- Page 1 Kit Instructions Handheld Scanner Mounting Arm 7350-K804 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Software screen images are representative, and in some cases, may not match a customer’s installed software exactly.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Apr 2020 First Issue... -
Page 5: Kit Contents
7350-K804 Handheld Scanner Mounting Arm This publication provides procedures for installing a Handheld Scanner Mounting Arm on NCR SelfServ™ Checkout (7350) R6L Narrow Core units. Note: Whether the SelfServ Checkout unit is configured as Left-hand (LH) orientation or Right-hand (RH) orientation, the Handheld Scanner Mounting Arm is installed on the side with the Basket Shelf. - Page 6 7350-K804 Handheld Scanner Mounting Arm Part Number Description 497-0477241 Handheld Scanner Mounting Arm 497-0476953 Space Pole Mount - Sp1 - 1.5" Diameter 497-0476958 Hand Scanner Mount Adapter 497-0455311 Bracket, Hand Scanner 006-8611143 Nut Keps, 8-32, Steel, Blue Zinc (6 Pcs)
-
Page 7: Installation Procedure
7350-K804 Handheld Scanner Mounting Arm Installation Procedure To install the Handheld Scanner Mounting Arm, follow these steps: Note: Whether the SelfServ Checkout unit is configured as Left-hand (LH) orientation or Right-hand (RH) orientation, the Handheld Scanner Mounting Arm is installed on the side with the Basket Shelf. - Page 8 7350-K804 Handheld Scanner Mounting Arm 3. Do the following: a. Align the screw hole on the Handheld Scanner Mount Adapter with screw hole on the Space Pole Mount. b. Secure the assembly using one (1) screw.
- Page 9 7350-K804 Handheld Scanner Mounting Arm 4. Do the following: Note: Whether the SelfServ Checkout unit is configured as Left-hand (LH) orientation or Right-hand (RH) orientation, the Handheld Scanner Mounting Arm is installed on the side with the Basket Shelf. a. Align the Handheld Scanner Mounting Arm studs with the corresponding holes on the Tower Frame using four (4) nuts, as shown in the image below.
