4. Operation

Control Panel Description

Button/Knob Function
<MENU> Exits from the current menu or function
Enables the currently displayed menu or sets the currently selected value into the
<ENTER>
selected function
Navigates upwards through the menu list or increases the numeric value when in a
<UP>
function
Navigates downwards through the menu list or decreases the numeric value when
<DOWN>
in a function

Programming

Refer to the Menu Map to understand the menu options. The menu map shows the main level and a
variable number of programming levels for each option.
• To go to the desired main level, press <MENU> repeatedly until the option shows on the display.
Press <ENTER> to select. This will enter the first programming level for that option.
• To select an option or value within the current programming level, press <UP> or <DOWN> until the
option shows on the display. Press <ENTER> to select. In this case, if there is another programming
level, that first option or the selected value will show on the display.
• Press <MENU> repeatedly to exit to the previous main level.

Passcode

After being prompted to enter the passcode, press <UP>, <DOWN>, <UP>, <DOWN>, <ENTER>.

Menu Map

Refer to the STRIKE Array 4C product page on
Main Menu
Protocol
DMX
Address
1Ch
DMX
Channel
12
www.chauvetprofessional.com
Programming Levels
DMX512
Artnet
sACN
001–512*
Virtual Color Wheel
Color Temperature
Manual Color Mixer
3Ch
5Ch
7Ch
10Ch
12Ch
13Ch
16Ch
22Ch
HSV
for the latest menu map.
Description
Sets the control protocol
Selects DMX address (*Highest channel
restricted to personality chosen)
1-channel: dimmer
3-channel: dimmer, virtual color wheel,
color temperature
5-channel: RGBAW
7-channel: dimmer, RGBAW, strobe
10-channel: dimmer, RGBAW, strobe,
virtual color wheel, color temperature
12-channel: dimmer, RGBAW, strobe,
virtual color wheel, color temperature,
auto programs and speed, control
13-channel: 16-bit dimmer, 16-bit
RGBAW, strobe
16-channel: 16-bit dimmer, 16-bit
RGBAW, strobe, virtual color wheel, color
temperature, control
22-channel: 16-bit RGBAW 1–4, control
3-channel: hue, saturation, value
