- Page 1 KVM switch and rackmount screen technology User Manual Matrix DB-15 M-IP813 / 824 M-IP1613 / 1624 Matrix DB-15 KVM M-802 / 803 / 804 M-1602 / 1603 / 1604 Designed and manufactured by Austin Hughes UM-CV-751-MKVM-Q418V1 www.austin-hughes.com...
- Page 3 Legal Information First English printing, October 2018 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 4: Table Of Contents
Contents < Part 1 > Matrix DB-15 M-IP813 M-IP824 M-IP1613 M-IP1624 Package contents KVM port connection IP, Remote & Local console connection P.3 - 4 IP console setting Important Preconfi guration for IP console P.6 - 8 KVM Cascade Specifi cations P.10 <... - Page 5 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 6: Part 1 > Matrix
< Part 1 > Matrix DB-15 < 1.1 > Package Contents Matrix DB-15 IP KVM M-IP813 / M-IP1613 M-IP824 / M-IP1624 • M-IP813 or M-IP1613 or M-IP824 or M-IP1624 KVM unit x 1 • Mounting set w/ bracket & screws x 1 KVM unit •... -
Page 7: Kvm Port Connection
< 1.2 > KVM port connection Matrix DB-15 IP KVM USB Servers CE - 6 / 10 / 15 Combo KVM cable support PS/2 or USB server DB-15 Combo KVM port CE - 6 / 10 / 15 Combo KVM cable support PS/2 or USB server PS/2 Servers CE-6 / CE-10 / CE-15... -
Page 8: Ip, Remote & Local Console Connection
< 1.3 > IP, Remote & Local console connection Matrix DB-15 IP KVM Receiver For remote console, max. cable length is subject to the resolution. Please refer to the tables below. Remote Console IP Console Frequency Max. Cat6 Cable Frequency Resolution Support Resolution Support ( Hz ) - Page 9 How to use a receiver to connect a remote console Matrix DB-15 IP KVM Local Power Computer Remote I/O Receiver Front Mouse Remote Local Rear Select button The receiver provides a hotkey function for remote console. Please refer to P.21 Remote Console Local computer...
-
Page 10: Ip Console Setting
< 1.4 > IP console setting Matrix DB-15 IP KVM After the cable connection, please take the following steps to confi gure the IP KVM : 1. Download IPKVMsetup.exe from the link: www.austin-hughes.com/support/utilities/cyberview/IPKVMsetup.exe 2. Double click IPKVMsetup.exe to confi gure the IP KVM by device setup as below. 3. -
Page 11: Important Preconfi Guration For Ip Console
< 1.5 > Important Preconfi guration for IP console Matrix DB-15 IP KVM You must complete the following tasks after the IP console setting is performed. ( 1 ) TARGET SERVER SETUP **Servers connected to KVM Resolution The IP KVM remote console recognizes several varieties of video display formats with resolutions up to 1600 x 1200 @60Hz. - Page 12 < 1.5 > Important Preconfi guration for IP console Matrix DB-15 IP KVM ( 2 ) REMOTE CLIENT COMPUTER SETUP The remote client computer must have a web browser ( such as Microsoft Internet Explorer, Mozilla Firefox, and Netscape Navigator ) and a Java Virtual Machine ( version 1.4 or higher ) installed. Enable Java on the web browser.
- Page 13 Matrix DB-15 IP KVM 6) Click < Update > After the firmware has been updated, IP KVM will reset automatically. After one minute, you will be redirected to the Login page and requested to login again. - Completed UM-CV-751-MKVM-Q418V1 www.austin-hughes.com...
-
Page 14: Kvm Cascade
< 1.6 > KVM Cascade Matrix DB-15 IP KVM ■ Cascade up to 8 levels, 240 servers ■ Cascading multiple KVM with CMC-8 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of M-802 / M-1602 or MU-1602 / MU-3202. When multiple matrix KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g. -
Page 15: Specifi Cations
< 1.7 > Specifi cations Matrix DB-15 IP KVM M-IP813 M-IP824 M-IP1613 M-IP1624 KVM Port ▀ Number of ports : 8 or 16 Connector : DB-15 combo connector Connectivity : Combo 4-in-1 KVM cable up to 6, 10 & 15 feet ▀... -
Page 16: Part 2. Matrix Db-15 Kvm
Part 2. Matrix DB-15 KVM < 2.1 > Package Contents Matrix DB-15 KVM M-802 / M-1602 • M-802 or M-1602 KVM unit x 1 • Mounting set w/ bracket & screws x 1 KVM unit • Power adapter w/ power cord ( for KVM ) x 1 •... - Page 17 Matrix DB-15 KVM M-802 Local Console Remote Console 1 Power Cascade M-1602 M-803 Local Console Remote Console 1 Power Remote-2 Cascade M-1603 M-804 Remote-3 Local Console Remote Console 1 Power Remote-2 Cascade M-1604 UM-CV-751-MKVM-Q418V1 P.12 www.austin-hughes.com...
-
Page 18: Kvm Port Connection
< 2.2 > KVM port connection Matrix DB-15 KVM USB Servers CE - 6 / 10 / 15 Combo KVM cable support PS/2 or USB server DB-15 Combo KVM port CE - 6 / 10 / 15 Combo KVM cable support PS/2 or USB server PS/2 Servers CE-6 / CE-10 / CE-15... - Page 19 < 2.3 > Local console & remote console connection Matrix DB-15 KVM For remote console, max. cable length is subject to the resolution. Please refer to the tables below. Remote Console Frequency Max. Cat6 Cable Resolution Support ( Hz ) Length ( M ) 1920 x 1200 1920 x 1080...
- Page 20 How to use a receiver to connect a remote console Matrix DB-15 KVM Local Power Computer Remote I/O Receiver Front Mouse Remote Local Rear Select button The receiver provides a hotkey function for remote console. Please refer to P.21 Remote Console Local computer CE-6...
-
Page 21: Kvm Cascade
< 2.4 > KVM Cascade Matrix DB-15 KVM ■ Cascade up to 8 levels, 240 servers ■ Cascading multiple KVM with CMC-8 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of M-802 / M-1602 or MU-1602 / MU-3202. When multiple matrix KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g. -
Page 22: Specifi Cations
< 2.5 > Specifi cations Matrix DB-15 KVM M-802 M-803 M-804 M-1602 M-1603 M-1604 KVM Port ▀ Number of ports : 8 or 16 Connector : DB-15 combo connector Connectivity : Combo 4-in-1 KVM cable up to 6, 10 & 15 feet Local Console ▀... -
Page 23: Part 3. Usage
Part 3. Usage Matrix DB-15 KVM Usage 3.1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications 8 ports Bank no. -
Page 24: Password
3.2 Password Matrix DB-15 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”... -
Page 25: Kvm Osd
3.3 KVM OSD Matrix DB-15 KVM Usage OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter Complete / Switch to selected port... -
Page 26: Kvm Hotkey & Remote Console Hotkey
3.4 KVM Hotkey & Remote Console Hotkey Matrix DB-15 KVM Usage Local Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock +... - Page 27 UM-CV-751-MKVM-Q418V1 P.22 www.austin-hughes.com...
- Page 28 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2018 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-MKVM-Q418V1 P.23...
