Starting Address

Each product will respond to a unique starting address from the controller. All products with the same
starting address will respond in unison. To set the starting address in DMX mode:
1. Go to the DMX Address main level.
2. Select the starting address (001–512).
Highest
Personality
Address
1Ch 512
3Ch 510
5Ch 508
7Ch 506
10Ch 503

Ethernet Settings

The Ethernet Settings control the universe, start address (Art-Net™ or sACN), IP address, and ethernet
conversion functions of the product.

IP Mode

It is possible to set the IP address of the STRIKE Array 4C manually, by the network, or to a preset static
address specific to each product. To set the IP mode, follow the instructions below:
1. Go to the Ethernet Setting main level.
2. Select the IP Mode option.
3. Select the desired IP mode, from Manual (set the IP address with the control panel), DHCP (the
network sets the IP address), or Static (a preset address specific to each product).

Universe

To assign an Art-Net™ or sACN universe to the STRIKE Array 4C:
1. Go to the Ethernet Setting main level.
2. Select the Universe option.
3. Set the universe, from 000–255 (for Art-Net™) or from 001–256 (for sACN).

Start Channel

Each product will respond to a unique starting address from the controller. All products with the same
starting address will respond in unison. To set the starting address in Art-Net™ or sACN mode:
1. Go to the Ethernet Setting main level.
2. Select the Start Channel option.
3. Select the starting address (001–512)
• See the Starting Address
personality.
• Make sure that the starting addresses on the various products do not overlap due to the new
personality setting.

IP Address

To set the IP address:
1. Go to the Ethernet Setting main level.
2. Select the IP Address option.
3. Set the first value of the IP address from 000–255.
4. Press <ENTER> to cycle through the 4 values of the IP address.
5. Set the other 3 values from 000–255.
6. Press <MENU> to exit when the IP address is set as desired.

Ethernet to DMX

When Ethernet to DMX is active, the selected universe of the Art-Net™ or sACN signal will be converted to
DMX and output through the 5-pin DMX out port.
1. Go to the Ethernet Setting main level.
2. Select the Ethernet To DMX option.
3. Select from No (do not convert) or Yes (convert).
16
Products per
Personality
Universe
512 12Ch
170 13Ch
102 16Ch
73 22Ch
51 HSV
section for the highest selectable starting address for each
Operation
Highest Products per
Address
501
500
497
491
510
STRIKE Array 4C User Manual Rev. 1
Universe
42
39
32
23
170
