Abmessungen

Maßangabe in mm

Montage

Montage auf Hutschiene | DIN rail mounting

Click!

Dimensions

45 70,5

31,1

47,5

74,5

Dimensions in mm

Mounting

1 x

2 x

Schraubbefestigung | Screw mounting

isoES425_D00214_01_Q_DEEN/ 11.2023

ISOMETER® isoES425

Click
