5.1.1 EtherNet/IP™ Client
In Client mode, the gateway controls the read/write data transfer between the
gateway and other EtherNet/IP devices.
Number of Clients Supported
Command List
Polling of Command List
Other Configurable Parameters
ProSoft Technology, Inc.
May 26, 2016
Connected Clients: 2
Unconnected Clients: 1
Support for 100 commands per Client, each configurable for
command type, IP address, register to/from addressing and
word/bit count.
User-configurable polling of commands, including disabled,
continuous and on change of data (write only).
Number of Commands (up to 100 per Client)
Min Command Delay
Response Timeout
Retry Count
Command Error Pointer
EIP Protocol
