CHAPTER 10: Field Definitions
Logging tab

IPSec Configuration dialog box

204
Add
Enter the email header you want to add to the list and click Add.
Remove
Click to remove the selected email header from the list.
Log removal of unknown headers
Click to log unknown headers that are filtered by the proxy.
Log removal of unknown ESMTP extensions
Click to log unknown ESMTP extensions that are filtered by the
proxy.
Log accounting/auditing information
Click to log accounting and auditing information.
IPSec Routing Policies
A list of current IPSec virtual private networking routing policies.
The list displays:
Local Address - The IP address of the local Firebox
Remote Address - The IP address of the remote IPSec-compliant
device
Disposition - Security disposition of the policy
Tunnel - Identifying name of the tunnel used by the policy
Destination Port - (optional) The port to which the Firebox sends
communications for the policy
Protocol - (optional) The protocol used by the policy
Source Port - (optional) The port from which the Firebox receives
all communication for the policy
DVCP - Identify if use DVCP
Move Up
The Firebox handles policies in the order listed top to bottom in
the IPSec Routing Policies list. Initially, the policies are listed in
