- Page 1 PSC-43X SEATED CALF RAISE Owner’s Manual WWW.BODYSOLID.COM ¡ ¢ ¡ £ ¤ ¤ ¥ ¦...
- Page 2 THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF EQUIPMENT. TO MINIMIZE RISK, YOU MUST FOLLOW THESE RULES: Inspect equipment before each workout. Check that all nuts, bolts, screws and pop pins are in place and fully tightened. Also, before use, check cables for sign of wear. Replace all worn parts immediately.
-
Page 3: Table Of Contents
PSC-43X TABLE OF CONTENTS • SAFETY INSTRUCTIONS....... PAGE 4 • PREPARATION........PAGE 5 • HARDWARE LIST........PAGE 6 • HARDWARE ILLUSTRATION....PAGE 7 • PART LIST / ILLUSTRATION....PAGE 10 • ASSEMBLY INSTRUCTIONS....PAGE 12 • EXPLODED VIEW........PAGE 18 •... -
Page 4: Safety Instructions
• Use care when getting on or off the unit. Powerline by Body Solid replacement parts when servicing this machine. Failure to do so will void your • Do no overexert yourself or work to exhaustion. -
Page 5: Preparation
PSC-43X PREPARATION Required tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each step. the PSC-43X include but are not limit to: While you may be able to assemble the PSC-43X using the •... -
Page 6: Hardware List
PSC-43X HARDWARE LIST PART # SIZE DESCRIPTION QUANTITY... -
Page 7: Hardware Illustration
PSC-43X HARDWARE ILLUSTRATION Part #1 1/2”X 3 1/2” hex head bolt Qty. 1 Part #2 M12X80mm hex head bolt Qty. 2 Part #3 M10X70mm hex head bolt Qty. 6 Part #4 5/16”X2 3/4” hex head bolt Qty. 2 Part #5 1/2”... - Page 8 PSC-43X HARDWARE LIST CONT. Part #6 M12 nylon lock nut Qty. 2 Part #7 M10 nylon lock nut Qty. 6 Part #8 M10 (I.D.) washer Qty. 4 Part #9 5/16” (I.D.) washer Qty. 2 Part #10 5/16” spring washer Qty. 2...
- Page 9 PSC-43X HARDWARE ILLUSTRATION Part #11 2”X2” foot cap Qty. 4 Part #12 2”X2” end cap Qty. 4 Part #13 1 3/4”X1 3/4” end cap Qty. 2 Part #14 48mm dia. round end cap Qty. 2 Part #15 1” dia. round end cap Qty.
-
Page 10: Part List / Illustration
PSC-43X PART LIST Part A Part B Part C support frame mainframe weight holder [1pcs] [1pcs] [1pcs] Part D Part E Part F ring pin frame roller adjuster foot frame [1pcs] [1pcs] [1pcs]... - Page 11 PSC-43X PART LIST CONT. Part G Part H Part I seat frame base frame weight rod [1pcs] [1pcs] [1pcs] Part J Part K seat pad roller rod [1pcs] [1pcs] Note: weight rod (I) is 500mm long and roller rod (K) is 445mm long...
-
Page 12: Assembly Instructions
PSC-43X STEP 1 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. 1A. - Page 13 PSC-43X STEP 1 Above shows STEP 1 assembled and completed...
- Page 14 PSC-43X STEP 2 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. 2A.
- Page 15 PSC-43X STEP 2 Above shows STEP 2 assembled and completed M10 nut M10X25mm bolt...
- Page 16 PSC-43X STEP 3 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten. 3A.
- Page 17 PSC-43X STEP 3 Above shows STEP 3 assembled and completed...
-
Page 18: Exploded View
PSC-43X EXPLODED VIEW M10 nut M10X25mm bolt... - Page 19 PSC-43X NOTES...
-
Page 20: Contact Page
PSC-43X please write your serial number in the boxes below S/N # Body-Solid ® Built for Life 1900 S. Des Plaines Ave. Forest Park, IL 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST www.bodysolid.com Copyright 2011. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and speci cations when we feel it will improve the product. Body-Solid machines maintain several patented and patent pending features and designs.
