Poe - Teldat 5Ge-Rail Installation Manual

Teldat S.A.
Note
To install the power cable using the M12 cable connector, ensure that the maximum tightening torque
does not exceed 0.4Nm to prevent damage to the router connector. Regular checkups should be con-
ducted after the initial connection to verify proper fitting.
3.3.1.2 Power cable
Please note that the power cable is not included with the router. The estimated maximum consumption for this equip-
ment is 0.5 A (at 110 VDC) or 2.5 A (at 24 VDC). Any cable with four conductors and a gauge of 0.50 mm
or greater is acceptable. The specific cable type and gauge will depend on the female connector being used.
There is no requirement for a shielded cable, although you may choose to use one. If you decide to use a shielded
cable, we advise connecting it to the grounding point on the other side of the router, the ground point on the power
supply, or both.
It is important that the cable you use is certified for flammability. Look for a CE or UL marking to ensure this certifica-
tion.
To connect
Ensure that the power supply cable is not yet connected
to the device.
Connect all data cables.
Proceed to connect the power supply cable to the device. Disconnect any data cables that may be connected.
Finally, connect the power supply cable to the power
supply.

3.3.2 PoE

The Teldat 5Ge-Rail device can be powered through an Ethernet cable, but only if the cable complies with the POE
802.3at standard (PoE+). The LAN1 port on the device is designed to support this type of power delivery.
To connect the PoE injector to the device, please refer to the image below:
Teldat 5Ge-Rail
It is important to be cautious when dealing with electric current in power cables,
telephone lines, and communication cables as it can be dangerous. Before in-
stalling, handling, or opening the equipment covers, make sure to connect and dis-
connect the cables according to the instructions provided in the following table in
order to prevent electric shocks:
To disconnect
Disconnect the power supply cable from the power sup-
ply.
Disconnect the power supply cable from the device.
3 Components and Power Supply
2
(AWG20)
11
