2. Introduction
Description
The STRIKE Array 4C is an IP65-rated audience blinder with four independently focusable pods. Intense
RGBA-WW LED output delivers a full range of color as well as a wide choice of white color temperatures
with exceptional color rendering. Industry leading low end dimming performance includes Red Shift which
warms the color temperature of the output as it dims to emulate a classic tungsten look. Variable PWM and
high CRI make the product ideal for broadcast applications. A proprietary Tool-Free interlocking system
enables the STRIKE Array 4C to be interconnected easily with other STRIKE Array-series products for
scalable configurations. Omega-Bracket locks installed on both the yoke and the rear of the product
streamline the truss mounting process.
Features
•
Intense 4 pod color blinder/strobe rated IP65 for all-weather use
•
Full range of color and excellent rendition of any color temperature of white
•
Emulated "red shift" to mimic incandescent fixtures perfectly
•
Individual pan (or tilt depending on mount orientation) of each head to allow for directional
adjustment of light output
•
Innovative interlocking system to connect multiple Strike Array family fixtures together
•
Multiple mounting locations and re-positionable yoke with ¼ turn adapters for creative and
convenient rigging options
•
Independent pod control and strobe functionality for high-impact effects on the fly
Product Overview
1
4
6
4
2
# Name
1 Display
2 Menu buttons
3
3 Condensation valve
4 Power in
5 USB-C port
6 Ethernet ports
7 DMX in/out
5
7
STRIKE Array 4C User Manual Rev. 1
