HULALA
H
NOTE:
This brochure contains IMPORTANT safty info. Please read
and keep for future reference.
O
ITEM NO. SBHM0638
M
E
1/27

Advertisement

loading
Need help?

Need help?

Do you have a question about the SBHM0638 and is the answer not in the manual?

Questions and answers

Summary of Contents for HULALA HOME SBHM0638

  • Page 1 HULALA ITEM NO. SBHM0638 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 1/27...
  • Page 2 MAINTAINANCE AND WARNING Keep furniture away from heat. Do not clean furniture with harsh cleansers or polish. Do not use detergents, Solvents, abrasives, spray packs or leather cleaner. Use non-color mild soap with warm water clean spills(Mix 1:10 soap to water) Do not place furniture under direct sunlight, material will possibly fade over time.
  • Page 3 ASSEMBLY INSTRUCTIONS 3/27...
  • Page 4 PARTS LIST Bottom panel Top Panel Left side panel Middle vertical panel Back panel Right side panel Left door Adjustable shelf 4/27...
  • Page 5 PARTS LIST Middle right door Middle left door Right door 5/27...
  • Page 6 HARDWARE LIST Bolt Spring Washer ø1/4”x1-1/4”L Flat washer Screw ø1/8”x3/4”L Allen wrench Doorstop Screw Hinge ø3x15mm Shelf holder Screw Hinge ø3x15mm Bracket Screw Plastic belt Expansion nut ø7x35mm Screwdriver 6/27...
  • Page 7 SPARE Screw Screw ø3x15mm ø3x15mm Be sure to check all packing material carefully for small parts, which may have come loose inside the carton during shipment. 7/27...
  • Page 8 ASSEMBLY INSTRUCTIONS Step 1 Insert leg(L/M) to bottom panel(B). 8/27...
  • Page 9 ASSEMBLY INSTRUCTIONS Step 2 L&M Attach leg(L/M) to bottom panel(B) with bolt(1) ,flat washer(2) and spring washer(3), tight it with Allen wrench(4). 9/27...
  • Page 10 ASSEMBLY INSTRUCTIONS Step 3 C&D&E C&D&E Attach left side panel(C) ,middle vertical panel(D)and right side panel(E) to bottom panel(B), and tight it with Allen wrench(4). 10/27...
  • Page 11 ASSEMBLY INSTRUCTIONS Step 4 Attach head rebounder(5) to top panel(A) with screw(6) , tight it with screwdriver(16). 11/27...
  • Page 12 ASSEMBLY INSTRUCTIONS Step 5 C&D&E C&D&E Attach preassemble unit at step 4 to top panel(A) , and tight it with Allen wrench(4). 12/27...
  • Page 13 ASSEMBLY INSTRUCTIONS Step 6 Attach back panel( F) to the unit preassembly unit at step 5 with screw (7), tight screw with screwdriver(16). 13/27...
  • Page 14 ASSEMBLY INSTRUCTIONS Step 7 shelf holder can be adjusted up or down Insert shelf holder (8) to preassemble unit at step 6 , and attach adjustable shelf (G) to it. 14/27...
  • Page 15 ASSEMBLY INSTRUCTIONS Step 8 Attach hinge(9) to left door(H) with screw (11). Tight screw with screwdriver(16). 15/27...
  • Page 16 ASSEMBLY INSTRUCTIONS Step 9 Attach hinge(9) to right door(K) with screw (11). Tight screw with screwdriver(16). 16/27...
  • Page 17 ASSEMBLY INSTRUCTIONS Step 10 Attach hinge(10) to middle left door(I) with screw (11). Tight screw with screwdriver(16). 17/27...
  • Page 18 ASSEMBLY INSTRUCTIONS Step 11 Attach hinge(10) to middle right door(J) with screw (11). Tight screw with screwdriver(16). 18/27...
  • Page 19 ASSEMBLY INSTRUCTIONS Step 12 Attach left door(H) and middle left door(I) to preassemble unit at step 7 with screw(11), tight screw with screwdriver(16). 19/27...
  • Page 20 ASSEMBLY INSTRUCTIONS Step 13 Close the door , if the doors are not at the desired position , please adjust it as shown. 20/27...
  • Page 21 ASSEMBLY INSTRUCTIONS Step 14 Attach middle right door(J) and right door(K) to preassemble unit at step 13 with screw(11), tight screw with screwdriver(16). 21/27...
  • Page 22 ASSEMBLY INSTRUCTIONS Step 15 Close the door , if the doors are not at the desired position , please adjust it as shown. 22/27...
  • Page 23 ASSEMBLY INSTRUCTIONS Step 16 Attach bracket(12) to preassemble unit at step 15 with screw(11), tight screw with screwdriver(16). 23/27...
  • Page 24 ASSEMBLY INSTRUCTIONS Step 17 Drill hole on the wall , and insert expansion nut(13) , then attach bracket(12) to it with screw(14), tight screw with screwdriver(16). 24/27...
  • Page 25 ASSEMBLY INSTRUCTIONS Step 18 Furniture Furniture Wall Wall Attach the unit to the wall with plastic belt(15) Anti-tipping hardware must be used for this product to avoid tipping and injury. If the unit is not stable , please adjust the adjustable level. 25/27...
  • Page 26 ASSEMBLY INSTRUCTIONS Step 19 H&I&J&K If the door is over out or over in when close it , please adjust it as image. 26/27...
  • Page 27: Warranty

    WARRANTY We strive to offer high-quality products, and we also try our best to satisfy each and every customer that orders from us with product or service as needed. We provide 30 days warranty starting from the time you receive the item. Each customer must provide a record of their order such as the order number, or item receipt for any items that are out of the warranty period you may also still receive replacement parts by purchasing them...
