DEMO9S08LG32—Quick Start Guide Quick Start Guide DEMO9S08LG32 Up to 5V MCU with integrated LCD display driver • Quick Start Guide • Lab Tutorial • CodeWarrior Manual ™ • Getting Started CD...
Page 2
Get to Know the DEMO9S08LG32 Board Footprint Only MCU I/O Expansion Header Power Selection Switch LCD Glass 12V Input, Selection Barrel Jumpers Connector LEDs Connector for Debugger KBI Switches and Power Buzzer LCD Contrast Control POT MC9S08LG32 Potentiometer Figure 1. DEMO9S08LG32 Board...
Page 3
DEMO9S08LG32—Quick Start Guide Introduction DEMO9S08LG32 is a cost-effective board targeting quick microcontroller evaluation. The MC9S08LG32 device is a 5V Freescale microcontroller with an integrated liquid crystal display (LCD) driver for automotive and industrial applications. DEMO9S08LG32 contains an on-board display that allows developers to explore software development using the integrated LCD driver.
Page 4
CD to learn more about the key benefits that LG32 provides to your Insert the Getting Started CD from applications. DEMO9S08LG32 kit into the CDROM drive on your computer to install CodeWarrior. This provides the driver files for built-in debug support. The CodeWarrior v.6.2...
Page 5
DEMO9S08LG32—Quick Start Guide STEP Verify the default jumper positions on the board All jumpers 2–88 shunted for LCD applications USER 1 and 2 jumpers 1–8 connected ADC jumper VDDA connected Connected for buzzer application MCU_EN and AGND jumpers connected Connected to FIX...
Page 6
STEP STEP Install example software and Connect the USB cable program the demo board between the PC and the USB debugger connector The CD provided in the demo board kit contains example software. Insert the CD Operating system will recognize your into your computer.
Page 7
DEMO9S08LG32—Quick Start Guide When the debugger is launched: From the connection manager click “Connect (Reset).” From Erase and Program Flash menu, click “Yes” to allow the debugger to mass erase the microcontroller’s on-chip memory and program it with the new application.
Page 8
The flash programming status window (shown below) will appear. Click Run When CodeWarrior makes the connection, the integrated debugger circuit provides power to the MCU if PWR_SEL is connected as VB, thus enabling the application to run.
Page 9
DEMO9S08LG32—Quick Start Guide STEP Use combination of KEY1 to KEY8 to see the various functionalities of the LG32 demo in accordance with the table below KEY1 Mode > LCD Demo SPED Speedometer Fuel Driver Info Demo Demo Demo Demo Demo...
