Summary of Contents for Chauvet Professional Rogue Outcast 1 Hybrid

  • Page 1 USER MANUAL...
  • Page 2 Rogue Outcast 1 Hybrid. Trademarks CHAUVET, the Chauvet logo, and Rogue Outcast 1 Hybrid are registered trademarks or trademarks of Chauvet & Sons, LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries.

  • Page 3: Table Of Contents

    20CH ..........................Color Wheel ....................23 Gobo Wheel ....................24 Configuration (Standalone) ................25 Run Mode........................Setup..........................Reset Function ....................... Factory Reset Function ....................System Information ..................27 Rogue Outcast 1 Hybrid User Manual Rev. 2 TOC 1 of 2...
  • Page 4 Focus ..........................Frost ..........................Mac 4 ..........................Mac 5 ..........................Mac 6 ..........................5. Technical Information ..............Product Maintenance ..................29 6. Technical Specifications ............Returns.................... Contact Us ..................TOC 2 of 2 Rogue Outcast 1 Hybrid User Manual Rev. 2...

  • Page 5: Before You Begin

    40,000 to 50,000 hours. If extending this lifespan is vital, lower the operating temperature by improving the ventilation around the product, thus reducing the ambient temperature. In addition, limiting the overall projection intensity may extend the LEDs’ lifespan. Rogue Outcast 1 Hybrid User Manual Rev. 2 Page 3 of 32...

  • Page 6: Safety Notes

    The maximum ambient temperature is 113 °F (45 °C). Do not operate the product at higher temperatures. • In the event of a serious operation problem, stop using this product immediately! If your Chauvet product requires service, contact Chauvet Technical Support. Page 4 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...

  • Page 7: Introduction

    2. Introduction Description The Rogue Outcast 1 Hybrid is an outdoor-ready, IP65 spot/beam/wash moving head ideal for small to medium festivals and events. Powered by an intense 400W lamp, Rogue Outcast 1 Hybrid delivers a 6500K output with tight beam angles of 1° to 5° in Beam Mode and a zoom range of 4° to 24° in Spot Mode and 9°...

  • Page 8: Product Dimensions

    4.6 in 117 mm 19.88 in 505 mm 4.50 in 114 mm 14.66 in 372 mm 18.6 in 471 mm 11 in 280 mm 25.6 in 649 mm Page 6 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...

  • Page 9: Setup

    Always replace the blown fuse with another of the same type and rating. DMX Linking The Rogue Outcast 1 Hybrid can be linked to a DMX controller using a 5-pin DMX connection. If using other DMX-compatible products with this product, each can be controlled individually with a single DMX controller.

  • Page 10: Mounting

    Only loosen or tighten the bracket knobs manually. Using tools could damage the knobs. Procedure The Rogue Outcast 1 Hybrid comes with a double-bracketed yoke to which you can either attach mounting clamps for hanging or simply use as a floor stand. You must supply the mounting clamps. Make sure the clamps are capable of supporting the weight of this product.

  • Page 11: Lamp Replacement

    ETUP Lamp Replacement The Rogue Outcast 1 Hybrid is equipped with an USHIO NSL 400-W lamp. Follow the procedure below to safely change the lamp, Disconnect the product from power before opening. Procedure Turn the product off and disconnect it from power. Wait at least 15 minutes for the lamp to cool down.

  • Page 12: Operation

    1. Starting from the Main Level screen, select Address, press <ENTER>. 2. Select the starting address (001–512), press <ENTER>. The highest recommended starting address for each DMX mode is as follows: Personality Address 20CH 25CH Page 10 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...

  • Page 13: Menu Map

    PERATION Menu Map Refer to the Rogue Outcast 1 Hybrid product page on www.chauvetprofessional.com for the latest menu map. Main Level Programming Levels Description Address 001–512 Sets the DMX starting address 20CH Selects the DMX mode 25CH Auto Test Runs the product’s test sequence...
  • Page 14 Leaves lamp time unchanged Reset Lamp Time Resets lamp timer to 0 Defines amount of hours between Interval 10–250 maintenance Maintenance Timer Remain Shows remaining time in maintenance 10–250 Time cycle Page 12 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...
  • Page 15 Shows fan speed Fan 1–5 _ _ _ Shows speed of fans 1–5 _ _ _ _ _ _ _ _ _ _ _ _ _ Shows UID information Rogue Outcast 1 Hybrid User Manual Rev. 2 Page 13 of 32...

  • Page 16: Dmx Values

    052  059 UV 060  187 Split colors 188  219 Clockwise color scroll, fast to slow 220  223 Stop 224  255 Counterclockwise color scroll, slow to fast Page 14 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...
  • Page 17 108  111 Gobo 13 shake, from slow to fast 112  127 Open 128  189 Clockwise gobo scroll, fast to slow 190  193 Stop 194  255 Counterclockwise gobo scroll, slow to fast Rogue Outcast 1 Hybrid User Manual Rev. 2 Page 15 of 32...
  • Page 18 190  193 Stop 194  255 Counter-clockwise rotation, slow to fast Frost 000  255 0–100% 000  007 No function Beam defraction 008  255 Frost effect Page 16 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...
  • Page 19 224  231 Effect 28 232  239 Effect 29 240  247 Effect 30 248  255 Effect 31 Movement macro speed 000  255 Fast to slow Rogue Outcast 1 Hybrid User Manual Rev. 2 Page 17 of 32...
  • Page 20 220  229 Disable blackout all function during pan/tilt 230  239 Lamp off 240  249 Pan/tilt smooth mode on 250  255 Pan/tilt smooth mode off Page 18 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...

  • Page 21: 20Ch

    052  059 UV 060  187 Split colors 188  219 Clockwise color scroll, fast to slow 220  223 Stop 224  255 Counterclockwise color scroll, slow to fast Rogue Outcast 1 Hybrid User Manual Rev. 2 Page 19 of 32...
  • Page 22 108  111 Gobo 13 shake, from slow to fast 112  127 Open 128  189 Clockwise gobo scroll, fast to slow 190  193 Stop 194  255 Counterclockwise gobo scroll, slow to fast Page 20 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...
  • Page 23 190  193 Stop 194  255 Counter-clockwise rotation, slow to fast Frost 000  255 0–100% 000  007 No function Beam defraction 008  255 Frost effect Rogue Outcast 1 Hybrid User Manual Rev. 2 Page 21 of 32...
  • Page 24 220  229 Disable blackout all function during pan/tilt 230  239 Lamp off 240  249 Pan/tilt smooth mode on 250  255 Pan/tilt smooth mode off Page 22 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...

  • Page 25: Color Wheel

    PERATION Color Wheel The Rogue Outcast 1 Hybrid includes one color wheel with 13 fixed colors plus open (white), as indicated below. The diagram shows the color on the wheel, as mentioned in the DMX Values tables. ORANGE CTO 6500K...

  • Page 26: Gobo Wheel

    PERATION Gobo Wheel The Rogue Outcast 1 Hybrid includes one static gobo wheel with 13 fixed gobos plus open, and one rotating gobo wheel with 9 gobos. The diagram shows the gobo number on the wheel as numbered in the DMX Values tables.

  • Page 27: Configuration (Standalone)

    Highlight BL.O.Color Move, press <ENTER>. Select YES or NO, press <ENTER>. BL.O. Gobo Move Enables/disables blackout on gobo wheel move. Highlight BL.O.Gobo Move, press <ENTER>. Select YES or NO, press <ENTER>. Rogue Outcast 1 Hybrid User Manual Rev. 2 Page 25 of 32...
  • Page 28 Maintenance timer interval This option defines the amount of time (hours) that the maintenance timer will count down to. Highlight Interval Time, press <ENTER>. Select 010–250, press <ENTER>. Page 26 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...

  • Page 29: Reset Function

    Power: The lamp’s power is displayed on the screen. • Fan Speed: The product’s fan speed is displayed on the screen. • Fixture Time: The product’s total running time. Rogue Outcast 1 Hybrid User Manual Rev. 2 Page 27 of 32...

  • Page 30: Offset Mode

    Highlight MAC4, press <ENTER>. Select 000–255, press <ENTER>. Mac 5 Highlight MAC5, press <ENTER>. Select 000–255, press <ENTER>. Mac 6 Highlight MAC6, press <ENTER>. Select 000–255, press <ENTER>. Page 28 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...

  • Page 31: Technical Information

    Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Do not spin the cooling fans while blowing compressed air into them. Rogue Outcast 1 Hybrid User Manual Rev. 2 Page 29 of 32...

  • Page 32: Technical Specifications

    Channel Range 3- and 5-pin XLR 20 or 25 channels Ordering Product Name Item Code UPC Number Rogue Outcast 1 Hybrid 781462220112 UL 1573 CSA C22.2 No. 166 E113093 Page 30 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...

  • Page 33: Returns

    Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be your responsibility. FedEx packing or double-boxing are recommended. Chauvet reserves the right to use its own discretion to repair or replace returned product(s). Rogue Outcast 1 Hybrid User Manual Rev. 2 Page 31 of 32...

  • Page 34: Contact Us

    Visit the applicable website above to verify our contact information and instructions to request support. Outside the U.S., U.K., Ireland, Mexico, France, Germany, or Benelux, contact the dealer of record. Page 32 of 32 Rogue Outcast 1 Hybrid User Manual Rev. 2...
