- Page 1 PGM200X GLUTE MASTER Owner’s Manual WWW.BODYSOLID.COM ¡ ¢ £ ¤ ¥ ¥ ¦ § ¥ ¨ ¨ ¥ ¨ ¤...
- Page 2 THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF EQUIPMENT. TO MINIMIZE RISK, YOU MUST FOLLOW THESE RULES: Inspect equipment before each workout. Check that all nuts, bolts, screws and pop pins are in place and fully tightened. Also, before use, check cables for sign of wear. Replace all worn parts immediately.
-
Page 3: Table Of Contents
PGM200X TABLE OF CONTENTS • SAFETY INSTRUCTIONS....... PAGE 4 • PREPARATION........PAGE 5 • HARDWARE LIST........PAGE 6 • HARDWARE ILLUSTRATION....PAGE 7 • PART LIST / ILLUSTRATION....PAGE 9 • ASSEMBLY INSTRUCTIONS....PAGE 10 • EXPLODED VIEW........PAGE 16 •... -
Page 4: Safety Instructions
Owner’s Manual. Use only • Keep hands, limbs, loose clothing, and long hair well Powerline by Body Solid replacement parts when out of the way of all moving parts • Use care when getting on or off the unit. -
Page 5: Preparation
PGM200X PREPARATION Required tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each step. the PGM200X include but are not limit to: While you may be able to assemble the PGM200X using the •... -
Page 6: Hardware List
PGM200X HARDWARE LIST PART # SIZE DESCRIPTION QUANTITY... -
Page 7: Hardware Illustration
PGM200X HARDWARE ILLUSTRATION Part #30 M10X55mm hex head bolt QTY. 6 Part #31 M10X60mm hex head bolt QTY. 2 Part #32 M8X40mm hex head bolt QTY. 2 Part #33 M8X20mm hex head bolt QTY. 8 Part #34 M8X50mm hex head bolt QTY. - Page 8 PGM200X HARDWARE ILLUSTRATION CONT. Part #41 M8 nylon lock nut QTY. 8 Part #43 M10 nut QTY. 1 Part #50 M10 washer QTY. 16 Part #51 M8 washer QTY. 26 Part #54 M10 spring washer QTY. 10...
-
Page 9: Part List / Illustration
PGM200X PART LIST PartA PartB PartC mainframe base frame r-elbow frame [1pcs] [1pcs] [1pcs] PartD PartE PartF l-elbow frame vertical frame adjust frame [1pcs] [1pcs] [1pcs] PartG PartH PartJ sliding frame connect frame r-foot plate [1pcs] [1pcs] [1pcs] PartK PartL PartM l-foot plate leg pad... -
Page 10: Assembly Instructions
PGM200X STEP 1 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. 1A. - Page 11 PGM200X STEP 1...
- Page 12 PGM200X STEP 2 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. 2A.
- Page 13 PGM200X STEP 2...
- Page 14 PGM200X STEP 3 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware FIRST in this step. wrench tighten all hardware at the END of step 3F. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten.
- Page 15 PGM200X STEP 3...
-
Page 16: Exploded View
PGM200X EXPLODED VIEW... - Page 17 PGM200X NOTES...
-
Page 18: Contact Page
PGM200X please write your serial number in the boxes below S/N # Body-Solid ® Built for Life 1900 S. Des Plaines Ave. 1900 S. Des Plaines Ave. Forest Park, IL 60130 Forest Park, IL 60130 Phone:(708)427-3555 Phone:(708)427-3555 Fax:(708)427-3556 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST Hours: M-F 8:30 - 5:00 CST www.bodysolid.com Copyright 2011.
