Step 1: Check what's in the box
AVoIP Manager Collaboration Device
1 Power cords for US and EU
Step 2: Get to know your AVoIP Manager
#
Feature
1
3 x USB 3.0 Connectors
2
Power Button with LED
3
Power Connector
4
1 x HDMI OUT Connector
5
RJ-45 Connector
Step 3: Mount the AVoIP Manager
AVoIP MANAGER can be installed on a flat surface / wall, rear of a monitor or rack mount using the included
VESA mounting bracket and screw set:
Mount AVoIP MANAGER on the mounting bracket
Attach the mounting bracket to the AVoIP MANAGER with 2 screws.
This step is required for all the options detailed below.
AVoIP Manager Quick Start
AVoIP Manager Quick Start Guide
This guide helps you install and use your
Go to
http://www.kramerav.com/downloads/AVoIP Manager
if firmware upgrades are available.
AVoIP
Manager for the first time.
to download the latest user manual and check
1 VESA mounting bracket
1 VESA screw set
Function
Connect to USB local devices (for example, a USB camera, a
soundbar, microphone etc.).
Press to power ON or turn OFF the device.
Connect to the 12V DC power supply.
Connect to an HDMI sink.
HDMI OUT 2 is unavailable.
Connect to a LAN (default mode).
P/N:
2 9 0 0 - 3 0 1 8 4 1 QS
1 Quick start guide
Rev:
1
Advertisement
Related Manuals for Kramer AVoIP Manager
Summary of Contents for Kramer AVoIP Manager
- Page 1 Connect to a LAN (default mode). Step 3: Mount the AVoIP Manager AVoIP MANAGER can be installed on a flat surface / wall, rear of a monitor or rack mount using the included VESA mounting bracket and screw set: Mount AVoIP MANAGER on the mounting bracket Attach the mounting bracket to the AVoIP MANAGER with 2 screws.
- Page 2 Connect an HDMI display. Connect to the LAN (default mode). If you wish to use a Kramer active optical pluggable HDMI cable with your AVOIP MANAGER, contact your local Kramer office to assist in purchasing the correct cable. Step 5: Connect the power Connect the 12V DC power adapter to your AVOIP MANAGER and plug it into the mains electricity.
- Page 3 To login remotely: Browse to https://<IP>/agent (will be displayed after bootup is complete). Enter login credentials: User: kramer Pass: kramer Navigate to the Services page and verify that there are 15 services: 10 are running and 5 exited.
- Page 4 Make sure that the MAC ADDRESS fits the product sticker. Unplug the power supply and plug it back in. Verify the box automatically starts with a green indicator. For further details, refer to Refer to AVoIP Manager SW Box Installation Guide...
