Technical Information
A.4.7 Digital input specification
Number of Inputs
Minimum high voltage
Minimum low voltage
Maximum leakage current
Insulation voltage
Connector
Comments
A.4.8 Electrical specifications
Nominal Supply Voltage
Nominal Power Consumption
Inrush Current Characteristics
DC Voltage range
Interruptions on Power Supply
voltage Class
Supply Change-over Class
Earth Protection Reference
Power over Ethernet
For safe operation, the Teldat 5Ge-Rail devices have a protective earth connection. The earth lead should have a
minimum cross-section of 2.5 mm and the distance between the device and the earth connection should be as short
as possible.
A.4.9 Mechanical specifications
Equipment dimensions without
cable
(W x L x H)
Weight
Material
Noise
Ingress Protection Rating
LEDs
32
1 on-board
12 V d.c. For use with 24 V (or higher) battery systems
6 V d.c.
1 mA. To limit power consumption at high input voltages
1500 V d.c. Input to output.
M12.
Polarity Independent.
Surge protection is highly recommended when connecting to power sources to en-
sure the safety and reliability of the device.
Un = 24 V – 110 V d.c.
12 W typical, 20W maximum at full load, 55 W maximum for a short time in special
cases.
0.1 A 2s [I2t].
16.8 V – 137.5 V d.c.
S2 (10 ms)
Not supported
Zero Volts or Ground
According to 802.3at (PoE+) on LAN-1 (> 5 °C only)
ca. 212 x 212 x 40 mm plus 30 mm mounting kit (2 x 15 mm).
Approx. 3000 g.
Paint-coated galvanized iron sheet.
0 dB (fanless).
IP40 (EN 60529) Solid particle protection > 1 mm.
5 (Power, LAN1, LAN2, W, SIM).
