- Page 1 User Manual DT3108 Barcodescanner – DT3108 0645733500 info@diwolar.nl https://www.dtronic.nl/ Datum : 27-1-2024 Versie : 1.0...
-
Page 2: Introduction
User manual ‘DT3108’ Introduction Thank you for trusting a product from DTRONIC. Please read the contents of the user manual carefully in order to use the products safely and effectively. You are advised to keep this manual correctly for your installation and as a reference. Please do not disassemble the product or tear off the seal, otherwise we will not provide warranty or replacement service. -
Page 3: Table Of Contents
User manual ‘DT3108’ Inhoud INTRODUCTION .......................... 2 1. PRODUCT ..........................6 Function ..........................6 Unbox ..........................6 Start ..........................6 Window ..........................6 Reading ..........................7 Picture ..........................7 Led indicator ........................7 2. SYSTEM SETUP ........................8 System Setup ........................8 2.1.1 Setup code ...................... - Page 4 User manual ‘DT3108’ 2.4.8 Terminator settings ....................19 2.4.9 CTRL + X ........................ 20 2.4.10 Case output settings ..................... 21 2.4.11 Data output settings ........Fout! Bladwijzer niet gedefinieerd. 2.4.12 Pre/Post data length setting......Fout! Bladwijzer niet gedefinieerd. Symbologies ........................22 2.5.1 1D all symbologies ....................
- Page 5 User manual ‘DT3108’ 2.5.46 Telepen ............Fout! Bladwijzer niet gedefinieerd. 2.5.47 Straight 2 of 5 Industrial ..................34 2.5.48 Maxicode ............Fout! Bladwijzer niet gedefinieerd. 2.5.49 Interleave 2 of 5 (ITF5) setting ................35 2.5.50 Extra code setting ..........Fout! Bladwijzer niet gedefinieerd.
-
Page 6: Product
- Basically the scanner scans the 95% of bar codes, remaining 5% can be set as desired with this manual. - There are patented parts in the scanner, DTRONIC has the rights to sell these items on the Dutch, Belgian and German market 1.2 Unbox... -
Page 7: Reading
User manual ‘DT3108’ 1.5 Reading If the bar code is small, it should be closer to the scan window; if the bar code is large, it should be further away from the scan window for easier reading. If the bar code is highly reflective (for example, the coated surface), you may need to tilt the bar code at an angle to scan the bar code. -
Page 8: System Setup
User manual ‘DT3108’ 2. System Setup 2.1 System Setup Option and function setting mainly by reading a series of special bar codes. In this chapter, we give you a detailed introduction to the options and functions available for user setup and the corresponding setup code. -
Page 9: Led
User manual ‘DT3108’ 2.1.4 Led Always off Always on Blink test mode Disable blink test mode 2.1.5 Beeper Duration Short Normal 2.7Khz Mute 2.1.6 Beeper settings Volume set to High (50%) (default) Volume set to midrange (25%) Volume set to bass (12.5%) -
Page 10: Set The Beep Switch
User manual ‘DT3108’ 2.1.7 Set the beep switch Open (default) Close 2.1.8 Power on beep switch Open (default) Close 2.1.9 Read success beep switch Open (default) Close 2.2 Reading mode settings 2.2.1 Continuous mode (default) When the reading setting code is switched to this mode, it enters the continuous reading state. In this mode, the "repeat read switch"... -
Page 11: Auto Scan Mode
User manual ‘DT3108’ 2.2.2 Auto Scan mode Auto scan Delay 50ms Delay 100ms Delay 300ms Datum : feb-2024 pagina 11 van 47 Versie : 1.0... -
Page 12: Communication Settings
User manual ‘DT3108’ 2.3 Communication settings 2.3.1 Communication settings USB HID (default) USB serial port RS-232 serial port USB CDC Enable virtual keyboard Disable virtual keyboard 2.3.2 USB keyboard Portuguese (Brazil) cannot output "?" and "/" . Nederlands Italian Spanish (Brazil) -
Page 13: Usb Keyboard Sending Speed
User manual ‘DT3108’ Portuguese (Brazil) French German (Austria) Turkish Q Turkish F English (UK) Japanese German (Switzerland) French (Belgium) America 2.3.3 USB keyboard sending speed If there is missed data at the receiver side, the occurrence speed should be turned down, which is easy to occur at the receiver side with poor performance. -
Page 14: Set Usb Keyboard Sending Speed
User manual ‘DT3108’ 20 ms 2.3.4 Set USB keyboard sending speed USB keyboard send speed, unit is milliseconds (ms). The default value is 5ms, the settable time range: 0ms~200ms. Set USB keyboard sending speed Setting the USB keyboard to send speed of 50ms can be set by reading the following barcodes in order. -
Page 15: Serial Port Baud Rate Setting
User manual ‘DT3108’ 2.3.6 Serial port baud rate setting Baud rate 4800 Baud rate 9600 (default) Baud rate 19200 Baud rate 38400 Baud rate 57600 Baud rate 115200 2.3.7 Serial port parity bit setting No checksum (default) Odd calibration Even Check... -
Page 16: Custom Prefix On/Off Settings
User manual ‘DT3108’ 2.3.8 Custom prefix on/off settings Custom prefixes add a user-defined string before the decoded information. For example, if you allow to add a custom prefix and set the prefix to the string "AB", after reading the barcode with the data "123", the scanner adds the string "AB"... -
Page 17: Custom Suffix On/Off Settings
User manual ‘DT3108’ 2.3.10 Custom suffix on/off settings The custom suffix adds a user-defined string after the decoded information. For example, it is allowed to add a custom suffix and set the suffix to the string "AB", after reading the barcode with the data of "123", the scanner adds the string "AB"... -
Page 18: Customize Code Id
User manual ‘DT3108’ Close Code ID (default): Code ID is not spliced to the read string. Code ID prefix: The Code ID is spliced before the recognition string. Code ID suffix: The Code ID is spliced after the recognition string. -
Page 19: Terminator Settings
User manual ‘DT3108’ 2.3.14 Terminator settings The terminator suffix is used to mark the end of a complete piece of data information. The terminator suffix stands alone and does not participate in any other form of data formatting. The terminator suffix must be the last piece of data sent, and no additional data will be added thereafter. -
Page 20: Ctrl + X
User manual ‘DT3108’ 2.3.15 CTRL + X Non- printable Keyboard Control + ASCII ( CTRL+ X) Mode ASCII control characters Windows Mode Control + X Control + X Mode Off Mode On CTRL + X Char CTRL + X function... -
Page 21: Case Output Settings
User manual ‘DT3108’ CTRL+ T CTRL+ U CTRL+ V Paste CTRL+ W CTRL+ X CTRL+ Y CTRL+ Z CTRL+ [ CTRL+ \ CTRL+ ] CTRL+ ^ CTRL+ - NP Enter 2.3.16 Case output settings Case conversion for characters in a string, prefix and suffix have no effect. -
Page 22: Symbologies
User manual ‘DT3108’ 2.4 Symbologies Each type of barcode has its own unique properties, and the setup codes in this chapter allow you to adjust the scanner to accommodate these property changes. The fewer barcode types that are turned on, the faster the scanner will Scan. You can turn off the barcode types that will not be used to improve the performance of the scanner. -
Page 23: Mirror Code For All Symbologies
User manual ‘DT3108’ 2.4.5 Mirror Code for all symbologies Enable Disable 2.4.6 All barcodes Close all barcodes Turn on all barcodes 2.4.7 EAN8 Settings EAN8 on (default) EAN8 off Convert EAN8 to EAN13 Do not Convert EAN8 to EAN13 (default) 2.4.8 Code 11 Settings... -
Page 24: Add-On Code Setting
User manual ‘DT3108’ 1 check bit 2 check bits Transmit check bit Not transmit check bit 2.4.9 Add-on code setting Adaptive UPC/EAN add-on codes Only Decode UPC/EAN Add-on codes Ignore UPC/EAN add-on codes (default) 2.4.10 EAN 13 settings EAN13 on (default) -
Page 25: Issn Settings
User manual ‘DT3108’ 2.4.11 ISSN 2.4.12 ISSN Settings Convert EAN-13 to ISSN Do not Convert EAN-13 to ISSN (default) 2.4.13 ISBN setting Convert EAN13 to ISBN Do not Convert EAN13 to ISBN (default) 2.4.14 UPC-A settings Transmit UPC-A check character (default) -
Page 26: Upc-E Settings
User manual ‘DT3108’ Output digital Not output digital 2.4.15 UPC-E settings UPC-E on (default) UPC-E Off Do no Transmit UPC-E transmission Check Transmit UPC-E Check Character (default) Character Convert UPC-E to UPC-A Do not Convert UPC-E to UPC-A (default) 2.4.16 UPCE... -
Page 27: Ean/Upc
User manual ‘DT3108’ 2.4.17 EAN/UPC Enable Disable 2.4.18 Code 39 Settings Code 39 on (default) Code 39 Off Enable Code 39 Check Character Disable Code 39 Check Character (default) Do not Transmit Code 39 Check Character Transmit Code 39 Check Character... -
Page 28: Code 39 Length Setting
User manual ‘DT3108’ 2.4.19 Code 39 Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. -
Page 29: Code 128 Length Setting
User manual ‘DT3108’ 2.4.22 Code 128 length setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. -
Page 30: Codabar Settings
User manual ‘DT3108’ Minimum length setting Maximum length setting Example Set the scanner to Scan only barcodes with a minimum of 8 bytes and a maximum of 12 bytes. 1. Scan "Startup Settings" 2. Scan "Minimum length setting" 3. Scan Digital Code "8" (see Appendix 1 for data and edit barcode) 4. -
Page 31: Codabar Length Setting
User manual ‘DT3108’ 2.4.26 Codabar Length Setting OPMERKING: If the maximum length is less than the minimum length, only the barcode of these two lengths will be Scan. If the maximum length is equal to the minimum length, only this length is supported. -
Page 32: Gs1 Databar Expanded
User manual ‘DT3108’ 2.4.29 GS1 Databar Expanded Enable Disable 2.4.30 Data matrix Code Enable Disable 2 of 5 enable 2 of 5 disable 2.4.31 MSI Enable Disable Datum : feb-2024 pagina 32 van 47 Versie : 1.0... -
Page 33: Micro Qr Code
User manual ‘DT3108’ 2.4.32 QR Enable Disable Enable QR code URL link Disable QR code URL link 2.4.33 Micro QR code Enable Disable 2.4.34 PDF417 Enable Disable 2.4.35 Micro PDF417 Enable Disable Datum : feb-2024 pagina 33 van 47 Versie : 1.0... -
Page 34: Rss-Expanded
User manual ‘DT3108’ 2.4.36 RSS-Expanded Enable Disable 2.4.37 RSS-Limited Enable Disable 2.4.38 RSS-14 Enable Disable 2.4.39 Straight 2 of 5 Industrial Enable Disable Datum : feb-2024 pagina 34 van 47 Versie : 1.0... - Page 35 User manual ‘DT3108’ 2.4.40 Interleave 2 of 5 (ITF5) setting ITF5 on (default) ITF5 off Enable ITF25 check character (default) Disable ITF25 Check Character Transmit ITF25 Check Character Do not Transmit ITF25 Check Charcter (default) 2.4.41 Aztec code Enable Disable 2.4.42 ITF25 length setting...
- Page 36 User manual ‘DT3108’ Example Set the scanner to Scan only barcodes with a minimum of 8 bytes and a maximum of 12 bytes. 1. Scan "Startup Settings" barcode 2. Scan "Minimum length setting" barcode 3. Scan Digital Code "8" (see Appendix 1 for data and edit barcode) 4.
- Page 37 User manual ‘DT3108’ 3. Appendix 3.1.1 Symbolgies ID Set Symbologies CODE ID(default) All Symbologies Codabar Code128 Code32 < Code93 Code39 Code11 EAN-13 EAN-8 GS1 DataBar GS1 DataBar Limited GS1 DataBar Expanded GS1-128 (EAN-128) 2 of 5 Interleaved 2 of 5...
- Page 38 User manual ‘DT3108’ QR Code Micro QR Code 3.1.2 ASCII Tabel <SPACE> “ & ‘ Datum : feb-2024 pagina 38 van 47 Versie : 1.0...
- Page 39 User manual ‘DT3108’ < > 3.1.3 Function Key Mapping Key（When Disable Control Key（When Enable Control Character ） Character） Save Ctrl+@ Insert Ctrl+A Home Ctrl+B Ctrl+C Delete Ctrl+D PageUp Ctrl+E PageDown Ctrl+F Ctrl+G Backspace Backspace Datum : feb-2024 pagina 39 van 47...
- Page 40 User manual ‘DT3108’ Enter Ctrl+J Caps Lock Ctrl+K Print Screen Ctrl+L Enter Enter Scroll Lock Ctrl+N Pause/Break Ctrl+O Ctrl+P ↑ Ctrl+Q ↓ Ctrl+R ← Ctrl+S → Ctrl+T Ctrl+U Ctrl+V Ctrl+W Ctrl+X Ctrl+Y Ctrl+Z Ctrl+\ Ctrl+] Datum : feb-2024 pagina 40 van 47...
- Page 41 User manual ‘DT3108’ Ctrl+^ Ctrl+_ 3.1.4 Control Character Set Datum : feb-2024 pagina 41 van 47 Versie : 1.0...
- Page 42 User manual ‘DT3108’ Datum : feb-2024 pagina 42 van 47 Versie : 1.0...
- Page 43 User manual ‘DT3108’ 3.1.5 Examples The maximum length for every prefix or suffix is 10 digits, setting up by scanning parameter barcodes. (Please enable Custom prefix/Suffix by scanning parameter barcodes) Example 1.1： Set up Custom prefix”XYZ” for all symbologies According to the Barcode Type ID, “99” is the Hex valule for all symbologies;...
- Page 44 User manual ‘DT3108’ Set Length Range for barcode Example 2.1：Set Length Range for Code128 as 4 - 12 digits 1. Scan Parameter Barcode Set Minimum Length for Code 128， 2. Scan parameter barcode 4 in the appendix Data and Digital Barcodes, 3.
- Page 45 User manual ‘DT3108’ 3.1.6 Data Digit code Datum : feb-2024 pagina 45 van 47 Versie : 1.0...
- Page 46 User manual ‘DT3108’ Datum : feb-2024 pagina 46 van 47 Versie : 1.0...
-
Page 47: Datum : Feb-2024 Pagina 3 Van
User manual ‘DT3108’ Cancel All Digits Cancel Current Configuration Cancel Last Digit Save Datum : feb-2024 pagina 47 van 47 Versie : 1.0...
