Chapter 12 Support Resources; Troubleshooting Tips; General - Watchguard Firebox SOHO 6 User Manual

CHAPTER 12

Troubleshooting Tips

If you have problems during the installation and the configuration
of your SOHO 6, refer to this information.

General

What do the PWR, Status, and Mode lights signify on the
SOHO 6?
When the PWR light is lit, the SOHO 6 is connected to a power
source. When the Status light is lit, there is a management
connection to the SOHO 6. When the MODE light is lit, the
SOHO 6 is operational.
If the PWR light blinks:
The SOHO 6 is running from its backup flash memory. You can
connect to the SOHO 6 from a computer attached to one of the
four Ethernet ports (labeled 0-3) to configure the SOHO 6.
User Guide
Support Resources
163
