EIP Protocol
User Manual
Class 3 Client/UClient [x] Commands Controller Tag Access
Parameter
Enable
Internal Address
Poll Interval
Reg Count
Swap Code
IP Address
Slot
Func Code
Data Type
Tag Name
Page 68 of 218
Description
Value
Enable Specifies if the command should be executed and
Disable under what conditions.
Conditional Write Enable - The Command is executed each scan of the
command list
Disable- The command is disabled and will not be
executed
Conditional Write - The Command executes only if
the internal data associated with the command changes
0 to 3999 Specifies the database address in the modules internal
database to be associated with the command. If the
command is a read function, the data received in the
response message is placed at the specified location. If
the command is a write function data used in the
command is sourced from specified data area.
0 to 65535 Specifies the minimum interval to execute continuous
commands. The parameter is entered in 1/10 of a
second. If a value of 100 is entered for a command the
command executes no more frequently than every 10
seconds.
Specifies the number of data points to be read from or
written to the target device.
None Specifies if the data from the server is to be ordered
Word swap differently than it was received. This parameter is
Word and Byte typically used when dealing with floating-point or other
swap multi-register values.
None - No change is made (abcd)
Byte swap
Word swap - The words are swapped (cdab)
Word and Byte swap - The words and bytes are
swapped (dcba)
Byte swap - The bytes are swapped (badc)
xxx.xxx.xxx.xxx Specifies the IP address of the target device to be
addressed by this command
-1 Use a value of -1 when interfacing to a PLC5 These
devices do not have a slot parameter. When addressing
a processor in a ControlLogix or CompactLogix, the slot
number corresponds to the slot in the rack containing
the controller being addressed.
332 Specifies the function code to be used in the command.
333 332 - CIP Data Table Read
333 - CIP Data Table Write
Bool Specifies the data type of the target controller tag
SINT name.
INT
DINT
REAL
DWORD
Specifies the controller tag in the target PLC.
