Kramer RTBUS-28XL Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
RTBUS-28XL Round Table Connection Bus

Step 2: Get to know your RTBUS-28XL

# Feature
1 Pneumatic Mechanism
2 Outer Rim
3 Mounting Screws (x2)
4 Locking Butterfly Nuts (x2)
5 Mounting Butterfly Nuts (x2)
6 Mounting Brackets (x2)
7 Black Anodized or Brushed
Aluminum Semi-Automatic
Lid (with Opening for Cable
Pass-Through)
8 Lid Latch (x2)
9 Inner Pass-Through
Opening and Bushing (x1)
10 Pass-Through Opening and
Bushing (x3)
11 USB-C (PD) Charging Port
12 USB-A (QC 3.0) Charging
Port
13 5A MAX. Power Socket
RTBUS 28XL Quick Start
RTBUS-28XL Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/RTBUS-28XL
firmware upgrades are available.
Function
Enables automatic lifting and smooth
closing of the lid.
Fits over the table surface.
For securing RTBUS-28XL
Tighten to lock the mounting butterfly
screw.
Tighten to secure the unit to the table
surface.
For securing the unit to the table surface.
Covers the connecting surface, leaving
the table surface neat and tidy.
For safely closing the lid.
Insert a cable through the opening and the
bushing – for larger or multiple cables
(inner diameter approx. 12.5mm Ø).
Insert a cable through the opening and the
bushing (inner diameter approx. 10 mm
Ø).
Use to charge a device.
Use to charge a device.
Some laptops may require more than
30W power for charging. Additionally,
when connecting USB−A in parallel,
the USB−C port may not support
laptop charging.
Connect to a 90-240V AC power
consuming device.
When using an IL plug, it is required
to use straight configurations cable.
RTBUS-28XL for the first time.
to download the latest user manual and check if
User manual
to the table.
P/N: 2 9 0 0 - 3 0 1 6 9 8 QS
1 Quick start guide
Rev: 4
