For the latest information on our products and a list of Kramer distributors, visit our Web
site where updates to these cable installation instructions may be found.
We welcome your questions, comments, and feedback.
Web site:
www.kramerelectronics.com
E-mail:
info@kramerel.com
Contents
1
2
2.1
2.2
3
K R A ME R E LE CT R O N IC S L TD .
HDBT Installation
Cable Recommendations for
Usage and Termination Guidelines
P/N: 2900-300462 Rev 1
Guide
MODELS:
Kramer HDBT
1
2
2
2
3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kramer HDBT
Summary of Contents for Kramer HDBT
- Page 1 Cable Recommendations for Usage and Termination Guidelines For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to these cable installation instructions may be found. We welcome your questions, comments, and feedback.
- Page 2 To check our suggested cables listing, per product, go to http://www.kramerelectronics.com Kramer's BC-HDKat6a is an HDBaseT certified 4-pair U/FTP (unshielded around foiled twisted pair) cable designed as the ideal companion to Kramer's HDBaseT transmitter-receiver sets to provide optimum range and performance. It is constructed of 4 shielded twisted pairs (U/FTP) of 23AWG solid copper conductors that are cabled together in an unshielded outer jacket, and is optimized for installations of HDBaseT twisted pair digital transmitter−receiver sets.
- Page 3 Make sure that the drain wire is well soldered to the metal casing of the RJ-45 connectors on both cable ends Always use the recommended Kramer RJ-45 connector (CCR-RJ45-TP6) Keep the pairs twisted as close to the termination point as possible and make sure that the strain relief is pulled...
- Page 4 HDBaseT Twisted Pair Cable Termination This procedure describes how to terminate HDBT Twisted Pair cable. Tools You will need these tools at hand: a razor knife, wire cutters, a pair of pliers and a standard RJ-45 Crimp Tool. Step 1: Remove part of the purple jacket Remove approximately 2.5”...
- Page 5 Keep pressure on the top and bottom of the loader so the cables stay in place while sliding down. Step 6: Cut all conductors Using the wire cutters, cut all conductors leaving approximately 0.5” remaining. HDBT - HDBaseT Twisted Pair Cable Termination...
- Page 6 Solder the drain wire to the metal casing of the RJ-45 connector and cut off the excess using the wire cutters. Verify the continuity of the conductors and the shield using a cable tester. HDBT – HDBaseT Twisted Pair Cable Termination...
