Operation

Virtual Color Wheel

The STRIKE Array 4C includes a feature called the Virtual Color Wheel (VCW). This feature is available as
a standalone control mode and as a control channel in select DMX personalities. More than 30 premixed
colors, custom blended by Chauvet engineers, are available to call up for easier programming.
The DMX values used for these colors are provided below. The intensity of the output can be adjusted to
more closely replicate industry-standard colors. A chart is available at
compare Chauvet's premixed colors with popular gel colors. This chart is for comparison purposes only
and is not an assertion that Chauvet's premixed colors match any of the gel colors listed.

Virtual Color Wheel Chart

DMX Value Display Readout
000  005 --
006  013 C3050–Md Yellow
014  021 C3040–Lt Yellow
022  028 C3240–Amb Yellow
029  035 C2340–VLt Amber
036  043 C2040–Lt Amber
044  051 C2050–Md Amber
052  059 C2060–Dk Amber
060  067 C1050–Lt Red
068  075 C1080–Md Red
076  083 C1020–NC Pink
084  091 C1030–Md Pink
092  099 C1630–Dk Pink
100  107 C1250–Md Red Amber
108  115 C1060–Dk Red Amber
116  121 C1650–Magenta
122  130 C6170–Dk Magenta
131  138 C6020–Lt Lavender
139  146 C5030–Lt Blue
147  154 C5020–VLt Blue
155  162 C5430–Lt Blue2
163  170 C5070–Blue
171  178 C5050–Md Blue
179  186 C5060–Dk Blue
187  194 C5690–Indigo
195  202 C5080–VDk Blue
203  210 C5081–VDk Blue2
211  218 C4370–Yel Green
219  226 C4070–Green
227  234 C4550–Turquoise
235  242 C4560–Aqua
243  250 C4570–Blue Green
251  255 --
The colors above are simulated renditions of the color output produced compared with
other similar incandescent products. Chauvet makes no guarantee of the color output
accuracy.
STRIKE Array 4C User Manual Rev. 1
Red Green
-- --
255 225
255 177
255 220
195 000
255 000
255 053
255 008
255 000
255 000
255 075
255 075
218 077
255 000
255 005
255 003
255 000
255 220
000 255
000 215
000 215
000 195
000 163
000 128
053 009
007 084
011 082
000 255
000 255
000 255
000 255
000 255
-- --
www.chauvetprofessional.com
Blue Amber
-- --
000 255
003 255
000 255
015 255
011 255
000 255
000 255
003 014
002 000
062 255
057 255
057 255
009 168
009 036
062 255
055 000
093 255
159 112
145 196
132 52
188 000
190 000
193 000
255 000
116 000
139 000
002 025
009 000
087 096
098 044
026 008
-- --
to
White
--
037
037
000
057
061
017
017
000
000
073
041
061
000
000
012
000
044
078
065
092
019
068
038
000
000
000
000
175
255
255
000
--
