 1/4–20 flat head screws as shown in the image below.
Page 14
7350-K600/K601/K602 Lower Bumper Kits Installing Lower Bumpers on Bagwell To install lower bumpers on the bagwell, follow these steps: Note: This procedure provides instructions for installing the kit on a 3–Bag Bagwell configuration only as an example. 1. Remove hole cover labels from the lower area of the Bagwell as shown in the image below.
Page 15
7350-K600/K601/K602 Lower Bumper Kits 2. To install the Bagwell Door Bumpers, do the following: a. Insert a bumper spacer into each hole on the bagwell doors. b. Align the Bagwell Door Bumper holes with the corresponding bumper spacer and then secure each bumper using two 1/4–20 flat head screws as shown in the image below.
Page 16
7350-K600/K601/K602 Lower Bumper Kits 3. To install the Wrap Around Corner Bumper on the Bagwell side, do the following: a. Insert a bumper spacer into each hole. b. Align the Wrap Around Corner Bumper holes with the corresponding bumper spacer and then secure using three 1/4–20 flat head screws as shown in the image below.
Page 17
7350-K600/K601/K602 Lower Bumper Kits 4. Detach the back splash from the bagwell frame by removing seven 8–32 pan head screws. 5. Attach the rear support bracket onto the bagwell frame using four 8–32 nut.
Page 18
7350-K600/K601/K602 Lower Bumper Kits 6. Attach the back splash onto the bagwell frame using seven 8–32 pan head screws. 7. To install a Rear Bagwell Bumper, do the following: a. Insert a bumper spacer into each hole on the back splash. b.
