XES Synergix™
8825/8830/8850/8855 & X2-Tech
System Introduction
701P37895
March 2002

Advertisement

   Also See for Xerox 8850

   Related Manuals for Xerox 8850

   Summary of Contents for Xerox 8850

  • Page 1 XES Synergix™ 8825/8830/8850/8855 & X2-Tech System Introduction 701P37895 March 2002...
  • Page 2 This page left intentionally blank.
  • Page 3: Emc Notices

    EMC Notices Australia/New Zealand Changes or modifications to this equipment, not specifically approved by Fuji Xerox Australia Pty. Limited, may void the user's authority to operate this equipment. Shielded cables must be used with this equipment to maintain compliance with the Radio Communications Act 1992.
  • Page 4: Japan

    Changes or modifications to this equipment, not specifically approved by Fuji Xerox Limited, may void the user's authority to operate this equipment. Shielded cables must be used with this equipment to maintain compliance with the Voluntary Control Council for Interference by Information Technology Equipment regulations.
  • Page 5: Trademark Acknowledgments

    XEROX , X2-TECH with RACER™, XES Synergix 8855 and 8855 Digital Solution, XES Synergix 8850 and 8850 Digital Solution, XES Synergix 8825 and 8825 Digital Solution, XES Synergix 8830 and 8830 Digital Solution, XES Synergix Scan System, the digital box icon, AccXES, and the acronym XES are trademarks of XEROX Corporation.
  • Page 6: Introduction

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Introduction Congratulations on acquiring your new XES Synergix 8825/8830/8850/8855 or X2-TECH Printer, or XES Synergix 8825/8830/8850/8855 or X2-TECH Digital Solution. We look forward to supporting you and helping you to increase your organizational productivity. The integrated features, the ease...
  • Page 7: Table Of Contents

    Making Test Prints... 36 Using the Web Printer Manager Tool (8825/8830/8850/8855 & X2- TECH) ... 36 Using the XES Synergix 8825/8830/8850 Printer Control Panel ... 37 Using Test Prints ... 38 PRINTER CONFIGURATION Test Print... 38 PRINTER SETTINGS Test Print... 39...
  • Page 8 SCSI Device Error Codes ... 56 SCSI Device Error Codes Chart ... 57 Appendices ... 58 Appendix 1 - Key Features of the XES Synergix 8825/8830/8850 Printer/Digital Solution ... 58 Appendix 2 - Key Features of the XES Synergix 8855 Printer/Digital Solution...
  • Page 9: 8825/8830/8850 System Components

    The Printer is typically supplied with an embedded AccXES Controller. For the availability of printers without AccXES Controllers, contact your Sales Representative. The XES Synergix 8830 and 8850 Printers have a 3 roll media capacity. The XES Synergix 8825 Printer is manufactured in either a one roll or two roll configuration.
  • Page 10: 8855 System Components

    6 or 16 meters (19.7 or 52.5 feet) depending upon your installation configuration. For more advanced finishing needs, your printer can be equipped with a programmable On-line Folder, or Xerox Stacker with print-stacking capabilities of up to 500 E size prints or copies.
  • Page 11: X2-tech System Components

    X2-TECH System Components The X2-TECH Color Printer is available in 36" wide or 54" wide format, in two configurations. The first configuration is comprised of the X2-TECH Color Printer and an AccXES Controller. The second configuration, known as the Digital Solution, combines the X2-TECH Color Printer with the Synergix Scan System and the AccXES Controller.
  • Page 12: 8825/8830/8850 System Capabilities

    Accounting software running on a networked client workstation, or with third party software running on a Server. 8825/8830/8850 Digital Solution • Copy, collate, and fold* through the 8825/8830/8850 Digital Solution (* with the optional Folder). • Scan documents to be stored as electronic files, which are retrieved at a workstation using the AccXES Client Tool’s Retrieve Tool.
  • Page 13 XES Synergix Scan System XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction XES Synergix 8850 Printer Figure 2. A Digital Solution is comprised of an 8825 printer, with EV4 Controller, or 8830/8850 printer, with CNG Controller, and an XES Synergix Scan System.
  • Page 14: 8855 System Capabilities

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction 8855 System Capabilities XES Synergix 8855 Engineering Printer • Print documents directly from desktop applications like AutoCAD. • Create sets of documents, send or cancel print jobs, and view the printer queue from remote workstations with the AccXES Client Tools.
  • Page 15 8855 System Capabilities (continued) XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Figure 4. A Digital Solution is comprised of an 8855 printer, with UP8 Controller and an XES Synergix Scan System.
  • Page 16: X2-tech System Capabilities

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction X2-TECH System Capabilities • Print documents directly from desktop applications like AutoCAD. • View the printer queue, cancel print jobs, resolve media mismatches, and change printer defaults remotely with the Web Printer Manager Tool.
  • Page 17: Optional On-line Folders

    Optional On-line Folders The folder is an optional finishing device which can be used with the XES Synergix 8825/8830/8850/8855 Engineering Printer or Digital Solution. The default finishing options are controlled from your workstation by using the Web PMT or the AccXES Client Tools. You may be offered a limited selection of folding options, or a full selection of finishing programs to choose from, depending upon your attached folding device.
  • Page 18: Optional Stacker 1000

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Optional Stacker 1000 The Xerox Stacker 1000 is an optional finishing device which may be used with the XES Synergix 8825/8830/8850 printer or the XES Synergix 8825/8830/8850 Digital Solution. The illustration shows the Xerox Stacker 1000 with an XES Synergix 8830 printer.
  • Page 19: Getting Started

    This Getting Started Section is designed to help you quickly set up, operate, and troubleshoot your XES Synergix 8825/8830/8850/8855 or X2-TECH Digital Solution, or XES Synergix 8825/8830/8850/8855 or X2-TECH Printer. Quick Start Procedures To get your system up and operational fast, the following Quick Start...
  • Page 20: User Guide References For Additional Information

    Changing System Parameters, references are included in this section directing you to other manuals where more extensive information can be found. For example, to add a printer, or to add a port to your workstation, refer to the appropriate print driver user guide. Overview of Digital Solution Manuals This is an all inclusive listing of the manuals for the XES Synergix 8825/8830/8850/8855 or X2-TECH Digital Solution for use with Firmware 8.0.
  • Page 21 XES Synergix 8825/8830/8850/8855 Network Administrator’s Guide A guide for the System Administrator to use when connecting the XES Synergix 8825/8830/8850/8855 Printer or Digital Solution to a network. Folder Operator Manual A detailed description of how to use the optional Folder.
  • Page 22 XES Synergix 8825/8830/8850/8855 Windows NT4.0 PostScript Print Driver User Guide XES Synergix 8825/8830/8850/8855 Windows 2000 PostScript Print Driver User Guide XES Synergix 8825/8830/8850/8855 HDI AutoCAD 2000 Print Driver User Guide XES Synergix 8825/8830/8850/8855 HDI AutoCAD 2000i Print Driver User Guide...
  • Page 23: Quick Start For Document Copying

    • Make sure that media is loaded into all drawers of the XES Synergix 8825, 8830, 8850, or 8855 Printer. For full details on loading the roll media, go to the 8825/8830/8850 or 8855 Printer Operator Manual. • 8825/8830/8850 Digital Solution: If necessary, power on the Scanner/Controller Circuit Breaker/Printer.
  • Page 24: Quick Start For Remote Desktop Printing

    Communications Setup (required for initial install only) • Establish Local Area Network (LAN) communications. For full details go to the XES Synergix 8825/8830/8850/8855 Network Administrator’s Guide. • Install Print Drivers on your workstation. For full details go to the applicable Print Driver User Manual.
  • Page 25: Verifying The Remote Workstation Setup

    Select the default printer and scanner. • On the Document Submit Tab, add a file and send it to the printer, as a test that you are connected to the printer. See the previous section in this guide, entitled Printing from Your Desktop, for printing instructions.
  • Page 26: Quick Start For Printing To The X2-tech

    Operating System on your workstation. Select the X2-TECH color printer from the displayed list of printers during driver installation. For full installation details refer to the XES Synergix 8825/8830/8850/8855 HP GL/2 & HP RTL Print Driver User Guide. Figure 9. Typical Main Page of the Web PMT...
  • Page 27: Color Printing With The Hp-gl/2 Driver

    In Windows 95/98/NT 4.0 Select “File,” “Print,” within a desktop application (such as Microsoft Word) to display the Print Screen which lets you select your printer, the number of copies to be printed, and the range of pages to be printed.
  • Page 28: Quick Start For Scanning To Net

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Quick Start for Scanning to Net Note: Scan-to-Net is a standard feature of the 8830/8850/8855/X2-TECH Digital Solutions, and an optional feature of the 8825 Digital Solution. Effective with Firmware Release 7.5, a new Color Enablement feature key is available enabling Scanning-to-Net in color in TIFF and JPEG formats.
  • Page 29 & X2-TECH Digital Solution User Guide. READY TO SCAN INSERT DOCUMENT AUTO 100.0% Menu Previous Next Enter Exit Figure 10. Typical Scanner Control Panel XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Batch Transform Sample Sets Build Finisher Store/ Recall C/CA Start Mode...
  • Page 30: Retrieving Scanned Documents

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Quick Start for Scanning to Net (continued) Retrieving Scanned Documents • With the AccXES Client Tools running on your workstation, select the Document Retrieve Tab. • In the Scan Directory field, type in the 16 alphanumeric character directory name that you used at the scanner when you scanned your images.
  • Page 31 Right click on a retrieved file name and select the Raster Editor button to edit a file before saving it. If the file does not open within the XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Raster Editor, open the Raster editor separately, then open the file from within the editor program.
  • Page 32: Quick Start For Job Accounting

    When the XES Job Accounting license is optionally purchased (8825 and X2- TECH) or provided as a standard item of your system purchase (8830/8850/8855), make sure to have your System Administrator use the Web Printer Manager Tool or Printer Control Panel to check the setting of the Controller's Account Mode.
  • Page 33: Quick Start For Plot Nesting

    Plot nesting parameters can be set with the AccXES Client Tools, with the Web Printer Manager Tool, or with the XES Synergix 8825/8830/8850 Printer Control Panel as described in this section. Setting Nesting Parameters with AccXES Client Tools •...
  • Page 34: Plot Nesting Using The Web Printer Manager Tool

    If your browser starts up in the Mail or News mode, go to the Browser mode. 2. In the browser URL box enter http:// followed by the printer’s IP address. If you don’t know the printer’s IP address, see your System Administrator or the test print set produced at the time of your printer’s installation.
  • Page 35: Accessing Plot Nesting Parameters

    Accessing Plot Nesting Parameters 1. Click on the PRINTER DEFAULTS hypertext link. 2. Click on the PRINTER SETUP group of the Printer Defaults Side Menu and the PRINTER SETUP menu will expand to show the subgroup menu items and display the top page of the PRINTER SETUP group, which is the Miscellaneous page (see Figure 13).
  • Page 36: Setting Plot Nesting Parameters

    The factory default setting is Off. Timeout — In this text box, enter the maximum idle time (in seconds) for the printer to wait after processing a print job, before printing and cutting a nested page. The factory default is 5 seconds.
  • Page 37: Setting Nesting Parameters With The 8825/8830/8850 Printer Control Panel

    Press the Next key until MARGIN is displayed. Either accept the factory default setting of zero (0), or press the Enter key to change the setting. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Input the Plot Nesting Margin using a number between 0 and 25 millimeters using the numeric keypad.
  • Page 38: Changing System Parameters To Meet Your Needs

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Changing System Parameters to Meet Your Needs Changing Copying Parameters (8825/8830/8850/8855 Digital Solution) For full details go to the XES Synergix & X2-TECH Digital Solution User Guide. NOTE: The X2-TECH Digital Solution does not support copying at this time.
  • Page 39: Using The Document Submit Tool

    Document Retrieve tab, or by opening a saved document set. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction • Change print job or document options. The three types of options that can be accessed to customize the print job and documents in the set are listed below.
  • Page 40: Document Options

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Changing System Parameters to Meet Your Needs (continued) DOCUMENT OPTIONS Double click on the file name in the Document Submit window to go to the individual document print option tabs. This allows you to modify the default options of individual documents.
  • Page 41: Effect Of Postscript Jobs On Copies, Collation And Finishing Settings

    If PostScript collation is false, PostScript copies is a page parameter.) * Note that if a Banner Page is enabled BEFORE the job, the job is treated as a multiple data format job with the banner page being file 1. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction...
  • Page 42: Problem Solving (8825/8830/8850)

    Panels, as well as on the printed ERROR/WARNING PAGE. The test prints (PRINTER CONFIGURATION and PRINTER SETTINGS) that you can run with the “Utilities Menu” on the Printer Control Panel, print out all the current settings, the status of the Controller, key information on the Network Interface Card(s), and a list of the most recent errors encountered during printer operation.
  • Page 43: Problem Solving (8855 & X2-tech)

    Problem Solving (8855 & X2- TECH) For the 8855: LED (light emitting diode) displays on the 8855 Printer and its UP8 Controller will advise you of basic operating problems. (See the 8855 & X2-TECH Controller Status LED Table in this System Introduction manual.)
  • Page 44: Making Test Prints

    PostScript Test — Press the PostScript button to print a PostScript test page (a PostScript license is required). Clicking any of the above buttons will send the test print request to the printer for immediate processing. A message will display showing the success or failure of this request.
  • Page 45: Using The Xes Synergix 8825/8830/8850 Printer Control Panel

    Using the XES Synergix 8825/8830/8850 Printer Control Panel If you would rather generate a test print from the printer, do the following: • While the Printer is NOT printing, at the 8825/8830/8850 Printer Control Panel press the ONLINE key. PAUSED will be displayed. •...
  • Page 46: Using Test Prints

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Using Test Prints PRINTER CONFIGURATION Test Print The Configuration test print provides key information as to the current Controller Configuration and Error Log, Print Engine Configuration and Error Log, Installed Media, Communication Parameters (including port and protocol enables), Network Interface Card Hardware (HW) addresses, status of Job Accounting, and Scanner Configuration.
  • Page 47: Printer Settings Test Print

    Manager Tool User Guide (for firmware version 8.0). NOTE: To display the job parameters used at the time that a specific job is printed, set the Diagnostics Page option to ON at the 8825/8830/8850 Printer Control Panel, or on the Miscellaneous Page of the Web PMT.
  • Page 48: Printer Pen Settings Test Print

    906/907, VCGL (color feature only), VDS, HP-GL/HP-GL/2 data formats. Stored pen palettes may be selected to support any of the above-listed emulations. For the XES Synergix 8825/8830/8850 printers, you select an emulation-supporting palette through the Printer Control Panel’s “Setup Printer” / “Emulations” menus. For the XES Synergix 8855 printer and the X2-TECH printer, you select an emulation-supporting palette using the EMULATIONS group of the Printer Defaults Side menu of the Web PMT.
  • Page 49 Using Test Prints (continued) Figure 18. Typical Pen Settings Test Print for Pen Palette 1 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction User-definable pen patterns List of numbered pens (0 to 255)with user- definable Width, Pattern, Color and Override attributes.
  • Page 50: 8825/8830/8850 Printer Control Panel Displayed Error Codes

    This code indicates that the toner cartridge is out of toner and should be replaced. Refer to the CARE section, “Replacing the Toner Cartridge,” in the Xerox 8825/8830 Printer Operator Manual. J2.02 This code indicates that the toner cartridge is not installed correctly. Refer to the CARE section, “Replacing the Toner Cartridge,” in the Xerox 8825/8830 Printer Operator Manual. LL.-- Communications, sensor, or fuser errors.
  • Page 51 For reference purposes, one record is equivalent to one completed job. Use the Account Management Tool to download the contents of the Controller's Job Log file. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction...
  • Page 52: 8855 Printer Displayed Error Codes

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction 8855 Printer Displayed Error Codes The 8855 Printer has a small interface consisting of five 7-segment LEDs (light emitting diodes). The LEDs are used to display printer status, errors, or other conditions that might require user intervention.
  • Page 53: X2-tech Lcd-displayed Error Codes

    X2-TECH LCD-Displayed Error Codes For the meanings of error messages displayed on the X2-TECH printer's LCD, refer to Appendix A of the ColorgrafX X2 User Guide. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction...
  • Page 54: 8855 & X2-tech Controller Status Leds

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction 8855 & X2-TECH Controller Status LEDs AccXES Controllers (UP8 for 8855 and KLF for X2-TECH include 4 status LEDs used to indicate the following conditions: Controller Status LEDs LED Number Color Indicated Condition...
  • Page 55: Scanner Control Panel Displayed Error Codes

    CALL FOR SERVICE. SCANNER FAULT 50000007 INTERNAL FAULT. CALL FOR SERVICE. SCANNER FAULT 50000008 INTERNAL FAULT. CALL FOR SERVICE. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Recommendation Follow instructions on display. Follow instructions on display. Follow instructions on display. Follow instructions on display. Also, try switching off system power, checking cables, then switching on system power.
  • Page 56 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Scanner Control Panel Displayed Error Codes (continued) Status Code SCANNER FAULT 50000009 INTERNAL FAULT. CALL FOR SERVICE. SCANNER FAULT 5000000A INTERNAL FAULT. CALL FOR SERVICE. CONTROLLER FAULT 50000011 INTERNAL FAULT. SCANNED IMAGE LOST. ENTER TO CONT.
  • Page 57 For reference purposes, one record is equivalent to one completed job. Use the Account Management Tool to download the contents of the Controller's Job Log file. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Recommendation...
  • Page 58: Controller Error Codes

    Factory Defaults. Instructions for restoring factory defaults, are provided in the XES Synergix 8825/8830/8850 Controller Setup Manual for Firmware 8.0, or in the Web Printer Manager Tool User Guide (for firmware version 8.0). For full firmware uploading instructions see the Firmware Release Notes that...
  • Page 59: Controller Error Codes Chart

    Floppy Disk Drive recalibration failed. 21080100 No response from Floppy Disk Controller to Sense Interrupt command. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction What To Do About Printed Error Code Refer to “SCSI Device Error Codes” following this table. Call for Service.
  • Page 60 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Printed Error Code Description 21080300 No results available from Floppy Disk Controller for Sense Interrupt command. 210F0100 No response from Floppy Disk Controller to Seek command. 210F0200 Floppy Disk Controller timed out executing Seek command.
  • Page 61 Address Field missing during Read command. 21C60E00 Bad track found during Read command. 21C60F00 Floppy Disk Controller reported equipment check during Read XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction What To Do About Printed Error Code Call for Service. Call for Service. Call for Service.
  • Page 62 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Printed Error Code Description 30000000 A scanner was previously connected to the system, but was not detected during the boot sequence. 30000001 A scanner is connected to the system, but no hard drive was found.
  • Page 63 5000000A The task controlling the scanner reported an unexpected status to the scanner UI task. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction What To Do About Printed Error Code Manually remove the document if necessary. Rescan the document if necessary. If subsequent scans fail to print it is necessary to reboot the Controller.
  • Page 64: Scsi Device Error Codes

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction SCSI Device Error Codes Displayed in the Controller Configuration error log of the PRINTER CONFIGURATION Test Print, SCSI Device Error Codes are in the “1ncckkaa” format. The meaning of the error codes follows...
  • Page 65: Scsi Device Error Codes Chart

    ILLEGAL REQUEST. Indicates that there was an illegal parameter in the command descriptor block or in the additional parameters supplied as data for some commands. Action: Call for Service. Action: Call for Service. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Description /Action...
  • Page 66: Appendices

    8830: throughput at 4 ips, and 7 D(A1) size prints per minute 8825: throughput at 2 ips, and 4 D(A1) size prints per minute. 8850: throughput at 4.5 ips, and 10 D (A1) size prints per minute • Hours of unattended operation with one to three media drawers. Media sizes can be mixed.
  • Page 67 Job accounting can be used to record copying and scanning activities. • 4 ips standard scanning speed with XES Synergix 8830/8850 Digital Solution. Feature key upgrade from 2 ips to 4 ips with 8825 Digital Solution. A 4 to 2 ips downgrade option is available for the 8830/8850 Digital Solutions.
  • Page 68 Submit Tool, the Document Retrieve Tool, and the Printer Queue Tool. These tools are used to do the following: • Establish a connection from your workstation to your 8825/8830/8850 printer's Controller and its attached Digital Solution scanner. • Create sets of documents that can be saved as a single file and sent to a remote printer from your workstation.
  • Page 69: Appendix 2 - Key Features Of The Xes Synergix 8855 Printer/digital Solution

    • Convenient printer setup from individual workstations using the Web PMT. • Available accessories include an optional Folder and Xerox Stacker. AccXES Controller • Plug-and-play performance in standalone or networked configurations with multiple ports: RS-232C Serial port; Bi-directional, IEEE P1284 Parallel port;...
  • Page 70 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Appendix 2 (continued) Controller Firmware • Convenient administration of printer operating settings from individual workstations using the Web PMT. • Print queue can be viewed and managed (with the appropriate password) at individual workstations using the Web PMT or Printer Queue in the AccXES Client Tools.
  • Page 71 ADI print drivers for AutoCAD releases 13 and 14. HDI print drivers for AutoCAD 2000 and 2000i. • HP-GL/2/HP RTL print drivers for Windows. • PostScript PPD Drivers available for Windows 95/98, NT 4.0, and Windows 2000 platforms. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction...
  • Page 72: Appendix 3 - Key Features Of The X2-tech Color Printer/digital Solution

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Appendix 3 - Key Features of the X2- TECH Color Printer/Digital Solution X2-TECH Color Printer • Resolution of 360 x 360 or 720 x 720 dpi in both monochrome and full color. •...
  • Page 73 • Account Data Tracking can be conveniently performed with the optional Account Management Tool running on a networked client workstation. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction • Scan-to-Net is a standard feature with the purchase of an X2-TECH Digital Solution (printer, Controller, and scanner).
  • Page 74 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Appendix 3 (continued) Controller Firmware • Convenient administration of printer operating settings from individual workstations using the Web PMT. • Print queue can be viewed and managed (with the appropriate password) at individual workstations using the Web PMT or Printer Queue in the AccXES Client Tools.
  • Page 75 Print Drivers • HP-GL/2/HP RTL print drivers for Windows 95, 98, NT4, and 2000, are also optimized for use with AutoCAD 2000, 2000i, and 2002. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction...
  • Page 76: Appendix 4 - Xes Synergix 8825/8830/8850 Printer/digital Solution Features And Specifications

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Appendix 4 - XES Synergix 8825/8830/8850 Printer/Digital Solution Features and Specifications Printer Feature Description/Specifications 8825 - EV4 Controller Specifications CPU: Power PC 8240 (603e) operating at 250 MHz clock speed. Hardware Specifications RAM: 64MB DRAM is standard. Maximum RAM is 256MB. Two DIMM Slots accommodate 64 or 128MB, PC100, DIMMs.
  • Page 77 Hard disk: 9.1 GB, Ultra SCSI, 7200 rpm internal hard disk drive standard on CNG. (Required option for N5T running 6.0+ firmware) Physical Characteristics The Controller is attached to the side panel of XES Synergix 8825/8830 Printer as an embedded device. Electrical Requirements 100 - 250 VAC auto-ranging power supply.
  • Page 78 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction N5T/CNG (8830/8850) and EV4 (8825) General Specifications Printer Feature Client/Host Support UNIX telnet, tftp, and lpr/lpd AccXES Client Tools Web Printer Manager Tool AccXES Account Management Tool PC/Windows NT 3.51/4.0 HP-RTL/HP-GL/2 Print Driver...
  • Page 79 Wide area network support (default gateway, netmask parameters) Automatic Active Port Sensing Job Spooling/Queuing Internal to controller: 143 MB+ hard disk Job Queue Management Single Prioritized queue, adjustable pre and post-render job priority, job canceling, queue monitoring, resource based scheduling. XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction...
  • Page 80 Supports all color formats of the non-PostScript data formats. Raster Imaging: Cluster dot halftoning at 45-degree screen angle supporting 128 gray levels (8825/8830) 256 for 8850. Vector Rendering: Advanced stochastic halftoning technique supporting 128 gray levels (8825/8830) 256 for 8850.
  • Page 81 Feature-keyed scanning speeds. Effective with Firmware Release 7.5, a new Color Enablement feature key is available enabling Scanning-to-Net in color in TIFF and JPEG formats. See the “Scanning resolutions and speeds table” in the XES Synergix 8825/8830/8850/8855 Digital Solution User Guide for more details on particular resolution and scan speed combinations.
  • Page 82 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Scan-to-Net Job Processing Retrieval Protocol TCP/IP FTP get Output Format Single bit TIFF 6 Group IV compressed image 8-bit grayscale TIFF 6 w/ Packbits lossless compression 8-bit grayscale TIFF 6 uncompressed Single bit CALS-I Group IV compressed image...
  • Page 83 8855 Family - Kip interface 8 rev G Accounting Standard for 8830/8850. Optional feature key for 8825. Available for print, copy and scan jobs. Accounting of media use is accomplished with the AccXES Account Management Tool running on a networked client workstation.
  • Page 84: Appendix 4 - Xes Synergix 8855 Printer/digital Solution Features And Specifications

    Description/Specifications Power PC 740 200 MHz, 8.5 SpecInt95, 16.0 SpecFP9 (estimated) Printer Only: 64 MB Base (128 MB recommended with PostScript option and PDF printing) Copier/Printer: 64 MB Base (128 MB recommended with PostScript option and PDF printing) 100 MHz, 64 MB SDRAM DIMMs, 192 MB maximum 4-8 MB Flash (upgradeable via host interface) 9.1 GB Ultra SCSI Hard Disk Standard...
  • Page 85 Printer Feature Client/Host Support UNIX (Solaris) Windows NT 4.0 Windows 95/98 Windows 2000 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Description/Specifications tftp and lpr/lpd ftp and telnet (command line) Web Printer Manager Tool AccXES Client Tools AccXES Account Management Tool...
  • Page 86 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Printer Feature Print Job Input Host Interfaces Network Protocols Automatic Active Port Sensing Job Spooling/Queuing Job Queue Management Print Job Processing Data Formats Job Control Language Color Support Automatic Format Recognition Palettes and Patterns...
  • Page 87 Sets Build Batch Key Copy Job Output (8855 Digital Solution) Sample XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Description/Specifications Type (line, photo, mixed), Background (off, light, dark, auto-suppression), Contrast (7 levels) selectable prior to scan time Scaling (preset, 25% - 400% in 0.1% increments, auto), Rotation (Off, auto), Auto Size Detection, Margins, Mirror, Invert, user specified original document width input and centering.
  • Page 88 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Print and Copy Job Rendering and Output Compression Long Plot Multiple Copies Electronic Collation Finisher Support Scan-to-Net Job Processing Retrieval Protocol Output Format Processing Options Scan job parameter sets AHA Starlite 3410, Lossless.
  • Page 89 Scanner Control Panel Interface Accounting Remote Configuration Localization (Languages supported) XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Description/Specifications All printer parameter and processing defaults sets are available through Web PMT No printer UI provided. See Web PMT and test print error messages.
  • Page 90: Appendix 5 - X2-tech Printer/digital Solution Features And Specifications

    XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Appendix 5 - X2-TECH Printer/Digital Solution Features and Specifications Printer Feature Controller (KLF) Memory Hard disk Physical Characteristics Electrical Requirements Agency Approvals I/O Ports Serial (2) Parallel SCSI Ethernet Scanner IEEE 1394 Description/Specifications Power PC 740 200 MHz, 8.5 SpecInt95, 16.0 SpecFP9 (estimated)
  • Page 91 Printer Feature Client/Host Support UNIX (Solaris) Windows NT 4.0 Windows 95/98 Windows 2000 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Description/Specifications tftp and lpr/lpd ftp and telnet (command line) Web Printer Manager Tool AccXES Client Tools AccXES Account Management Tool is Optional Accessory...
  • Page 92 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Printer Feature Print Job Input Host Interfaces Network Protocols Automatic Active Port Sensing Job Spooling/Queuing Job Queue Management Print Job Processing Data Formats Job Control Language Color Support Automatic Format Recognition Palettes and Patterns...
  • Page 93 Scan-to-Net Job Processing Retrieval Protocol Output Format Processing Options Scan job parameter sets XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction AHA Starlite 3410, Lossless. 24.4 meters (80 feet) Print: 1 to 999. Copy: 1 to 999. Yes. Supported by the Controller.
  • Page 94 XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction Printer Feature User Interfaces User Parameter Setup using Web PMT Printer Control Panel Interface AccXES Controller Interface Scanner Control Panel Interface Accounting Remote Configuration Localization (Languages supported) Description/Specifications All printer parameter and processing defaults sets are available through Web PMT No printer UI provided.
  • Page 95: Appendix 6 - Abbreviations And Their Meanings

    Image Output Terminal inches per second IPX/SPX Internetwork Packet Exchange / Sequenced Packet Exchange (Novell NetWare Protocols) Line Printer Remote Line Printer Daemon XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction LPT1 Parallel Port 1 millimeters MSDL Microsoft Download Service Network Interface Card...
  • Page 96 This page has been intentionally left blank.
  • Page 97 This page has been intentionally left blank.
  • Page 98 XEROX , X2-TECH with RACER™, XES Synergix 8855 and 8855 Digital Solution, XES Synergix 8850 and 8850 Digital Solution, XES Synergix 8825 and 8825 Digital Solution, XES Synergix 8830 and 8830 Digital Solution, XES Synergix Scan System, the digital box icon, AccXES, and the acronym XES are trademarks of XEROX Corporation.
