Kit Instructions
Ingenico IPP320350 - SP1
7358-K403
Issue A

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7358-K403 and is the answer not in the manual?

Questions and answers

Related Manuals for NCR 7358-K403

Summary of Contents for NCR 7358-K403

  • Page 1 Kit Instructions Ingenico IPP320350 - SP1 7358-K403 Issue A...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.

  • Page 3: Revision Record

    Revision Record Issue Date Remarks Dec 2021 First Issue...

  • Page 5: Kit Contents

    This publication provides procedure for installing the 7358-K403 Ingenico IPP320350 - SP1 to the NCR FastLane SelfServ™ Checkout (7358) R6L Plus. Note: The PIN Pad device is not included in the 7358-K403 Ingenico IPP320350 - SP1 Kit. For more information, contact and NCR Customer Service Representative.

  • Page 6: Required Tools

    Ingenico IPP320350 - SP1 Required Tools The following tools are required for removing and installing the7358-K403 Ingenico IPP320350 - SP1. • Phillips Screwdriver #2 • #8–32 Nut Driver Note: Use a magnetized screwdriver to easily handle the screws.

  • Page 7: Installation Procedures

    Ingenico IPP320350 - SP1 Installation Procedures To install the 7358-K403 Ingenico IPP320350 - SP1 to the NCR FastLane SelfServ™ Checkout (7358) R6L Plus unit, follow these steps: 1. Turn off the NCR SelfServ Checkout software and hardware systems. 2. Open the Upper Cabinet Door. For more information, refer to Opening Tower Cabinet on page 6.
  • Page 8 Ingenico IPP320350 - SP1 4. Align the Space Pole Adapter to the PIN Pad slot on the Upper Cabinet Door and then secure using four (4) wing nuts. Ensure that the orientation of the Space Pole Adapter is the same with the image shown below. 5.
  • Page 9 Ingenico IPP320350 - SP1 6. Secure the PIN Pad mount using one (1) Allen screw, as shown in the image below.
  • Page 10 Ingenico IPP320350 - SP1 Opening Tower Cabinet To open the Tower Cabinet, follow these steps: 1. Insert the key into the door latch lock and turn key counterclockwise. 2. Remove the key and then press the keylock to unlatch the door. Caution: Ensure that the door is pushed down while lock is pressed because the door will automatically open.
  • Page 11 Ingenico IPP320350 - SP1 3. Raise the Tower Cabinet door.
  • Page 12 Ingenico IPP320350 - SP1 Removing Existing PIN Pad Mount Assembly To remove the existing 7358-K403 Ingenico IPP320350 - SP1 from the NCR FastLane SelfServ™ Checkout (7358) R6L Plus unit, follow these steps: 1. Turn off the NCR SelfServ Checkout software and hardware systems.
  • Page 13 Ingenico IPP320350 - SP1 4. If necessary, do the following: a. Open the Upper Cabinet Door. For more information, refer to Opening Tower Cabinet on page 6. b. Detach the Space Pole Adapter from the Upper Cabinet Door by removing four (4) wing nuts.
