Freescale Semiconductor
Data Sheet: Technical Data
KE02 Sub-Family Data Sheet
Supports the following:
MKE02Z16VLC2(R),
MKE02Z32VLC2(R),
MKE02Z64VLC2(R),
MKE02Z16VLD2(R),
MKE02Z32VLD2(R),
MKE02Z64VLD2(R),
MKE02Z32VLH2(R),
MKE02Z64VLH2(R),
MKE02Z32VQH2(R), and
MKE02Z64VQH2(R)
Key features
• Operating characteristics
– Voltage range: 2.7 to 5.5 V
– Flash write voltage range: 2.7 to 5.5 V
– Temperature range (ambient): -40 to 105°C
• Performance
– Up to 20 MHz ARM® Cortex-M0+ core
– Single cycle 32-bit x 32-bit multiplier
– Single cycle I/O access port
• Memories and memory interfaces
– Up to 64 KB flash
– Up to 256 B EEPROM
– Up to 4 KB RAM
• Clocks
– Oscillator (OSC) - supports 32.768 kHz crystal
or 4 MHz to 20 MHz crystal or ceramic
resonator; choice of low power or high gain
oscillators
– Internal clock source (ICS) - internal FLL with
internal or external reference, 31.25 kHz pre-
trimmed internal reference for 16 MHz system
clock (able to be trimmed for up to 20 MHz
system clock)
– Internal 1 kHz low-power oscillator (LPO)
Freescale reserves the right to change the detail specifications as may be
required to permit improvements in the design of its products.
© 2013–2014 Freescale Semiconductor, Inc.
Document Number MKE02P64M20SF0
MKE02P64M20SF0
• System peripherals
– Power management module (PMC) with three
power modes: Run, Wait, Stop
– Low-voltage detection (LVD) with reset or
interrupt, selectable trip points
– Watchdog with independent clock source
(WDOG)
– Programmable cyclic redundancy check module
(CRC)
– Serial wire debug interface (SWD)
– Bit manipulation engine (BME)
• Security and integrity modules
– 64-bit unique identification (ID) number per chip
• Human-machine interface
– Up to 57 general-purpose input/output (GPIO)
– Two up to 8-bit keyboard interrupt modules
(KBI)
– External interrupt (IRQ)
• Analog modules
– One up to 16-channel 12-bit SAR ADC,
operation in Stop mode, optional hardware
trigger (ADC)
– Two analog comparators containing a 6-bit
DAC and programmable reference input
(ACMP)
Rev 4, 10/2014
