SSV Works RG4-5KRC Manual page 9

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com
I
Phone: 818-991-1778
I
Fax: 866-293-6751
- 5mm Allen Key
PARTS LIST IMAGES
1. US2-C65 Enclosures (1 pair,
0
5. MG Allen Socket Head Bolts
& Washersx4
- 3mm Allen Key
2. R~nger Clamp x 4
6. MG Set Screws x 8
A. Find the best orientation for the speaker on your bar and
screw in the Set Screws in the OPPOSITE holes of where the
clamp will install into.
RG-C65K
Polaris Ranger
6.5" Speaker Cage Mount Pods
- 8mm Open End Wrench
3. Aftermarket Speaker Adapter
(comes with unloaded pods only)
0
4. MG Hex Head Bolts
&
Washersx4
B. Loosely install the clamp base to the cage mount pod with the
two (2) MG Hex head bolts and washers, place the cage mount
pod in the desired mounting location and tighten the hex head
bolts using a 8mm wrench.
