Austin Hughes CyberView MU-IP1613 User Manual

Dedicated kvm switch and rackmount screen technology
Hide thumbs Also See for CyberView MU-IP1613:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Matrix Cat6
Matrix Cat6 KVM
Designed and manufactured by Austin Hughes
UM-CV-751-MUKVM-KIT-Q222V1
dedicated KVM switch and rackmount screen technology
- KVM Rear Kit Version
for LCD Console Drawer
-MUIP1613 / 1624
KVM
-MUIP3213 / 3224
-MU1602 / 1603 / 1604
-MU3202 / 3203 / 3204
back
back
www.austin-hughes.com
751

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CyberView MU-IP1613 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Austin Hughes CyberView MU-IP1613

Summary of Contents for Austin Hughes CyberView MU-IP1613

  • Page 1 - KVM Rear Kit Version for LCD Console Drawer -MUIP1613 / 1624 Matrix Cat6 -MUIP3213 / 3224 back -MU1602 / 1603 / 1604 Matrix Cat6 KVM -MU3202 / 3203 / 3204 back Designed and manufactured by Austin Hughes UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.com...
  • Page 2 Legal Information First English printing, May 2022 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.

  • Page 3: Table Of Contents

    Contents < Part. 1 > Matrix Cat6 IP KVM MU-IP1613 MU-IP1624 MU-IP3213 MU-IP3224 Package contents KVM port & Cat6 dongle connection IP & Remote console connection Connect to IP console IP Console Firmware Update KVM Cascade P.10 Specifi cations P.11 <...

  • Page 4: Package Contents

    < Part 1 > Matrix Cat6 Matrix Cat6 IP KVM < 1.1 > Package Contents -MUIP1613 / -MUIP3213 • Receiver box for remote console x 1 -MUIP1624 / -MUIP3224 • Power adapter w/ power cord ( for receiver ) x 1 •...

  • Page 5: Kvm Port & Cat6 Dongle Connection

    < 1.2 > KVM port & Cat6 dongle connection Matrix Cat6 IP KVM DG-100C DG-100P DG-100H DG-100SD DG-100S USB-C dongle DP-USB dongle HDMI-USB dongle DVI-USB dongle VGA-USB dongle Servers DG-100C USB-C CAT 5 / 6 cable DG-100P max. 40 meters Cat6 KVM port Drawer KVM Rear Kit DG-100H...

  • Page 6: Ip & Remote Console Connection

    < 1.3 > IP & Remote console connection Matrix Cat6 IP KVM Receiver For remote console, max. cable length is subject to the resolution. Please refer to the tables below. Drawer KVM Rear Kit Remote Console IP Console Frequency Frequency Max.
  • Page 7 How to use a receiver to connect a remote console Matrix Cat6 IP KVM Local Power Computer Remote I/O Receiver Front Mouse Remote Local Rear Select button The receiver provides a hotkey function for remote console. Please refer to P.21 Drawer KVM Rear Kit Remote Console...

  • Page 8: Connect To Ip Console

    < 1.4 > Connect to IP console Matrix Cat6 IP KVM Please make sure to follow the below steps to setup your KVM IP properly. I. Confi gure the target server The target server is the server that connected to the IP KVM Switch. Before use IP remote access, you need to turn off...
  • Page 9 Matrix Cat6 IP KVM Change display scaling setting 100% Open Settings. Click on System. Click on Display. Under the “Scale and layout” section, select the scale 100%. UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.com...
  • Page 10 Matrix Cat6 IP KVM II. Logging in to IP KVM The default IP address is as below: IP address: 192.168.1.22 Subnet mask: 255.255.255.0 Gateway: 192.168.1.1 IP KVM model with single IP port: - Default address 192.168.1.22 IP KVM model with dual IP ports: - The 1st IP address 192.168.1.22 - The 2nd IP address 192.168.1.23 To log in to the IP KVM do as follows:...
  • Page 11 Matrix Cat6 IP KVM III. Confi gure Remote Console Resolution The IP remote console displayed on the HTML5-based browser support multiple types of resolution, with a maximum of 1,920 x 1,200. Click Remote Console and then Resolution, the Remote Console Video page is displayed, select the same resolution as target servers, click Apply to save the resolution.

  • Page 12: Ip Console Firmware Update

    < 1.5 > IP Console Firmware Update Matrix Cat6 IP KVM Firmware Update Steps 1) Download the latest IP KVM fi rmware from the link http://www.austin-hughes.com/resources/software/kvm-switch 2) Login the IP KVM 3) Click < Maintenance > 4) Click < Update Firmware > 5) Click <...

  • Page 13: Kvm Cascade

    < 1.6 > KVM Cascade Matrix Cat6 IP KVM ■ Cascade up to 8 levels, 256 servers ■ Cascading multiple KVM with CMC-8 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of MU-1602 / MU-3202 or M-802 / M-1602. When multiple matrix KVMs cascade together, the master KVM at level 1 will take all control of other Expansion KVM switches (e.g.

  • Page 14: Specifi Cations

    < 1.7 > Specifi cations Matrix Cat6 IP KVM -MUIP1613 -MUIP1624 -MUIP3213 -MUIP3224 KVM Port ▀ Number of ports : 16 or 32 Connector : RJ-45 Connectivity : DVI-D / VGA connector dongle up to 40 meters (132 feet) via Cat6 / Cat5 cable Local Console : Nil for LCD console drawer version...

  • Page 15: Matrix Cat6 Kvm

    < Part 2 > Matrix Cat6 KVM Matrix Cat6 KVM < 2.1 > Package Contents -MU1602 / -MU3202 • Receiver box for remote console x 1 • Power adapter w/ power cord ( for receiver ) x 1 • CE-6 6ft Combo KVM cable for receiver box x 1 KVM Rear Kit back -MU1603 / -MU3203...
  • Page 16 Matrix Cat6 KVM -MU1602 Remote Console 1 Power Cascade -MU3202 -MU1603 Remote Console 1 Power Remote-2 Cascade -MU3203 -MU1604 Remote-3 Remote Console 1 Power Remote-2 Cascade -MU3204 UM-CV-751-MUKVM-KIT-Q222V1 P.13 www.austin-hughes.com...

  • Page 17: Kvm Port & Cat6 Dongle Connection

    < 2.2 > KVM port & Cat6 dongle connection Matrix Cat6 KVM DG-100C DG-100P DG-100H DG-100SD DG-100S USB-C dongle DP-USB dongle HDMI-USB dongle DVI-USB dongle VGA-USB dongle Servers DG-100C USB-C CAT 5 / 6 cable DG-100P max. 40 meters Cat6 KVM port Drawer KVM Rear Kit DG-100H HDMI...

  • Page 18: Remote Console Connection

    < 2.3 > Remote console connection Matrix Cat6 KVM For remote console, max. cable length is subject to the resolution. Please refer to the tables below. Drawer KVM Rear Kit Remote Console Frequency Max. Cat6 Cable Resolution Support ( Hz ) Length ( M ) 1920 x 1080 1920 x 1200...
  • Page 19 How to use a receiver to connect a remote console Matrix Cat6 KVM Local Power Computer Remote I/O Receiver Front Mouse Remote Local Rear Select button The receiver provides a hotkey function for remote console. Please refer to P.21 Drawer KVM Rear Kit Remote Console Local computer...

  • Page 20: Kvm Cascade

    < 2.4 > KVM Cascade Matrix Cat6 KVM ■ Cascade up to 8 levels, 256 servers ■ Cascading multiple KVM with CMC-8 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of MU-1602 / MU-3202 or M-802 / M-1602. When multiple matrix KVMs cascade together, the master KVM at level 1 will take all control of other Expansion KVM switches (e.g.

  • Page 21: Specifi Cations

    < 2.5 > Specifi cations Matrix Cat6 KVM -MU1602 -MU1603 -MU1604 -MU3202 -MU3203 -MU3204 ▀ KVM Port Number of ports : 16 or 32 Connector : RJ-45 Connectivity : DVI-D / VGA connector dongle up to 40 meters (132 feet) via Cat6 / Cat5 cable Local Console : Nil for LCD console drawer version...
  • Page 22 < Part 3 > Usage Matrix Cat6 KVM Usage < 3.1 > KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications Front Panel - Port LED Indications 16 ports...
  • Page 23 < 3.2 > Password Matrix Cat6 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”...

  • Page 24: Matrix Cat6 Kvm Usage

    < 3.3 > KVM OSD Matrix Cat6 KVM Usage OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter...

  • Page 25: Kvm Hotkey & Remote Console Hotkey

    < 3.4 > KVM Hotkey & Remote Console Hotkey Matrix Cat6 KVM Usage Local / IP Remote Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port...
  • Page 26 Intentionally Left Blank UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.com...
  • Page 27 Intentionally Left Blank UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.com...
  • Page 28 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2022 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-MUKVM-KIT-Q222V1 www.austin-hughes.com...
