A.4.5 Configuration interface
Interface
Protocols
Speed
Connector
A.4.6 Digital output specification
Number of Outputs
Switching voltage
Switching current
Switching power
Insulation voltage
Connector
Comments
Teldat 5Ge-Rail
This can be configured in two modes:
Asynchronous Port :
V.24 DCE. Hardware flow control is not permitted.
Local Console:
V.24 DCE only 8-N-1, without flow control.
Asynchronous Port:
AT, PPP, GPS-DATA.
Asynchronous Port:
300 at 115,200 bps.
Local console:
115,200 bps (by default).
M12 8P A-Coded
1 on-board
110 V d.c.
1 A
30 W d.c.
1500 V d.c. Control to contact.
M12.
Relay Contact.
Surge protection is highly recommended when connecting to power sources to en-
sure the safety and reliability of the device.
