- Page 1 PLT200 SMITH MACHINE LAT ATTACHMENT Owner’s Manual WWW.BODYSOLID.COM Ver. PLT200-20231009...
- Page 2 #DWRULE-4 #DWRULE-4...
- Page 3 PLT200 TABLE OF CONTENTS • SAFETY INSTRUCTIONS............PAGE 4 • PREPARATION................. PAGE 5 • PART/HARDWARE LIST............PAGE 6 • HARDWARE ILLUSTRATION..........PAGE 7 • ASSEMBLY INSTRUCTIONS..........PAGE 12 • EXPLODED VIEW..............PAGE 22 • CONTACT PAGE..............PAGE 24...
- Page 4 PLT200 SAFETY INSTRUCTIONS The PLT200 is designed for your enjoyment. By fol- When using exercise equipment, lowing these precautions and using common sense, you should always take basic you will have many safe and pleasurable hours of precautions including the healthful exercise with your Powerline Smith Machine following: Lat Attachment. • Read all instructions before using the PLT200. These After assembly, you should check all functions to instructions are written to ensure your safety and to protect the unit. ensure correct operation. If you experience problems, first recheck the assembly instructions to locate any • Do not remove any safety labels from the possible errors made during assembly. If you are machine. • Do not allow children on or near the equipment. unable to correct the problem, call the dealer from whom you purchased the machine or call 1-800-556- • Use the equipment only for its intended purpose 3113 for the dealer nearest you. as described in this guide. Do not use accessory attachments that are not recommended by the manufacturer. Such attachments might cause serious Obtaining Service...
- Page 5 PLT200 PREPARATION Required tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each step. the PLT200 include but are not limit to: While you may be able to assemble the PLT200 using the • Standard Wrench Set illustrations only, important safety notes and other tips may be included in the text. • Metric Wrench Set Some pieces may have extra holes that you will not use. Use • Adjustable Wrench only those holes indicated in the instructions and illustrations. • Standard / Metric Allen Key Set NOTE: With so many assembled parts, proper alignment and adjustment is critical. While tightening the nuts and bolts, be sure to leave Installation Requirements room for adjustments. Follow these installation requirements when assembling the PLT200: NOTE: The bottles that are marked “Poison” is your touch up paint. Keep away from children. Set up the PLT200 on a solid, flat surface. A smooth, flat surface under the machine helps keep it level. CAUTION: Obtain assistance! If you feel like you can’t assemble the PLT200 by yourself then do Provide ample space around the machine. Open space not attempt to do so as this could result in around the machine allows for easier access. injury. Review the Installation Requirements before proceeding with the following steps. For aesthetic purposes, insert all bolts in the same direction unless specified (in text or illustrations) to do otherwise.
- Page 6 PLT200 PART LIST Part # DESCRIPTION BASE FRAME CENTER UPRIGHT U FRAME STEEL BRACKET C-C 100mm CHROME GUIDE ROD TOP FRAME WEIGHT RISER PULLEY BRACKET LAT BAR CURL BAR HEX HEAD BOLT, M10x75mm HEX HEAD BOLT, M10x70mm HEX HEAD BOLT, M10x65mm HEX HEAD BOLT, M10x50mm HEX HEAD BOLT, M10x20mm SOCKET HEAD CAP SCREW, M10x45mm...
- Page 7 PLT200 PART LIST Part # DESCRIPTION TOP PLATE METAL BUSHING, ø18x ø10.5x13.5mm CABLE, 3210mm PULLEY, ø96mm TOP BOLT CABLE END LOCK M10 NYLON LOCK NUT M8 NYLON LOCK NUT M10 LOCK WASHER CABLE, 3210mm...
- Page 8 PLT200 HARDWARE ILLUSTRATION Part #1 M10x75mm HEX HEAD BOLT QTY. 4 Part #2 M10x70mm HEX HEAD BOLT QTY. 2 Part #3 M10x65mm HEX HEAD BOLT QTY. 5 ...
- Page 9 PLT200 HARDWARE ILLUSTRATION Part #5 M10x20mm HEX HEAD BOLT QTY. 1 Part #6 M10X45mm SOCKET HEAD CAP SCREW QTY. 1 Part #7 M8x65mm HEX DEAD BOLT QTY. 2 ...
- Page 10 PLT200 HARDWARE ILLUSTRATION Part #10 M10 WASHER QTY. 18 Part #12 M8 WASHER QTY. 4 Part #13 M12 HEX NUT QTY. 2 ...
- Page 11 PLT200 HARDWARE ILLUSTRATION Part #28 M10 NYLON LOCK NUT QTY. 14 Part #29 M8 NYLON LOCK NUT QTY. 2 Part #31 M10 LOCK WASHER QTY. 1 ...
- Page 12 PLT200 STEP 1 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: Finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, must wrench tighten.
- Page 13 PLT200 STEP 1 Above shows step 1 assembled and completed...
- Page 14 PLT200 STEP 2 NOTE: Finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, must wrench tighten. NOTE: There are two options for weight installation. 2A.
- Page 15 PLT200 STEP 2 Above shows Step 2 (Option #1) assembled and Above shows Step 2 (Option #2) assembled and completed. completed. Note: Guide Rod Note: Guide Rod with holes on the with holes on the side face down side face down...
- Page 16 PLT200 STEP 3 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: Wrench tighten all hardware at the end of Step 3B. some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, must wrench tighten. 3A.
- Page 17 PLT200 STEP 3 Above shows step 3 assembled and completed...
- Page 18 PLT200 STEP 4 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: Wrench tighten all hardware at the end of Step 4G. some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, must wrench tighten. Put the key ring of the Weight Selector Pin (#20) onto the threaded end of the Top Bolt (#26).
- Page 19 PLT200 STEP 4 Above shows step 4 assembled and completed...
- Page 20 PLT200 STEP 5 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: Some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. Attach Lat Bar (J) to Top Cable (#24). Attach Short Bar (K) to Low Cable (#32).
- Page 21 PLT200 STEP 5 Above shows step 4 assembled and completed...
- Page 22 PLT200 EXPLODED VIEW...
- Page 23 NOTE...
- Page 24 PLT200 please write your serial number in the boxes below 018501-��-��-����-���� S/N # 1900 S. Des Plaines Ave. Forest Park, IL 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST...
