Mount The Camera - Reolink Lumus Quick Start Manual

Set up the Camera on PC (Optional)
Step 1 Download and install the Reolink Client. Go to https://reolink.com > Support > App & Client
Step 2 Power on the camera.
Step 3 Launch the Reolink Client. Click the "
add it.
Step 4 Follow the onscreen instructions to finish the initial setup.

Mount the Camera

Installation Tips
• Do not face the camera towards any light sources.
• Do not point the camera towards a glass window. Or, it may result in poor image quality
because of the window glare by infrared LEDs, ambient lights or status lights.
• Do not place the camera in a shaded area and point it towards a well-lit area. Or, it may result in
poor image quality. To ensure best image quality, the lighting condition for both the camera and
the capture object shall be the same.
• To ensure better image quality, it's recommended to clean the lens with a soft cloth from time to
time.
• Make sure the power ports are not directly exposed to water or moisture and not blocked by dirt
or other elements.
• Do not install the camera at places where rain and snow can hit the lens directly.
5 English
" button and input the UID number of the camera to
Mount the Camera
1
2
Drill holes in accordance with the mounting hole template and screw the base of the bracket onto
the wall. Next, attach the other part of the bracket onto the base.
Rotate to separate parts from
the bracket.
English 6
