Shielding Gas Supply (Shielding Gas Cylinder For Welding Machine); Gas Test; Rinse Hose Package Function; Setting The Shielding Gas Quantity - EWM drive 4X HP Operating Instructions Manual

5.4.2

Shielding gas supply (shielding gas cylinder for welding machine)

5.4.3

Gas test

•
Slowly open the gas cylinder valve.
•
Open the pressure regulator.
•
Switch on the power source at the main switch.
•
Initiate gas test function on the machine control.
•
Set the relevant gas quantity for the application on the pressure regulator.
•
The gas test is triggered on the machine control by pressing the
Shielding gas flows for around 25 seconds or until the button is pressed again.
5.4.4

Rinse hose package function

Operating
Element
5.4.4.1

Setting the shielding gas quantity

Welding process
MAG welding
MIG brazing
MIG welding (aluminium)
TIG
Helium-rich gas mixtures require a higher gas volume!
The table below can be used to correct the gas volume calculated where necessary:
Shielding gas
75% Ar/25% He
50% Ar/50% He
25% Ar/75% He
100% He
Incorrect shielding gas setting!
•
If the shielding gas setting is too low or too high, this can introduce air to the weld pool and
may cause pores to form.
•
Adjust the shielding gas quantity to suit the welding task!
099-005392-EW501
01.02.2016
Action Result
Select rinse hose package.
Shielding gas flows continuously until the Gas Test button is pressed
5 s
again.
Recommended shielding gas quantity
Wire diameter x 11.5 = l/min
Wire diameter x 11.5 = l/min
Wire diameter x 13.5 = l/min (100 % argon)
Gas nozzle diameter in mm corresponds to l/min gas throughput
Design and function
Notes on the installation of welding current leads
button briefly.
Factor
1.14
1.35
1.75
3.16
