- Page 1 User Manual DT3430 Barcodescanner – DT3430 0645733500 info@diwolar.nl https://www.dtronic.nl/ Datum : 22-1-2024 Versie : 1.0...
-
Page 2: Introduction
User manual ‘DT3430’ Introduction Thank you for trusting a product from DTRONIC. Please read the contents of the user manual carefully in order to use the products safely and effectively. You are advised to keep this manual correctly for your installation and as a reference. Please do not disassemble the product or tear off the seal, otherwise we will not provide warranty or replacement service. -
Page 3: Table Of Contents
User manual ‘DT3430’ Inhoud INTRODUCTION .......................... 2 1. PRODUCT ..........................5 Function ..........................5 Unbox ..........................5 Start ..........................5 Window ..........................5 Reading ..........................6 Picture ..........................6 Led indicator ........................6 2. SYSTEM SETUP ........................7 System Setup ........................7 2.1.1 Setup code ...................... - Page 4 User manual ‘DT3430’ 2.5.18 Code 39 Length Setting ..................21 2.5.19 Code 32 settings ....................21 2.5.20 Code 128 settings ....................22 2.5.21 Code 93 settings ....................22 2.5.22 Codabar Settings ....................23 2.5.23 Codablock A ......................23 2.5.24 Codablock F ......................23 2.5.25 GS1 Databar Limited .....................
-
Page 5: Product
- Basically the scanner scans the 95% of bar codes, remaining 5% can be set as desired with this manual. - There are patented parts in the scanner, DTRONIC has the rights to sell these items on the Dutch, Belgian and German market 1.2 Unbox... -
Page 6: Reading
User manual ‘DT3430’ 1.5 Reading If the bar code is small, it should be closer to the scan window; if the bar code is large, it should be further away from the scan window for easier reading. If the bar code is highly reflective (for example, the coated surface), you may need to tilt the bar code at an angle to scan the bar code. -
Page 7: System Setup
User manual ‘DT3430’ 2. System Setup 2.1 System Setup Option and function setting mainly by reading a series of special bar codes. In this chapter, we give you a detailed introduction to the options and functions available for user setup and the corresponding setup code. -
Page 8: Pairing Bluetooth
User manual ‘DT3430’ 2.2 Pairing bluetooth Press the button on the scanner, the scanner turns on and a green light appears. Connect the USB connector to the computer or laptop, wait a few moments for the computer to find and actually see it. -
Page 9: Bluetooth Name
User manual ‘DT3430’ 2.2.1 Bluetooth name First scan the "Bluetooth name setting" and then scan another barcode that becomes the Bluetooth name of this scanner. NOTE: The longest Bluetooth name can be 16 bytes. If the Bluetooth barcode is more than 16 bytes, the Bluetooth takes only the first 16 bytes as the Bluetooth name. -
Page 10: Led
User manual ‘DT3430’ 2.2.2 Led Enable Aimer Disable Aimer Enable Illumination Disable Illumination Always off Always on Blink test mode Disable blink test mode 2.2.3 Level lighting Datum : jan-2024 pagina 10 van 43 Versie : 1.0... -
Page 11: Beeper Settings
User manual ‘DT3430’ 2.2.4 Be 2.2.5 Beeper settings Volume set to High (50%) (default) Volume set to midrange (25%) Volume set to bass (12.5%) 2.2.6 Set the beep switch Open (default) Close 2.2.7 Power on beep switch Open (default) Close 2.3 Reading mode settings... -
Page 12: Auto Scan Mode
User manual ‘DT3430’ Continuous mode (default) 2.3.2 Auto Scan mode Auto scan Delay 50ms Delay 100ms Delay 300ms 2.3.3 Code reading timeout 30sec 300sec 2400sec Datum : jan-2024 pagina 12 van 43 Versie : 1.0... -
Page 13: Communication Settings
User manual ‘DT3430’ 2.4 Communication settings 2.4.1 Communication settings USB HID (default) USB serial port RS-232 serial port USB CDC Enable virtual keyboard Disable virtual keyboard 2.4.2 USB keyboard Portuguese (Brazil) cannot output "?" and "/" . Nederlands Italian Datum : jan-2024 pagina 13 van 43 Versie : 1.0... - Page 14 User manual ‘DT3430’ Spanish (Brazil) Portuguese Portuguese (Brazil) French German (Austria) Turkish Q Turkish F English (UK) Japanese German (Switzerland) French (Belgium) America Datum : jan-2024 pagina 14 van 43 Versie : 1.0...
-
Page 15: Symbologies
User manual ‘DT3430’ 2.5 Symbologies Each type of barcode has its own unique properties, and the setup codes in this chapter allow you to adjust the scanner to accommodate these property changes. The fewer barcode types that are turned on, the faster the scanner will Scan. You can turn off the barcode types that will not be used to improve the performance of the scanner. -
Page 16: Data Matrix Mirror Code
User manual ‘DT3430’ 2.5.5 Data matrix mirror code Enable Disable 2.5.6 Mirror Code for all symbologies Enable Disable 2.5.7 All barcodes Close all barcodes Turn on all barcodes 2.5.8 EAN8 Settings EAN8 on (default) EAN8 off Enable EAN8 transmission Check Character... -
Page 17: Code 11 Settings
User manual ‘DT3430’ Convert EAN8 to EAN13 Do not Convert EAN8 to EAN13 (default) 2.5.9 Code 11 Settings Enable Disable 1 check bit 2 check bits Transmit check bit Not transmit check bit 2.5.10 Add-on code setting Adaptive UPC/EAN add-on codes... -
Page 18: Ean 13 Settings
User manual ‘DT3430’ 2.5.11 EAN 13 settings EAN13 on (default) EAN13 off Enable EAN13 transmission Check Character Disable EAN13 transmission checks (default) Transmit EAN13 System Character (default) Do not Transmit EAN13 System Character 2.5.12 HANXIN Enable Disable 2.5.13 UPC-A settings... -
Page 19: Upc-E Settings
User manual ‘DT3430’ Enable Disable 2.5.14 UPC-E settings UPC-E on (default) UPC-E Off Do no Transmit UPC-E transmission Check Transmit UPC-E Check Character (default) Character Convert UPC-E to UPC-A Do not Convert UPC-E to UPC-A (default) Extended to 12 bits Disable to 12 bits 2.5.15 UPCE... -
Page 20: Ean/Upc
User manual ‘DT3430’ 2.5.16 EAN/UPC Enable Disable Normal and inverse Normal baroce 2.5.17 Code 39 Settings Code 39 on (default) Code 39 Off Enable Code 39 Check Character Disable Code 39 Check Character (default) Do not Transmit Code 39 Check Character... -
Page 21: Code 39 Length Setting
User manual ‘DT3430’ Full ASCII On Full ASCII Off (default) Normal and inverse Normal 2.5.18 Code 39 Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. -
Page 22: Code 128 Settings
User manual ‘DT3430’ 2.5.20 Code 128 settings Code 128 on (default) Code 128 Off Normal baroce Normal and inverse Transmit Code 128 Check Character Do not Transmit Code 128 Check Character (default) 2.5.21 Code 93 settings Code 93 On (default) -
Page 23: Codabar Settings
User manual ‘DT3430’ 2.5.22 Codabar Settings Codabar on (default) Codabar Off Transmit Codabar start and stop characters Do not Transmit Codabar start and stop characters (default) Not check Enable check transmit check bit Normal barcode Normal and inverse 2.5.23 Codablock A... -
Page 24: Gs1 Databar Limited
User manual ‘DT3430’ 2.5.25 GS1 Databar Limited Enable Disable 2.5.26 GS1 Databar omnidirectional Enable Disable 2.5.27 GS1 Databar Expanded Enable Disable 2.5.28 DOT_CODE Enable Disable 2.5.29 Composite Enable Disable Datum : jan-2024 pagina 24 van 43 Versie : 1.0... -
Page 25: Data Matrix Code
User manual ‘DT3430’ 2.5.30 Data matrix Code Enable Disable Enable Inverse DM Disable Inverse DM 2 of 5 enable 2 of 5 disable Matrix 2 of 5 check bit enable Matrix 2 of 5 check bit disable 2.5.31 MSI Enable... -
Page 26: Micro Qr Code
User manual ‘DT3430’ 2.5.32 QR Enable Disable Enable inverse QR Disable inverse QR Enable QR code URL link Disable QR code URL link 2.5.33 Micro QR code Enable Disable Inverse micro QR Disable inverse micro QR Datum : jan-2024 pagina 26 van 43... -
Page 27: Pdf417
User manual ‘DT3430’ 2.5.34 PDF417 Enable Disable Normal baroce Normal and inverse 2.5.35 Micro PDF417 Enable Disable 2.5.36 Pharmacode Enable Disable 2.5.37 RSS-Expanded Enable Disable Datum : jan-2024 pagina 27 van 43 Versie : 1.0... -
Page 28: Rss-Limited
User manual ‘DT3430’ 2.5.38 RSS-Limited Enable Disable 2.5.39 RSS-14 Enable Disable 2.5.40 Trioptic Code Enable Disable 2.5.41 Telepen Enable Disable Datum : jan-2024 pagina 28 van 43 Versie : 1.0... -
Page 29: Straight 2 Of 5 Industrial
User manual ‘DT3430’ 2.5.42 Straight 2 of 5 Industrial Enable Disable 2.5.43 Maxicode Enable Disable 2.5.44 Interleave 2 of 5 (ITF5) setting ITF5 on (default) ITF5 off Enable ITF25 check character (default) Disable ITF25 Check Character Transmit ITF25 Check Character... -
Page 30: Airline 2 Of 5
User manual ‘DT3430’ 2.5.45 Airline 2 of 5 Enable Disable 2.5.46 Aztec code Enable Disable Enable inverse Aztec Disable inverse Aztec Datum : jan-2024 pagina 30 van 43 Versie : 1.0... -
Page 31: Appendix
User manual ‘DT3430’ 3. Appendix 3.1.1 Control Character table ASCII Programming Barcode NULL Home Ctrl+A Alt+001 Ctrl+B Ctrl+B Alt+002 Lock Right Ctrl+C Up Arrow Ctrl+C Alt+003 Arrow Down Ctrl+D Alt+004 Arrow Arrow Left Ctrl+E Alt+005 NULL Arrow Right Ctrl+F Alt+006... - Page 32 User manual ‘DT3430’ Down Enter Enter Ctrl+P Alt+010 Arrow NULL NULL Ctrl+Q Alt+011 NULL NULL Ctrl+R Alt+012 delete Enter Enter Enter Alt+013 Enter Page Up Ctrl+N Alt+014 Insert Page Ctrl+O Alt+015 Down Ctrl+P Alt+016 NULL Ctrl+Q Alt+017 Home Print NULL...
- Page 33 User manual ‘DT3430’ Ctrl+U Alt+021 Ctrl+V Alt+022 Ctrl+W Alt+023 Ctrl+X Alt+024 Ctrl+Y Alt+025 NULL Ctrl+Z Alt+026 Ctrl+[ Alt+027 ALT+028 Ctrl+\ Alt+028 ALT+029 Ctrl+] Alt+029 NULL Ctrl+^ Alt+030 NULL Ctrl+_ Alt+031 Datum : jan-2024 pagina 33 van 43 Versie : 1.0...
-
Page 34: Visible Characters
User manual ‘DT3430’ 3.1.2 Visible Characters Deci ASCII Programming Barcode Data Space " & Datum : jan-2024 pagina 34 van 43 Versie : 1.0... - Page 35 User manual ‘DT3430’ Datum : jan-2024 pagina 35 van 43 Versie : 1.0...
- Page 36 User manual ‘DT3430’ < > Datum : jan-2024 pagina 36 van 43 Versie : 1.0...
- Page 37 User manual ‘DT3430’ Datum : jan-2024 pagina 37 van 43 Versie : 1.0...
- Page 38 User manual ‘DT3430’ Datum : jan-2024 pagina 38 van 43 Versie : 1.0...
- Page 39 User manual ‘DT3430’ Datum : jan-2024 pagina 39 van 43 Versie : 1.0...
- Page 40 User manual ‘DT3430’ Datum : jan-2024 pagina 40 van 43 Versie : 1.0...
- Page 41 User manual ‘DT3430’ Datum : jan-2024 pagina 41 van 43 Versie : 1.0...
- Page 42 User manual ‘DT3430’ Ç Datum : jan-2024 pagina 42 van 43 Versie : 1.0...
-
Page 43: Datum : Jan-2024 Pagina 3 Van
User manual ‘DT3430’ ç Datum : jan-2024 pagina 43 van 43 Versie : 1.0...
