- Page 1 Mini IP KVM User Manual Desktop Remote Server Management at Anywhere Mini Size Variety of Video Port Selection 1-port, 2-port, 4-port IP KVM Gateway User Friendly IP Remote Access OS Support : Mac / Windows / Linux UM-Mini IP KVM-Q423V1...
- Page 2 Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. UM-Mini IP KVM-Q423V1 P. 1 www.austin-hughes.com...
-
Page 3: Table Of Contents
Specification Design Overview I/O & Connection < Part 5 > VGA IP KVM P.11 Specification Design Overview I/O & Connection < Part 6 > DVI-D IP KVM P.13 Specification Design Overview I/O & Connection UM-Mini IP KVM-Q423V1 P. 2 www.austin-hughes.com... - Page 4 Windows enables mouse acceleration by default. Make sure you are logged in to windows to check mouse synchronization. Change display scaling setting 100% Open Settings. Click on System. Click on Display. Under the “Scale and layout” section, select the scale 100%. UM-Mini IP KVM-Q423V1 P. 3 www.austin-hughes.com...
- Page 5 The IP remote console displayed on the HTML5-based browser support multiple types of resolution, with a maximum of 1,920 x 1,200. Click Remote Console and then Resolution, the Remote Console Video page is displayed, select the same resolution as target servers, click Apply to save the resolution. UM-Mini IP KVM-Q423V1 P. 4 www.austin-hughes.com...
- Page 6 Click Control and then Remote console, the Remote console Preview is displayed, then Click Connect, the remote console opens in a separate windows. press the Mouse Sync once ( positioning top left corner ), the mouse will align. UM-Mini IP KVM-Q423V1 P. 5 www.austin-hughes.com...
- Page 7 Package items IP-C101 USB-C 1-port Mini IP KVM x 1, USB-C to USB-A 6ft power cable x 1, Mounting set x 1 IP-C102 USB-C 2-port Mini IP KVM x 1, USB-C to USB-A 6ft power cable x 1, Mounting set x 1...
-
Page 8: Part 3 > Usb-C Ip Kvm
0.445 kg / 0.981 lb 0.578 kg / 1.274 lb 0.712 kg / 1.569 lb Gross 0.745 kg / 1.642 lb 0.878 kg / 1.936 lb 1.212 kg / 2.672 lb Chassis color Dark Chassis materials Steel UM-Mini IP KVM-Q423V1 P. 7 www.austin-hughes.com... -
Page 9: Design Overview 3.3 I/O & Connection
PC 3 PC 2 PC 1 Switch PC 1 PC 2 PC 3 PC 4 HDMI OUT Online USB-C USB-C USB-C USB-C Keyboard USB-C Power Display Computers *USB-C to USB-A 6ft power cable included UM-Mini IP KVM-Q423V1 P. 8 www.austin-hughes.com... -
Page 10: Part 4 > Hdmi Ip Kvm
0.469 kg / 1.034 lb 0.609 kg / 1.343 lb 0.750 kg / 1.653 lb Gross 0.769 kg / 1.695 lb 0.909 kg / 2.005 lb 1.250 kg / 2.756 lb Chassis color Dark Chassis materials Steel UM-Mini IP KVM-Q423V1 P. 9 www.austin-hughes.com... -
Page 11: Design Overview 4.3 I/O & Connection
Mouse Display PC 2 PC 1 Switch PC 1 PC 2 PC 3 PC 4 HDMI OUT HDMI IN HDMI IN Online Keyboard USB-C Power Display Computers *USB-C to USB-A 6ft power cable included UM-Mini IP KVM-Q423V1 P. 10 www.austin-hughes.com... -
Page 12: Part 5 > Vga Ip Kvm
0.472 kg / 1.04 lb 0.613 kg / 1.351 lb 0.754 kg / 1.662 lb Gross 0.772 kg / 1.702 lb 0.913 kg / 2.013 lb 1.254 kg / 2.765 lb Chassis color Dark Chassis materials Steel UM-Mini IP KVM-Q423V1 P. 11 www.austin-hughes.com... -
Page 13: Design Overview 5.3 I/O & Connection
Mouse Display PC 2 PC 1 Switch PC 1 PC 2 PC 3 PC 4 VGA OUT VGA IN VGA IN Online Keyboard USB-C Power Display Computers *USB-C to USB-A 6ft power cable included UM-Mini IP KVM-Q423V1 P. 12 www.austin-hughes.com... -
Page 14: Part 6 > Dvi-D Ip Kvm
0.480 kg / 1.058 lb 0.623 kg / 1.373 lb 0.767 kg / 1.690 lb Gross 0.780 kg / 1.719 lb 0.923 kg / 2.034 lb 1.267 kg / 2.793 lb Chassis color Dark Chassis materials Steel UM-Mini IP KVM-Q423V1 P. 13 www.austin-hughes.com... -
Page 15: Design Overview
Mouse Display PC 2 PC 1 Switch PC 1 PC 2 PC 3 PC 4 DVI-D OUT DVI-D IN DVI-D IN Online Keyboard USB-C Power Display Computers *USB-C to USB-A 6ft power cable included UM-Mini IP KVM-Q423V1 P. 14 www.austin-hughes.com... - Page 16 The company reserves the right to modify product specifications without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2023 Austin Hughes Electronics Ltd. All rights reserved. UM-Mini IP KVM-Q423V1 P. 15...
