Specifications
Model
Fieldbus
Device type
Communication speed
Configuration file
Occupied area
(Number of inputs/outputs)
Power supply (control and input)
Terminal resistor
Internal current consumption
(The power supply for control and input)
Polarity of output
Output channel
Connected load
Power supply (output)
Output for com. error
Protective function
Enclosure
Operating temperature range
Storage temperature range
Operating humidity range
Withstand voltage
Insulation resistance
Standard
Weight
1: All unused connectors must have the seal cap fitted.
•PROFIBUS DP function
Model number
Address setting range
FREEZE function
SYNC function
FAIL SAFE function
ID number
EX600-SPR1A
Source/PNP (Negative common)
Solenoid valve with circuit of protection of surge voltage
500 VAC for 1 minute between external terminals and FE
500 VDC, 10 MΩ or more between external terminals and FE
CE marking (EMC directive, RoHS directive), UL(CSA)
EX600-SPR1A EX600-SPR2A
1 to 125
Supported
Supported
Supported
1411 (Hex)
-25-
PROFIBUS DP (DP-V0)
PROFIBUS DP
9.6/19.2/45.45/93.75/187.5/500 kbps
1.5/3/6/12 Mbps
GSD (SMCB1411.gsd)
(512 inputs/512 outputs) max.
24 VDC Class 2, 2 A
Internally implemented (For type A cable)
80 mA or less
Sink/NPN (Positive common)
32 outputs (8/16/24/32 outputs selectable)
of 24 VDC 1.5 W (SMC)
24 VDC Class2, 2 A
HOLD/CLEAR/Force ON
Short circuit protection
IP67 (with manifold assembled)
o
-10 to 50 C
o
-20 to 60 C
35 to 85%RH (no condensation)
300 g
EX600-SPR2A
1
No.EX※※-OMN0028-D
