Installation Instructions
MODELS:
Power Socket Installation
Power Cord Options
SAFETY WARNING
Disconnect the unit from the power supply before opening and servicing
For the latest information on our products and a list of Kramer distributors, visit our Web site where
updates to these installation instructions may be found.
We welcome your questions, comments, and feedback.
www.kramerAV.com
info@kramerel.com
for Inner Frame
for Modular TBUS
2900- 300061
P/N:
6
Rev:
Advertisement
Related Manuals for Kramer TBUS-1AXL
Summary of Contents for Kramer TBUS-1AXL
- Page 1 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to these installation instructions may be found. We welcome your questions, comments, and feedback.
- Page 2 Power Sockets for TBUS products Congratulations on purchasing your Kramer Table Connection Bus (TBUS-1AXL, TBUS-3XL, TBUS-4XL, TBUS-5XL, TBUS-6XL, TBUS-10XL, UTBUS-1XL and/or UTBUS-2XL). Some inner frame modules require single or dual power sockets. A choice of one or more power sockets per inner frame is available in several versions, including power sockets for the USA, the UK, Germany (the Europlug), Belgium-France, Italy, Switzerland, South Africa, Israel, Brazil and Australia.
- Page 3 Dual Power Socket Assemblies Dual Power Socket Assemblies: Power Specs Universal: TS-2U (80-001899) 100-240V AC, 50/60Hz, 5A Maximum 5A/2.5A per power outlet USA: TS-2US (80-001999) 100-240V AC, 50/60Hz, 5A Maximum 5A/2.5A per power outlet Belgium and France: TS-2FR (80-002299) 100-240V AC, 50/60Hz, 5A Maximum 5A/2.5A per power outlet Germany and EU: TS-2DE (80-002199)
- Page 4 Power Cord Options You can order any of the following power cords to use with a modular TBUS: Power Cord Type Description 6ft/110V (North America) C-AC/US (110V) 91-000099 6ft/125V (Japan) C-AC/JP (125V) 91-000699 6ft/220V (Europe) C-AC/EU (220V) 91-000199 6ft/220V (Israel) C-AC/IL (220V) 91-000999 6ft/250V (UK)
