dedicated KVM switch and rackmount screen technology
User Manual
USB Hub DB-15
2-console KVM
IP-802H
USB Hub DB-15
2-console KVM
CV-802H
USB Hub DB-15 KVM
CV-801H
751
Designed and manufactured by Austin Hughes
UM-CV-751-USBKVM-Q222V1
www.austin-hughes.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP-802H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Austin Hughes IP-802H

Summary of Contents for Austin Hughes IP-802H

  • Page 1 KVM switch and rackmount screen technology User Manual USB Hub DB-15 2-console KVM IP-802H USB Hub DB-15 2-console KVM CV-802H USB Hub DB-15 KVM CV-801H Designed and manufactured by Austin Hughes UM-CV-751-USBKVM-Q222V1 www.austin-hughes.com...
  • Page 2 Legal Information First English printing, May 2022 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.

  • Page 3: Table Of Contents

    Contents < Part. 1 > USB Hub DB-15 IP KVM IP-802H Package Contents KVM port connection IP & Local console connection Connect to IP console IP Console Firmware Update Built-in USB Hub Usage & Connection KVM Cascade P.10 Specifi cations P.11...
  • Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.

  • Page 5: Usb Hub Db-15 Ip Kvm

    USB Hub DB-15 < 1.1 > Package Contents IP-802H KVM unit • IP-802H KVM unit x 1 • Mounting set w/ bracket & screws x 1 • Power adapter w/ power cord ( for KVM ) x 1 IP-802H Local Console 12VDC 2 x USB 2.0...

  • Page 6: Kvm Port Connection

    < 1.2 > KVM port connection CB-6 / CB-10 / CB-15 USB Servers ■ 6 / 10 / 15 ft USB KVM cable ■ Support USB server DB-15 USB KVM port CB - 6 / 10 / 15 USB KVM cable support USB server USB Servers UM-CV-751-USBKVM-Q222V1...

  • Page 7: Ip & Local Console Connection

    < 1.3 > IP & Local console connection Network device hub or router CAT 5 / 6 cable IP Console Frequency Resolution Support ( Hz ) 1920 x 1080 1920 x 1200 1600 x 1200 1280 x 1024 1024 x 768 UM-CV-751-USBKVM-Q222V1 www.austin-hughes.com...

  • Page 8: Connect To Ip Console

    < 1.4 > Connect to IP console Please make sure to follow the below steps to setup your KVM IP properly. I. Confi gure the target server The target server is the server that connected to the IP KVM Switch. Before use IP remote access, you need to turn off...
  • Page 9 Change display scaling setting 100% Open Settings. Click on System. Click on Display. Under the “Scale and layout” section, select the scale 100%. UM-CV-751-USBKVM-Q222V1 www.austin-hughes.com...
  • Page 10 II. Logging in to IP KVM The default IP address is as below: IP address: 192.168.1.22 Subnet mask: 255.255.255.0 Gateway: 192.168.1.1 IP KVM model with single IP port: - Default address 192.168.1.22 IP KVM model with dual IP ports: - The 1st IP address 192.168.1.22 - The 2nd IP address 192.168.1.23 To log in to the IP KVM do as follows: Open the browser on the client, in the address bar, enter the default IP KVM address ( 192.168.1.22 )
  • Page 11 III. Confi gure Remote Console Resolution The IP remote console displayed on the HTML5-based browser support multiple types of resolution, with a maximum of 1,920 x 1,200. Click Remote Console and then Resolution, the Remote Console Video page is displayed, select the same resolution as target servers, click Apply to save the resolution.

  • Page 12: Ip Console Firmware Update

    < 1.5 > IP Console Firmware Update Firmware Update Steps 1) Download the latest IP KVM fi rmware from the link http://www.austin-hughes.com/resources/software/kvm-switch 2) Login the IP KVM 3) Click < Maintenance > 4) Click < Update Firmware > 5) Click < Browse > to select the firmware file 6) Click <...

  • Page 13: Built-In Usb Hub Usage & Connection

    < 1.6 > Built-in USB Hub Usage & Connection 2 x USB 2.0 ( USB hub for device connection ) Flash Disk Hard disk storage Keyboard / Mouse Scanner Printer Camera UM-CV-751-USBKVM-Q222V1 www.austin-hughes.com...

  • Page 14: Kvm Cascade

    < 1.7 > KVM Cascade ■ Cascade up to 8 levels, 128 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of CV-801H. When multiple combo DB-15 KVMs cascade together, the master KVM at level 1 will take all control of other Expansion KVM switches (e.g.

  • Page 15: Specifi Cations

    < 1.8 > Specifi cations IP-802H ▀ KVM Port Number of ports : Connector : DB-15 combo connector Connectivity : Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet Local Console ▀ Graphic connector : 1 x DB-15 Input device : 2 x USB type A for keyboard &...

  • Page 16: Cv-802H

    < Part 2 > USB Hub DB-15 2-console KVM < 2.1 > Package Contents CV-802H • CV-802H KVM unit x 1 • Mounting set w/ bracket & screws x 1 KVM unit • Power adapter w/ power cord ( for KVM ) x 1 •...

  • Page 17: Kvm Port Connection

    < 2.2 > KVM port connection CB-6 / CB-10 / CB-15 USB Servers ■ 6 / 10 / 15 ft USB KVM cable ■ Support USB server DB-15 USB KVM port CB - 6 / 10 / 15 USB KVM cable support USB server USB Servers UM-CV-751-USBKVM-Q222V1...

  • Page 18: Remote & Local Console Connection

    < 2.3 > Remote & Local console connection For remote console, max. cable length is subject to the resolution. Please refer to the tables below. Remote Console Frequency Max. Cat6 Cable Resolution Support ( Hz ) Length ( M ) 1920 x 1080 1920 x 1200 1600 x 1200...
  • Page 19 How to use a receiver to connect a remote console Local Power Computer Remote I/O Receiver Front Mouse Remote Local Rear Select button The receiver provides a hotkey function for remote console. Please refer to P.23 Remote Console Local computer CE-6 Cat6 cable ( Optional setup )

  • Page 20: Built-In Usb Hub Usage & Connection

    < 2.4 > Built-in USB Hub Usage & Connection 2 x USB 2.0 ( USB hub for device connection ) Flash Disk Hard disk storage Keyboard / Mouse Scanner Printer Camera UM-CV-751-USBKVM-Q222V1 P.16 P.16 www.austin-hughes.com...

  • Page 21: Kvm Cascade

    < 2.5 > KVM Cascade ■ Cascade up to 8 levels, 128 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of CV-801H. When multiple combo DB-15 KVMs cascade together, the master KVM at level 1 will take all control of other Expansion KVM switches (e.g.

  • Page 22: Specifi Cations

    < 2.6 > Specifi cations CV-802H KVM Port ▀ Number of ports : Connector : DB-15 combo connector Connectivity : Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet Local Console ▀ Graphic connector : 1 x DB-15 Input device : 2 x USB type A for keyboard &...

  • Page 23: Usb Hub Db-15 Kvm

    < Part 3 > USB Hub DB-15 KVM < 3.1 > Package Contents CV-801H KVM unit • CV-801H KVM unit x 1 • Mounting set w/ bracket & screws x 1 • Power cord ( for KVM ) x 1 CV-801H Local Console 12VDC...

  • Page 24: Kvm Port Connection

    < 3.2 > KVM port connection CB-6 / CB-10 / CB-15 USB Servers ■ 6 / 10 / 15 ft USB KVM cable ■ Support USB server DB-15 USB KVM port CB - 6 / 10 / 15 USB KVM cable support USB server USB Servers UM-CV-751-USBKVM-Q222V1...

  • Page 25: Built-In Usb Hub Usage & Connection

    < 3.3 > Built-in USB Hub Usage & Connection 2 x USB 2.0 ( USB hub for device connection ) Flash Disk Hard disk storage Keyboard / Mouse Scanner Printer Camera UM-CV-751-USBKVM-Q222V1 P.21 www.austin-hughes.com...

  • Page 26: Kvm Cascade

    < 3.4 > KVM Cascade ■ Cascade up to 8 levels, 128 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of CV-801H. When multiple combo DB-15 KVMs cascade together, the master KVM at level 1 will take all control of other Expansion KVM switches (e.g.

  • Page 27: Specifi Cations

    < 3.5 > Specifi cations CV-801H ▀ KVM Port Number of ports : Connector : DB-15 combo connector Connectivity : Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet ▀ Local Console Graphic connector : 1 x DB-15 Input device : 2 x USB type A for keyboard &...

  • Page 28: Usage

    < Part 4 > Usage USB Hub DB-15 KVM Usage < 4.1 > KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications 8 ports Bank no.

  • Page 29: Password

    < 4.2 > Password USB Hub DB-15 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”...

  • Page 30: Kvm Osd

    < 4.3 > KVM OSD USB Hub DB-15 KVM Usage OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter...

  • Page 31: Kvm Hotkey & Remote Console Hotkey

    < 4.4 > KVM Hotkey & Remote Console Hotkey USB Hub DB-15 KVM Usage Local / IP Remote Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port...
  • Page 32 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2022 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-USBKVM-Q222V1 P.28 P.28...
