Configuring the trusted network with static
addresses
To disable the SOHO 6 DHCP server and make static address
assignments, follow these steps:
1 Type the IP address of the trusted network in your browser
window to connect to the System Status page of the SOHO 6.
The default IP address is: http://192.168.111.1
2 From the navigation bar at left, select
Network = > Trusted.
The Trusted Network configuration page opens.
3 Type the IP address and the subnet mask in the applicable
fields.
4 Clear the Enable DHCP Server on the Trusted Network
checkbox.
5 Click Submit.
6 Reboot the SOHO 6 as necessary.
7 Configure the appliances on the trusted network with static
addresses.

Configuring Static Routes

To send the specified packets to different segments of the trusted
network connected through a router or switch, configure static
routes.
Follow these instructions to configure static routes:
1 Type the IP address of the trusted network in your browser
window to connect to the System Status page of the SOHO 6.
The default IP address is: http://192.168.111.1
User Guide
Configuring Static Routes
39
