- Page 1 HS2310-16GH2GT1XS Switch Hardware Installation and Reference Guide Document Version: V1.0 Date: 2023.12.07 Copyright ©2023 Ruijie Networks...
- Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.
- Page 3 Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support Case Portal: http://caseportal.ruijienetworks.com Community: http://community.ruijienetworks.com Technical Support Email: service_rj@ruijienetworks.com...
-
Page 4: Table Of Contents
Requirements of Installation Tools ..................16 Product Installation ........................17 Installation Flowchart ......................17 Confirmations before Installation ..................17 Installing the HS2310-16GH2GT1XS ................... 18 3.3.1 Mounting the Switch to a Standard 19-inch Rack ..........18 3.3.2 Mounting the Switch on the Wall ................19 3.3.3... - Page 5 4.2.1 Checking before the Device is Powered on ............25 4.2.2 Checking after Program Startup (Recommended) ..........25 Web Configuration .......................... 26 Maintenance and Troubleshooting ....................27 General Troubleshooting Procedure ................. 27 Troubleshooting Common Faults ..................27 Appendix A Connectors and Connection Media ................. 29 Appendix B Mini-GBIC and SFP+ Module .....................
-
Page 6: Product Overview
Product Overview 1 Product Overview The HS2310-16GH2GT1XS switch is designed for old apartments to provide the fiber to the home (FTTB) solution, without affecting telephone and fax functions. The switch provides a gigabit high-speed network over existing telephone lines in an old apartment. -
Page 7: Technical Specifications
Support speed control and fault alarm. EMC Standards VCCI-CISPR 32 Certification VCCI & JATE The HS2310-16GH2GT1XS switch should be installed in an equipment room or in a dedicated place, and is accessible only by maintenance personnel, professional personnel or technicians. -
Page 8: Product Appearance
Product Overview Product Appearance On the front panel, the HS2310-16GH2GT1XS switch provides 1 POTS/ISDN port, 1 console port, 2 10/100/1000Base-T ports (RJ45). 1 SFP+ port, 2 clock synchronization ports (SYNC_IN and SYNC_OUT), and 16 G.hn ports (RJ11). On the back panel, it provides an 12V AC power socket. -
Page 9: Port Definition
Hardware Installation and Reference Guide Product Overview Back Panel Figure 1-4 Back Panel of HS2310-16GH2GT1XS 1. Grounding pole 3. Wiring harness retainer Note 2. Anti-theft lock hole 4. DC power socket Port Definition POTS/ISDN Port The POTS/ISDN port is a 50-pin connector (RJ21). It supports 16 POTS/ISDN signal inputs, which means the signal can be transmitted through the device internally to provide internet access to the HA3515-DG in the room without effecting the POTS or ISDN function. -
Page 10: Power Supply
Hardware Installation and Reference Guide Product Overview The G.hn port is a 6P4C connector (RJ11). Only the Pin 3 and Pin 4 are used for transmitting signals. The connection between the G.hn port of the switch and the G.hn port of HA3515-DG can be crossover or straight-through. Figure 1-6 RJ11 Connector Power Supply AC Input... -
Page 11: Heat Dissipation
Product Overview Heat Dissipation HS2310-16GH2GT1XS switch adopts a right-to-left airflow to ensure normal operation. Maintain a minimum clearance of 10 cm around the device to allow air circulation. It is recommended to clean the device once every 3 months to avoid dust from blocking vents. -
Page 12: Buttons
Hardware Installation and Reference Guide Product Overview The port has been linked, but no data is transmitted. Green: The transmission rate is higher than Solid green/yellow the threshold value. Yellow: The transmission rate is lower than the threshold value. G.hn Port Status LEDs The port has been linked and data is transmitted. -
Page 13: Topology
Hardware Installation and Reference Guide Product Overview Topology A Single Switch Figure 1-8 Topology of a Single Switch The POTS/ISDN port is connected to the telephone bus. Connect one of the three ports (GE1/GE2/10G) to the network. LINE1-16 is connected to the G.hn ports of the HA3515-DG in rooms using telephone lines. Three Switches ... - Page 14 Hardware Installation and Reference Guide Product Overview When multiple switches are cascaded, it is recommended to wind telephone lines on ferrite cores for EMI suppression so as to improve the overall performance of the switches. The use of a ferrite core is shown as follows: Figure 1-10 Wingding Telephone Lines on the Ferrite Cores...
-
Page 15: Preparation Before Installation
2 Preparation Before Installation Safety Suggestions To avoid personal injury and equipment damage, please carefully read the safety suggestions before you install the HS2310-16GH2GT1XS switch. The following safety suggestions do not cover all possible dangers. 2.1.1 Installation Keep the chassis clean and free from any dust. -
Page 16: Static Discharge Damage Prevention
2.1.5 Laser The HS2310-16GH2GT1XS switch supports varying models of optical modules sold on the market which are Class I laser products. Improper use of optical modules may cause damage. Therefore, pay attention to the following when you use them: ... -
Page 17: Storage
2.2.2 Temperature and Humidity To ensure the normal operation and prolong the service life of HS2310-16GH2GT1XS switch, you should keep proper temperature and humidity in the equipment room. -
Page 18: Cleanness
Hardware Installation and Reference Guide Preparation Before Installation The requirements for the sampling site of the temperature and humidity in the operating environment of the device are as follows: There is no protective plate at the front or back of the equipment rack. The vertical height is 1.5 m above the floor. -
Page 19: Grounding
2.2.5 Grounding A good grounding system is the basis for the stable and reliable operation of the HS2310-16GH2GT1XS switch. It is the chief condition to prevent lightning stroke and resist interference. Please carefully check the grounding conditions on the installation site according to the grounding requirements, and perform grounding operations properly as required. -
Page 20: Lightning Resistance
Hardware Installation and Reference Guide Preparation Before Installation Figure 2-1 Grounding Pole 2.2.6 Lightning Resistance When the AC power cable is imported outdoors and directly connected to the power port of the HS2310- 16GH2GT1XS switch, lightning-proof grounding connectors should be adopted to prevent the switch from being hit by lightning shocks. -
Page 21: Optical Fiber Connection
Hardware Installation and Reference Guide Preparation Before Installation Optical Fiber Connection Before connecting optical fibers, ensure that the types of optical connector and optical fiber can be matched with the type of optical interface used, and check the sending and receiving direction of the optical fiber. The sending end of the device should be connected to the receiving end of the other device, and the receiving end of the device should be connected to the sending end of the other device. -
Page 22: Product Installation
Hardware Installation and Reference Guide Product Installation 3 Product Installation Please ensure that you have carefully read Chapter 2. Make sure that the requirements set forth in Chapter 2 have been met. Installation Flowchart Mount the switch on the Rack/Wall/Desktop Ground the switch Connect Power Supply Connect Interface Cable... -
Page 23: Installing The Hs2310-16Gh2Gt1Xs
If outdoor cabling is necessary, take relevant measures for lightning protection. 3.3.1 Mounting the Switch to a Standard 19-inch Rack The HS2310-16GH2GT1XS switch follows the EIA standard dimensions and can be installed in a 19-inch distribution cabinet. Step 1: Attach the mounting brackets to the switch with the supplied screws, as shown in Figure 3-1. -
Page 24: Mounting The Switch On The Wall
Figure 3-3 Attaching the Mounting Brackets to the Rack 3.3.2 Mounting the Switch on the Wall The HS2310-16GH2GT1XS switch can be mounted on the wall, as shown in the following figures. Attach the mounting brackets to the switch with the supplied screws, as shown in Figure 3-4. - Page 25 Hardware Installation and Reference Guide Product Installation Figure 3-4 Attaching the Mounting Brackets to the Switch for Wall-Mounting Use the expansion screws to secure the mounting brackets on the wall, as shown in Figure 3-5. Figure 3-5 Attaching the Switch on the Wall SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.
-
Page 26: Mounting The Switch On A Workbench
Hardware Installation and Reference Guide Product Installation 3.3.3 Mounting the Switch on a Workbench In some cases, users don’t have a 19-inch standard cabinet and wall hanging installation environment. At this time, people can choose to place the switch on a workbench. Attach the four rubber feet to the recessed areas on the bottom of the switch, as shown in Figure 3-6. -
Page 27: Grounding The Switch
Hardware Installation and Reference Guide Product Installation Grounding the Switch The switch has a PGND on the back panel. First connect the PGND to the grounding lug of the rack and then connect the grounding lug to the grounding bar of the equipment room. Wall mounting and desktop mounting also need to be well grounded. -
Page 28: Bundling The Cables
Hardware Installation and Reference Guide Product Installation Bundling the Cables Precautions The power cables and other cables should be bundled in a pleasing way. When you bundle fibers, make sure that the fibers at the connectors have natural bends or bends of large radius. -
Page 29: System Debugging
Connect the PC to the console port of the switch through the cable, as shown in Figure 4-1. Figure 4-1 Configuration Environment Start a terminal application on the computer, such as PuTTY, and configure the following parameters. Press Enter on the command-line interface. When the Ruijie prompt appears, you are set to configure your switch. -
Page 30: Startup Check
Hardware Installation and Reference Guide System Debugging Startup Check 4.2.1 Checking before the Device is Powered on The switch is fully grounded. The power cable is correctly connected. The DC power cable is attached to the wiring harness retainer on the rear panel using a cable tie. ... -
Page 31: Web Configuration
Hardware Installation and Reference Guide Web Configuration 5 Web Configuration Connect the PC to the switch using a network cable. Configure the PC with an IP address 192.168.1.xxx. Please note that 192.168.1.200 is in use by the switch. Open a command window by entering cmd in the Windows Start menu and then enter ping 192.168.1.200. Open a browser, enter 192.168.1.200 into the address bar of the browser and press Enter. -
Page 32: Maintenance And Troubleshooting
Hardware Installation and Reference Guide Maintenance and Troubleshooting 6 Maintenance and Troubleshooting General Troubleshooting Procedure Troubleshooting Common Faults Symptom Possible Causes Solution Forgetting the management A password is manually configured but Press the reset button to restore the device interface login it is forgotten. - Page 33 Hardware Installation and Reference Guide Maintenance and Troubleshooting 1. Replace the twisted pair cable. The G.hn port is not 1. The twisted pair cable is not in good 2. Check whether the device is installed connected or fails to contact. correctly according the installation guide.
-
Page 34: Appendix A Connectors And Connection Media
Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Appendix A Connectors and Connection Media 1000BASE-T/100BASE-TX/10BASE-T Ports The 1000BASE-T/100BASE-TX/10BASE-T is a port that supports adaptation of three rates, and automatic MDI/MDIX Crossover at these three rates. The 1000BASE-T complies with IEEE 802.3ab, and uses the cable of 100-ohm Category-5 or Supper Category-5 UTP or STP, which can be up to 100 m. - Page 35 Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Optical Fiber Connection For the optical fiber ports, select single-mode or multiple-mode optical fibers for connection according to the fiber module connected. The connection schematic diagram is shown in Figure A-4: Figure A-4 Optical Fiber Connections...
-
Page 36: Appendix B Mini-Gbic And Sfp+ Module
SFP modules (Mini-GBIC module) modules are available to address the requirements of interface types of switch modules. You can select the Mini-GBIC module to suit your specific needs. The models and technical specifications of some Mini-GBIC modules are listed below. For details, see Ruijie Transceiver Installation and Reference Guide. - Page 37 Hardware Installation and Reference Guide Appendix B Mini-GBIC and SFP+ Module Table B-2 Models of 1000M SFP Copper Module Standard Model DDM (Yes/No) 1000Base-T Mini-GBIC-GT Table B-3 Module Cabling Specification Cabling Model Connector Type Fiber Type Core Size(um) Distance 62.5/125 275m MINI-GBIC-SX-MM850 50/125...
- Page 38 Optic Cable Active Fiber- XG-SFP-AOC5M SFP+ 10.3125 Optic Cable Active Fiber- 10.3125 XG-SFP-AOC10M SFP+ Optic Cable SFP+ module types/models are still being updated. If you need a more accurate model, please contact Ruijie networks marketing personnel or technical support personnel.
- Page 39 Hardware Installation and Reference Guide Appendix B Mini-GBIC and SFP+ Module No transmit power is reported in the DDM function of the AOC cable, and the TX power allows N/A to be displayed. Table B-7 Cabling Specifications Modular Interface Cable Core Size Cabling Model...
-
Page 40: Appendix C Lightning Protection
Hardware Installation and Reference Guide Appendix C Lightning Protection Appendix C Lightning Protection Installing AC Power Arrester (lightning protection cable row) The external lightning protection cable row shall be used on the AC power port to prevent the switch from being struck by lightning when the AC power cable is introduced from the outdoor and directly connected to the power port of the switch. - Page 41 Hardware Installation and Reference Guide Appendix C Lightning Protection Installing the Ethernet Port Arrester During the switch usage, the Ethernet port arrester shall be connected to the switch to prevent the switch damage by lightning before the outdoor network cable connects to the switch. Tools: Cross or straight screwdriver, Multimeter, Diagonal pliers Installation Steps: Tear one side of the protection paper for the double-sided adhesive tape and paste the tape to the...
- Page 42 Hardware Installation and Reference Guide Appendix C Lightning Protection You may pay attention to the following conditions during the actual installation to avoid influencing the performance of the Ethernet port arrester: Reversed direction of the arrester installation. You shall connect the external network cable to the “IN” end and connect the switch Ethernet port to the “OUT”...
-
Page 43: Appendix D Cabling Recommendations In Installation
Appendix D Cabling Recommendations in Installation When HS2310-16GH2GT1XS switch is installed in standard 19-inch cabinets, the cables are tied in the binding rack on the cabinet by the cabling rack, and top cabling or bottom cabling is adopted according to the actual situation in the equipment room. - Page 44 Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation Cables of different types (such as power cords, signal cables, and grounding cables) should be separated in cabling and bundling. When they are close, crossover cabling can be adopted. In the case of parallel cabling, power cords and signal cables should maintain a space equal to or greater than 30 mm.
- Page 45 Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the cabinet or cabling slot. The proper position indicates a position that will not affect device running or cause device damage or cable damage during commissioning.
-
Page 46: Appendix E Site Selection
Hardware Installation and Reference Guide Appendix E Site Selection Appendix E Site Selection The machine room should be at least 5 km away from the heavy pollution source such as the smelter, coal mine and thermal power plant, 3.7 km away from the medium pollution source such as the chemical industry, rubber industry and electroplating industry, and 2 km away from the light pollution source such as the food manufacturer and leather plant.
